Notes: 2 Fuel Pumps may be Required - 1 Externally Mounted & 1 Mounted In Tank;Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
Current Draw: 5
Flow Rating: 28 gph
Fuel Type: Gas
Gasket or Seal Included: No
In Tank or External: External
Inlet Outside Diameter: 0.313''
Inlet Type: Quick Connect
Item Grade: Standard Replacement
Maximum Pressure: 99.0 PSI
Outlet Outside Diameter: 0.313''
Outlet Type: Quick Connect
Pump Type: Electric
Strainer Included: No
System Pressure: 44 psi
Terminal Gender: Male
Terminal Quantity: 2
Terminal Type: Threaded
UPC: 689604032619
Voltage: 12 VDC
Wiring Harness Included: No
Part Description: 1985 Ford Mustang In Line Electric Fuel Pump
Notes: From 11/1984;Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
Current Draw: 7
Flow Rating: 28 gph
Fuel Level Sender Assembly Included: No
Fuel Type: Gas
Gasket or Seal Included: Yes
In Tank or External: In Tank
Inlet Type: Strainer
Internal or External Strainer: External
Item Grade: Standard Replacement
Maximum Pressure: 80.0 PSI
Outlet Outside Diameter: 0.313''
Outlet Quantity: 2
Outlet Type: Quick Connect
Pump Type: Electric
Strainer Included: Yes
System Pressure: 36 psi
Terminal Gender: Male
Terminal Quantity: 2
Terminal Type: Pin
UPC: 689604218556
Voltage: 12.0 VDC
Part Description: 1985 Ford Mustang Fuel Pump Hanger Assembly
Notes: From 11/1984;Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
Current Draw: 6
Flow Rating: 32 gph
Fuel Type: Gas
Gasket or Seal Included: Yes
In Tank or External: In Tank
Inlet Type: Strainer
Item Grade: Standard Replacement
Maximum Pressure: 94.0 PSI
Outlet Outside Diameter: 0.313''
Outlet Type: Hose
Pump Type: Electric
Strainer Included: No
System Pressure: 44 psi
Terminal Gender: Male
Terminal Quantity: 2
Terminal Type: Blade
UPC: 689604033647
Voltage: 12 VDC
Wiring Harness Included: No
Part Description: 1985 Ford Mustang In Tank Electric Fuel Pump
Notes: 2 Fuel Pumps may be Required - 1 Externally Mounted & 1 Mounted In Tank;To 11/1984;Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
Current Draw: 10
Flow Rating: 39 gph
Fuel Type: Gas
Gasket or Seal Included: Yes
In Tank or External: In Tank
Inlet Type: Strainer
Item Grade: Standard Replacement
Maximum Pressure: 9.0 PSI
Outlet Outside Diameter: 0.313''
Outlet Type: Hose
Pump Type: Electric
Strainer Included: No
System Pressure: 6 psi
Terminal Gender: Male
Terminal Quantity: 2
Terminal Type: Pin
UPC: 689604033951
Voltage: 14 VDC
Wiring Harness Included: No
Part Description: 1985 Ford Mustang In Tank Electric Fuel Pump
Notes: To 11/84;Includes Tank Seal,In-Tank,FI,TBI,Automatic;Low Pressure Pump,In-Tank,FI,TBI;Low Pressure Pump,In-Tank,FI,TBI,Automatic;Low Pressure Pump,In-Tank,Turbocharged;Strainer required to validate the warranty: F111S,In-Tank,FI,TBI;Strainer required to validate the warranty: F111S,In-Tank,FI,TBI,Automatic;Strainer required to validate the warranty: F111S,In-Tank,Turbocharged;To 11/84;Includes Tank Seal,In-Tank,FI,TBI;To 11/84;Includes Tank Seal,In-Tank,Turbocharged;Two fuel pumps may be required, one mounted in-tank and one mounted externally.,In-Tank;Two fuel pumps may be required, one mounted in-tank and one mounted externally.,In-Tank,FI,TBI;Two fuel pumps may be required, one mounted in-tank and one mounted externally.,In-Tank,FI,TBI,Automatic
Gasket or Seal Included: Yes
Height (in.): 3
Inlet Type: Strainer
Length (in.): 7.5
Life Cycle Status Code: Available to Order
Maximum Free Flow (GPH): 50
Maximum Pump Pressure (PSI): 8
Minimum Free Flow (GPH): 50
Minimum Pump Pressure (PSI): 5
Outlet Size: .317
Outlet Type: Hose Connect
Package Contents: Pump & Kit
UPC: 072845114952
Weight (lbs.): 0.6
Width (in.): 3.75
Part Description: 1985 Ford Mustang Electric Fuel Pump
Notes: FROM 11-84; Incls Fuel Strainer & Tank Seal. Does not Incl Fuel Pump.;Fuel Pump Not Incld; FROM 11-84; Incls Fuel Strainer & Tank Seal. Does not Incl Fuel Pump.
Gasket Included: Y
Item Grade: STANDARD REPLACEMENT
Outlet Count: 1
Outlet Size: 3/8"
Outlet Type: QUICK CONNECT
Package Contents: PUMP & KIT
Package Quantity: 1
UPC: 080044047100
Part Description: 1985 Ford Mustang Fuel Pump Hanger
