1988 Honda Prelude Fuel Pump
My Vehicle Change Vehicle
1988 Honda Prelude
< Back to View All
Fuel Systems
- Department
- Product Fit
- Brands
- Prices
Product Specifications- Notes: Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
- Current Draw: 6
- Flow Rating: 26 gph
- Fuel Type: Gas
- Gasket or Seal Included: Yes
- In Tank or External: In Tank
- Inlet Type: Strainer
- Item Grade: Standard Replacement
- Maximum Pressure: 125.0 PSI
- Outlet Outside Diameter: 0.375''
- Outlet Type: Hose Bead
- Pump Type: Electric
- Strainer Included: No
- System Pressure: 44 psi
- Terminal Gender: Male
- Terminal Quantity: 2
- Terminal Type: Threaded
- UPC: 689604215265
- Voltage: 12 VDC
- Wiring Harness Included: No
- Part Description: 1988 Honda Prelude In Tank Electric Fuel Pump
Vehicle Fitment- 1988 Honda Prelude | All Trims | 4 Cyl 2.0L
Product Specifications- Notes: Strainer required to validate the warranty: F221S
- Average Current Draw(A): 6
- Average Flow Rating(GPH): 100
- Country of Orign: China
- Gasket or Seal Included: Yes
- Gasket Or Seal Material: FKM
- In Tank or External: In Tank
- Inlet Size: 0.433
- Inlet Type: Strainer
- Installation Warnings: No
- Maximum Pump Pressure (PSI): 123.3
- Minimum Pump Pressure (PSI): 79.8
- Negative Ground: No
- Outlet Quantity: 1
- Outlet Size: 0.346
- Outlet Type: Hose
- Product Height (in): 1.99
- Product Length (in): 4.94
- Product Width (in): 1.99
- Pump Type: Turbine
- Regulator Included: No
- Strainer Included: No
- Terminal Gender: Male
- Terminal Quantity: 2
- Terminal Type: Thread
- UPC: 00072845140340
- Voltage: 12V
- Weight (lbs): 1.25
- Wire Harness Included: No
- Part Description: 1988 Honda Prelude In Tank Electric Fuel Pump
Product Specifications- Notes: Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
- Current Draw: 10
- Flow Rating: 30 gph
- Fuel Level Sender Assembly Included: No
- Fuel Type: Gas
- Gasket or Seal Included: No
- Inlet Type: Strainer
- Internal or External Strainer: External
- Item Grade: Standard Replacement
- Maximum Pressure: 94.0 PSI
- Outlet Outside Diameter: 0.313''
- Outlet Quantity: 1
- Outlet Type: Hose
- Pump Location: In Tank
- Pump Type: Electric
- Strainer Included: Yes
- System Pressure: 3 psi
- Terminal Gender: Male
- Terminal Quantity: 2
- Terminal Type: Pin
- UPC: 689604233580
- Voltage: 12.0 VDC
- Part Description: 1988 Honda Prelude Fuel Pump And Sender Assembly
Vehicle Fitment- 1988 Honda Prelude | All Trims | 4 Cyl 2.0L
Product Specifications- Notes: Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
- Current Draw: 1
- Flow Rating: 42 gph
- Fuel Type: Gas
- Gasket or Seal Included: No
- In Tank or External: In Tank
- Inlet Type: Strainer
- Item Grade: Standard Replacement
- Maximum Pressure: 5.0 PSI
- Outlet Outside Diameter: 0.375''
- Outlet Type: Hose Bead
- Pump Type: Electric
- Strainer Included: No
- System Pressure: 3 psi
- Terminal Gender: Male
- Terminal Quantity: 2
- Terminal Type: Threaded
- UPC: 689604218952
- Voltage: 12 VDC
- Wiring Harness Included: No
- Part Description: 1988 Honda Prelude In Tank Electric Fuel Pump
Vehicle Fitment- 1988 Honda Prelude | All Trims | 4 Cyl 2.0L
Product Specifications- Notes: Includes Hose, Clamps, Isolator, & Tank Seal,SOHC,CARB;Strainer required to validate the warranty: F100S,SOHC,CARB;Includes Hose, Clamps, Isolator, & Tank Seal,DOHC,FI;Strainer required to validate the warranty: F100S,DOHC,FI
- Average Current Draw(A): 2
- Average Flow Rating(GPH): 115
- Connector Quantity: 2
- Connector Shape: Electrode column
- Country of Orign: China
- Gasket or Seal Included: No
- Grade Type: Performance
- In Tank or External: In Tank
- Inlet Size: 0.748
- Inlet Type: filter
- Installation Warnings: No
- Internal Or External Strainer: External
- Maximum Pump Pressure (PSI): 7.25
- Minimum Pump Pressure (PSI): 2.9
- Outlet Quantity: 1
- Outlet Size: 0.37
- Outlet Type: Male Quick Connect
- Product Height (in): 1.46
- Product Length (in): 4.13
- Product Width (in): 1.46
- Pump Type: Turbine
- Regulator Included: No
- Terminal Quantity: 2
- Terminal Type: Electrode column
- UPC: 00072845143822
- Voltage: 12V
- Weight (lbs): 0.41
- Part Description: 1988 Honda Prelude Electric Fuel Pump
Vehicle Fitment- 1988 Honda Prelude | All Trims | 4 Cyl 2.0L
Product Specifications- Notes: Strainer required to validate the warranty: F221S
- Average Current Draw(A): 6
- Average Flow Rating(GPH): 100
- Country of Orign: China
- Gasket or Seal Included: Yes
- Gasket Or Seal Material: FKM
- In Tank or External: In Tank
- Inlet Size: 0.433
- Inlet Type: Strainer
- Installation Warnings: No
- Maximum Pump Pressure (PSI): 123.3
- Minimum Pump Pressure (PSI): 79.8
- Negative Ground: No
- Outlet Quantity: 1
- Outlet Size: 0.346
- Outlet Type: Hose
- Product Height (in): 1.99
- Product Length (in): 4.94
- Product Width (in): 1.99
- Pump Type: Turbine
- Regulator Included: No
- Strainer Included: No
- Terminal Gender: Male
- Terminal Quantity: 2
- Terminal Type: Thread
- UPC: 00072845180346
- Voltage: 12V
- Weight (lbs): 1.25
- Wire Harness Included: No
- Part Description: 1988 Honda Prelude High Performance Electric Fuel Pump
Product Specifications- Notes: W/O Fuel Injection
- Item Dimensions: 16.3 x 5.9 x 5.3 inches
- Item Weight: 2.00 Pounds
- Replaces: 17708-SF1-A03, 17708-SF1-003, 17708-SF1-A04, 17708-SF1-A01, 17708-SF1-S06, 17708-SF1-A00, 17708-SF1-A06, 17708-SF1-A02, 17708-SF1-A05
- Part Description: 1988 Honda Prelude Pump Unit Assembly, Fuel
Vehicle Fitment- 1988 Honda Prelude | 2.0 S, 2.0 Si, 2.0 Si 4WS | 4 Cyl 2.0 L GAS
Product Specifications- Notes: DENSO OE Replacement Fuel Pump
- Gasket or Seal Included: No
- Gaskets Included: No
- Inlet Outside Diameter: 11.000
- Internal or External: Internal
- Internet Product Code (IPC): 7408C359E9B
- Item Grade: Premium Replacement
- Item has MSDS (SDS): Y
- MFG Brand Name: DENSO Auto Parts
- MFG Model # (Series): 951-0010
- MFG Name: DENSO
- Mounting Bracket Included: No
- Mounting Hardware Included: YES
- Negative Ground: Yes
- New or Remanufactured: NEW
- Outlet Quantity: 1
- Package Contents: Fuel Pump
- Regulator Included: NO
- Seal And Lock Ring Included: NO
- Strainer Included: NO
- Supplier Company Name: DENSO
- Universal Or Specific Fit: Specific
- UPC: 042511073586
- Voltage: 12
- Part Description: 1988 Honda Prelude Electric Fuel Pump
Vehicle Fitment- 1988 Honda Prelude | All Trims | 4 Cyl 2.0L
Product Specifications- Notes: Fuel Pump Not Incld; Incls Fuel Strainer & Tank Seal. Does no't Incl Fuel Pump.
- Gasket Included: Y
- Item Grade: STANDARD REPLACEMENT
- Outlet Count: 1
- Outlet Size: 5/16"
- Outlet Type: HOSE BEAD
- Package Contents: PUMP & KIT
- Package Quantity: 1
- UPC: 080044047384
- Part Description: 1988 Honda Prelude Fuel Pump Hanger
Vehicle Fitment- 1988 Honda Prelude | All Trims | 4 Cyl 2.0L
Product Specifications- Notes: W/Fuel Injection
- Item Dimensions: 16.6 x 6.2 x 5.3 inches
- Item Weight: 2.90 Pounds
- Fitment Type: Direct Replacement
- Replaces: 17708-SF1-934, 17708-SF1-S30, 17708-SF1-933, 17708-SF1-S31, 17708-SF1-932, 17708-SF1-931
- Part Description: 1988 Honda Prelude Pump Unit Assembly, Fuel
Vehicle Fitment- 1988 Honda Prelude | 2.0 S, 2.0 Si, 2.0 Si 4WS | 4 Cyl 2.0 L GAS
Product Specifications- Notes: with Plug Type Pump Electrical Connector;with 1.5 Inch Diameter Pump;Contains Hoses & Clamps;OE Replacement Pump
- Connector Gender: Male
- Connector Shape: Rectangle
- Fuel Pump Inlet Type: Strainer
- Fuel Sending Unit Included: No
- Gasket or Seal Included: Yes
- Inlet Attachment: Inlet-Strainer
- Inlet Count: 1
- Inlet Outside Diameter: 11.0
- Internal or External: Internal
- Internet Product Code (IPC): E8B947CDEF4
- Item Grade: OEM Standard Part
- Item has MSDS (SDS): No
- Length (Inch): 114.0
- Maximum Free Flow Rate (gph): 45
- Maximum Pressure (psi): 100
- MFG Brand Name: Airtex Products
- MFG Model # (Series): E8229
- Minimum Free Flow Rate: 33.0
- Minimum Free Flow Rate (gph): 45
- Minimum Pressure (psi): 80
- Mounting Hardware Included: No
- Muffler Outlet Diameter (in): 9.0
- Negative Ground: Yes
- Outlet Attachment: Outlet-HoseConnection
- Outlet Count: 1
- Outlet Fitting Thread Size: 5/16 Inch
- Outlet Quantity: 1
- Outlet Size: Outlet - .348
- Outlet Type: Hose Barb
- Package Contents: Pump and Kit
- Pump Type: Electric
- Regulator Included: No
- Seal And Lock Ring Included: No
- Strainer Included: No
- Supplier Company Name: Airtex Products
- Terminal Quantity: 2
- Terminal Type: Blade
- Universal Or Specific Fit: Specific
- UPC: 080044102496
- Voltage [V]: 12V
- Wiring Harness Included: Yes
- Part Description: 1988 Honda Prelude In-Tank Electric Fuel Pump
Vehicle Fitment- 1988 Honda Prelude | All Trims | 4 Cyl 2.0L
Product Specifications- Notes: Prelude; W/O Si Models
- Item Dimensions: 16.3 x 5.7 x 5.4 inches
- Item Weight: 2.00 Pounds
- Fitment Type: Direct Replacement
- Replaced by: 17708-SF1-S07
- Part Description: 1988 Honda Prelude Pump Unit Assembly, Fuel
Vehicle Fitment- 1988 Honda Prelude | 2.0 S | 4 Cyl 2.0 L GAS
Product Specifications- Gasket or Seal Included: No
- Inlet Attachment: Inlet-Strainer
- Inlet Type: STRAINER
- Internal or External: Internal
- Internet Product Code (IPC): E9319B510FB
- Item Grade: OEM Standard Part
- Item has MSDS (SDS): No
- Maximum Pressure (psi): 4
- MFG Brand Name: Airtex Products
- MFG Model # (Series): E8269H
- Minimum Pressure (psi): 1.0
- Outlet Attachment: Outlet-HoseBarb
- Outlet Size: 3/8
- Outlet Type: HOSE BARB
- Package Contents: Fuel Pump Assembly
- Package Quantity: 1
- Pump Type: Electrical
- Supplier Company Name: Airtex Products
- UPC: 080044136453
- Voltage [V]: 12V
- Wiring Harness Included: No
- Part Description: 1988 Honda Prelude Fuel Pump Hanger Assembly
Vehicle Fitment- 1988 Honda Prelude | All Trims | 4 Cyl 2.0L
Product Specifications- Notes: Includes Tank Seal, Isolator, Hose, Terminals & Clamps
- Gasket or Seal Included: No
- Inlet Attachment: Inlet-Strainer
- Inlet Type: STRAINER
- Internet Product Code (IPC): 3689800A340
- Item Grade: STANDARD REPLACEMENT
- Item has MSDS (SDS): No
- Maximum Pressure (psi): 4
- MFG Brand Name: Airtex Products
- MFG Model # (Series): E8371
- Minimum Pressure (psi): 2
- Outlet Attachment: Outlet-HoseConnection
- Outlet Size: Outlet - 3/8
- Outlet Type: HOSE CONNECT
- Package Contents: PUMP & KIT
- Package Quantity: 1
- Supplier Company Name: Airtex Products
- UPC: 080044090908
- Voltage [V]: 12V
- Part Description: 1988 Honda Prelude In-Tank Electric Fuel Pump
Vehicle Fitment- 1988 Honda Prelude | All Trims | 4 Cyl 2.0L
Product Specifications- Notes: Universal Electric Pump; May be used to replace mechanical pump
- Gasket Included: N
- Hazardous Material: No
- Inlet Count: 1
- Inlet Type: Female Thread
- Item Grade: Standard Replacement
- Maximum Free Flow Rate (gph): 30
- Maximum Pressure Rate (psi): 4.5
- Minimum Free Flow Rate (gph): 20
- Minimum Pressure Rate (psi): 2.5
- Outlet Count: 1
- Outlet Size: 1/8" - 27
- Outlet Type: Female Thread
- Package Contents: Pump & Kit
- Package Quantity: 1
- UPC: 080044050315
- Warranty: Lifetime Limited Warranty
- Part Description: 1988 Honda Prelude In-Line Electric Fuel Pump
Vehicle Fitment- 1988 Honda Prelude | All Trims | 4 Cyl 2.0L
