1990 Cadillac Fleetwood Fuel Pump
My Vehicle Change Vehicle
1990 Cadillac Fleetwood
< Back to View All
Fuel Systems
- Department
- Location
- Operation
- Product Fit
- Brands
- Prices
$81.72Product Specifications- Notes: Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Autobest recommends cleaning the fuel tank before installing a new pump.
- Current Draw: 4
- Flow Rating: 20 gph
- Fuel Type: Gas
- Gasket or Seal Included: Yes
- In Tank or External: In Tank
- Inlet Type: Strainer
- Item Grade: Standard Replacement
- Maximum Pressure: 71.0 PSI
- Outlet Outside Diameter: 0.313''
- Outlet Type: Hose Bead
- Pump Type: Electric
- Strainer Included: No
- System Pressure: 44 psi
- Terminal Gender: Male
- Terminal Quantity: 2
- Terminal Type: Pin
- UPC: 689604219218
- Voltage: 14 VDC
- Wiring Harness Included: No
- Part Description: 1990 Cadillac Fleetwood In Tank Electric Fuel Pump
Vehicle Fitment- 1990 Cadillac Fleetwood | All Trims | 8 Cyl 4.5L
$27.23Product Specifications- Notes: Improved Design;Original Pump;with 1 ,2 (in) Diameter Pump;Includes Hose, Clamps, Rubber Sleeve, Tank Seal, & Wires;Strainer required to validate the warranty: F141S;with 1 ,2 (in) Diameter Pump;Includes Hose, Clamps, Rubber Sleeve, Tank Seal, & Wires;Strainer required to validate the warranty: F141S;Includes Hose, Clamps, Rubber Sleeve, Tank Seal, & Wires;Strainer required to validate the warranty: F141S;with 1 ,2 (in) Diameter Pump
- Average Current Draw(A): 6
- Average Flow Rating(GPH): 100
- Country of Orign: China
- Gasket or Seal Included: Yes
- Gasket Or Seal Material: FKM
- In Tank or External: In Tank
- Inlet Size: 0.433
- Inlet Type: Strainer
- Installation Warnings: No
- Maximum Pump Pressure (PSI): 116
- Minimum Pump Pressure (PSI): 72.5
- Negative Ground: No
- Outlet Quantity: 1
- Outlet Size: 0.346
- Outlet Type: Hose
- Product Height (in): 1.99
- Product Length (in): 4.94
- Product Width (in): 1.99
- Pump Type: Turbine
- Regulator Included: No
- Strainer Included: No
- Terminal Gender: Male
- Terminal Quantity: 2
- Terminal Type: Thread
- UPC: 00072845122339
- Voltage: 12V
- Weight (lbs): 1.34
- Wire Harness Included: No
- Part Description: 1990 Cadillac Fleetwood In Tank Electric Fuel Pump
Vehicle Fitment- 1990 Cadillac Fleetwood | All Trims | 8 Cyl 4.5L
$23.14Product Specifications- Notes: Includes Tank Seals, Wires, Isolator, Rubber Sleeve & Clamps;Strainer required to validate the warranty: F102S;Includes Tank Seals, Wires, Isolator, Rubber Sleeve & Clamps;Strainer required to validate the warranty: F102S
- Average Current Draw(A): 5.5
- Average Flow Rating(GPH): 34.34
- Connector Gender: Male
- Connector Quantity: 1
- Connector Shape: Rectangle
- Country of Orign: China
- Gasket or Seal Included: No
- Grade Type: Performance
- In Tank or External: In Tank
- Inlet Size: 0.748
- Inlet Type: filter
- Installation Warnings: No
- Internal Or External Strainer: External
- Maximum Pump Pressure (PSI): 101.53
- Minimum Pump Pressure (PSI): 79.77
- Outlet Quantity: 1
- Outlet Size: 0.31
- Outlet Type: Male Quick Connect
- Product Height (in): 1.445
- Product Length (in): 5.157
- Product Width (in): 1.445
- Pump Type: Turbine
- Regulator Included: No
- Terminal Gender: Male
- Terminal Quantity: 2
- Terminal Type: Inserts
- UPC: 00072845122513
- Voltage: 12V
- Weight (lbs): 0.61
- Part Description: 1990 Cadillac Fleetwood In Tank Electric Fuel Pump
Vehicle Fitment- 1990 Cadillac Fleetwood | All Trims | 8 Cyl 4.5L
Product Specifications- Notes: w/50mm Dia Pump; DENSO Fuel Pump & Strainer Kit;w/50mm Dia Pump; DENSO Mfg. Replacement Fuel Pump & Strainer Kit
- Fuel Pump Type: Electrical
- Gaskets Included: No
- Internet Product Code (IPC): 79BDA7A4C49
- Item Grade: Premium Replacement
- Item has MSDS (SDS): Y
- MFG Brand Name: DENSO Auto Parts
- MFG Model # (Series): 950-0168
- MFG Name: DENSO
- Package Contents: Fuel Pump Kit
- Pump Placement: In Tank
- Supplier Company Name: DENSO
- UPC: 042511079922
- Part Description: 1990 Cadillac Fleetwood Fuel Pump And Strainer Set
Vehicle Fitment- 1990 Cadillac Fleetwood | All Trims | 8 Cyl 4.5L
Product Specifications- Notes: Improved Turbo Design; OE Pumps; Includes Tank Seal, Wires, Hose, Isolator, Rubber Sleeve & Clamps; Used to replace 1" & 2" Dia
- Connector Shape: Rectangle
- Fuel Pump Inlet Type: Strainer
- Fuel Sending Unit Included: No
- Gasket or Seal Included: Yes
- Inlet Attachment: Inlet-Strainer
- Inlet Count: 1
- Inlet Outside Diameter: 19.0
- Inlet Type: Strainer
- Internal or External: In Tank
- Internet Product Code (IPC): 9A383840EBD
- Item Grade: OEM Standard Part
- Item has MSDS (SDS): No
- Length (Inch): 133.0
- Maximum Free Flow Rate (gph): 55
- Maximum Pressure (psi): 95
- MFG Brand Name: Airtex Products
- MFG Model # (Series): E3222
- Minimum Free Flow Rate: 18.0
- Minimum Free Flow Rate (gph): 55
- Minimum Pressure (psi): 51.0
- Mounting Hardware Included: No
- Muffler Outlet Diameter (in): 8.0
- Negative Ground: Yes
- Outlet Attachment: Outlet-HoseConnection
- Outlet Count: 1
- Outlet Fitting Thread Size: 5/16
- Outlet Quantity: 1
- Outlet Size: Outlet - .365
- Outlet Type: Hose Barb
- Package Contents: Pump and Kit
- Pump Type: Electric
- Regulator Included: No
- Seal And Lock Ring Included: No
- Strainer Included: No
- Supplier Company Name: Airtex Products
- Terminal Gender: Male
- Terminal Quantity: 2
- Terminal Type: Pin
- Universal Or Specific Fit: Specific
- UPC: 080044089643
- Voltage [V]: 12V
- Wiring Harness Included: Yes
- Part Description: 1990 Cadillac Fleetwood In-Tank Electric Fuel Pump
Vehicle Fitment- 1990 Cadillac Fleetwood | 60 Special | 8 Cyl 4.5L
Product Specifications- Notes: Discontinued; 12V; 50PSI; 27GPH HI; IN-TANK
- UPC: 760687050209
- Part Description: 1990 Cadillac Fleetwood Fuel Pump
Vehicle Fitment- 1990 Cadillac Fleetwood | All Trims | 8 Cyl 4.5L
Product Specifications- Notes: w/50mm Dia Pump; DENSO Fuel Pump
- Gasket or Seal Included: No
- Gaskets Included: No
- Inlet Outside Diameter: 11.000
- Internal or External: Internal
- Internet Product Code (IPC): E2CD96F44CA
- Item Grade: Premium Replacement
- Item has MSDS (SDS): Y
- MFG Brand Name: DENSO Auto Parts
- MFG Model # (Series): 951-0013
- MFG Name: DENSO
- Mounting Bracket Included: No
- Mounting Hardware Included: YES
- Negative Ground: Yes
- New or Remanufactured: NEW
- Outlet Quantity: 1
- Package Contents: Fuel Pump
- Regulator Included: NO
- Seal And Lock Ring Included: NO
- Strainer Included: NO
- Supplier Company Name: DENSO
- Universal Or Specific Fit: Specific
- UPC: 042511073616
- Voltage: 12
- Part Description: 1990 Cadillac Fleetwood Electric Fuel Pump
Vehicle Fitment- 1990 Cadillac Fleetwood | All Trims | 8 Cyl 4.5L
Product Specifications- Connector Shape: Rectangle
- Fuel Sending Unit Included: No
- Gasket or Seal Included: Yes
- Inlet Attachment: Inlet-Strainer
- Inlet Count: 1
- Inlet Outside Diameter: 0.75
- Inlet Type: Strainer
- Internal or External: In Tank
- Internet Product Code (IPC): 9327248E2FF
- Item Grade: OEM Standard Part
- Item has MSDS (SDS): No
- Maximum Free Flow Rate (gph): 40
- Maximum Pressure (psi): 95
- MFG Brand Name: Airtex Products
- MFG Model # (Series): E3240
- Minimum Flow Rating: 15
- Minimum Free Flow Rate (gph): 40
- Minimum Pressure (psi): 42.0
- Mounting Hardware Included: No
- Negative Ground: Yes
- Outlet Attachment: Outlet-HoseConnection
- Outlet Count: 1
- Outlet Fitting Thread Size: 5/16
- Outlet Quantity: 1
- Outlet Size: Outlet - 5/16
- Outlet Type: Hose Connection
- Package Contents: Pump and Kit
- Pump Type: Electric
- Regulator Included: No
- Seal And Lock Ring Included: No
- Strainer Included: No
- Supplier Company Name: Airtex Products
- Terminal Gender: Male
- Terminal Type: Pin
- Universal Or Specific Fit: Specific
- UPC: 080044089650
- Voltage [V]: 12V
- Wiring Harness Included: Yes
- Part Description: 1990 Cadillac Fleetwood In-Tank Electric Fuel Pump
Vehicle Fitment- 1990 Cadillac Fleetwood | All Trims | All Engines
Product Specifications- Notes: Gas; 8 Cylinder; All
- Part Description: 1990 Cadillac Fleetwood Fuel Pump
Vehicle Fitment- 1990 Cadillac Fleetwood | 60 Special, Base, Brougham, d'Elegance | 8 Cyl 4.5 L GAS, 8 Cyl 4.9 L GAS, 8 Cyl 5.7 L GAS
Product Specifications- Notes: w/37mm Dia Pump; OE Replacement Fuel Pump
- Gasket or Seal Included: No
- Gaskets Included: Yes
- Inlet Outside Diameter: 19.000
- Internal or External: Internal
- Internet Product Code (IPC): E3BCD6939D7
- Item Grade: Premium Replacement
- Item has MSDS (SDS): Y
- MFG Brand Name: DENSO Auto Parts
- MFG Model # (Series): 951-5003
- MFG Name: DENSO
- Mounting Bracket Included: No
- Mounting Hardware Included: YES
- Negative Ground: Yes
- New or Remanufactured: NEW
- Outlet Quantity: 1
- Package Contents: Fuel Pump
- Regulator Included: NO
- Seal And Lock Ring Included: NO
- Strainer Included: NO
- Supplier Company Name: DENSO
- Universal Or Specific Fit: Specific
- UPC: 042511153714
- Voltage: 12
- Part Description: 1990 Cadillac Fleetwood Fuel Pump
Vehicle Fitment- 1990 Cadillac Fleetwood | All Trims | 8 Cyl 4.5L
Product Specifications- Notes: w/Sender Code CPW; Incls Fuel Pump, Sending Unit, Float, Fuel Strainer & Tank Seal
- Gasket or Seal Included: Yes
- Inlet Attachment: Inlet-Strainer
- Inlet Count: 1
- Inlet Type: STRAINER
- Internet Product Code (IPC): 73ED3266E06
- Item Grade: OEM Standard Part
- Item has MSDS (SDS): No
- Maximum Pressure (psi): 95
- MFG Brand Name: Airtex Products
- MFG Model # (Series): E3635S
- Minimum Pressure (psi): 65
- Outlet Attachment: Outlet-QuickConnect
- Outlet Count: 1
- Outlet Size: Outlet - 3/8
- Outlet Type: QUICK CONNECT
- Package Contents: Fuel Pump Assembly
- Package Quantity: 1
- Supplier Company Name: Airtex Products
- UPC: 080044020394
- Part Description: 1990 Cadillac Fleetwood Electric Fuel Pump
Vehicle Fitment- 1990 Cadillac Fleetwood | All Trims | 8 Cyl 4.5L
Product Specifications- Notes: Includes Tank Seals, Wires, Isolator, Rubber Sleeve & Clamps;Strainer required to validate the warranty: F102S;Includes Tank Seals, Wires, Isolator, Rubber Sleeve & Clamps;Strainer required to validate the warranty: F102S
- Average Current Draw(A): 5.5
- Average Flow Rating(GPH): 38.3
- Connector Gender: Male
- Connector Quantity: 1
- Connector Shape: Rectangle
- Country of Orign: China
- Gasket or Seal Included: Yes
- Grade Type: Performance
- In Tank or External: In Tank
- Inlet Size: 0.748
- Inlet Type: Strainer
- Installation Warnings: No
- Internal Or External Strainer: External
- Maximum Pump Pressure (PSI): 101.53
- Minimum Pump Pressure (PSI): 79.77
- Outlet Quantity: 1
- Outlet Size: 0.315
- Outlet Type: Hose
- Product Height (in): 1.445
- Product Length (in): 5.157
- Product Width (in): 1.445
- Pump Type: Turbine
- Regulator Included: No
- Terminal Gender: Male
- Terminal Quantity: 2
- Terminal Type: Inserts
- UPC: 00072845162519
- Voltage: 12V
- Weight (lbs): 0.61
- Part Description: 1990 Cadillac Fleetwood High Performance Electric Fuel Pump
Vehicle Fitment- 1990 Cadillac Fleetwood | All Trims | 8 Cyl 4.5L
- Product Specifications
- Notes: Cadillac; V8-350
- Part Description: 1990 Cadillac Fleetwood Fuel Pump
Vehicle Fitment- 1990 Cadillac Fleetwood | 60 Special | 8 Cyl 4.5 L GAS
