1993 Dodge Dakota Fuel Pump
My Vehicle Change Vehicle
1993 Dodge Dakota
< Back to View All
Fuel Systems
- Department
- Product Fit
- Brands
- Prices
Product Specifications- Notes: with 15 or 22 Gallon Tank;Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
- Current Draw: 8
- Flow Rating: 33 gph
- Fuel Level Sender Assembly Included: Yes
- Fuel Type: Gas
- Gasket or Seal Included: Yes
- In Tank or External: In Tank
- Inlet Type: Strainer
- Internal or External Strainer: External
- Item Grade: Standard Replacement
- Maximum Pressure: 80.0 PSI
- Outlet Outside Diameter: 0.375''
- Outlet Quantity: 2
- Outlet Type: Quick Connect
- Pump Type: Electric
- Regulator Included: No
- Resistance Ohms Empty: 101.0
- Resistance Ohms Full: 2.0
- Strainer Included: Yes
- System Pressure: 44 psi
- Terminal Gender: Male
- Terminal Quantity: 5
- Terminal Type: Pin
- UPC: 689604061435
- Vapor Pressure Sensor: No
- Voltage: 12.0 VDC
- Part Description: 1993 Dodge Dakota Fuel Pump Module Assembly
Vehicle Fitment- 1993 Dodge Dakota | All Trims | 4 Cyl 2.5L
- 1993 Dodge Dakota | All Trims | 6 Cyl 3.9L
- 1993 Dodge Dakota | All Trims | 8 Cyl 5.2L
Product Specifications- Notes: with 15 or 22 Gallon Tank;with 15 or 22 Gallon Tank;with 15 or 22 Gallon Tank
- Average Current Draw(A): 7
- Average Flow Rating(GPH): 33.1
- Connector Gender: Female
- Connector Quantity: 1
- Connector Shape: Rectangle
- Country of Orign: China
- Fuel Filter Included: No
- Fuel Sending Unit Included: Yes
- Fuel Tank Pressure Sensor Included: No
- Gasket or Seal Included: Yes
- Gasket Or Seal Material: FKM
- Grade Type: Regular
- Housing Material: POM
- In Tank or External: In Tank
- Inlet Size: 0.433
- Inlet Type: Strainer
- Installation Warnings: No
- Internal Or External Strainer: Internal
- Maximum Pump Pressure (PSI): 108.8
- Minimum Pump Pressure (PSI): 79.8
- Mounting Hardware Included: No
- Negative Ground: No
- Outlet Quantity: 1
- Outlet Type: Quick Connect
- Product Height (in): 5.83
- Product Length (in): 15.55
- Product Width (in): 8.07
- Pump Type: Turbine
- Regulator Included: No
- Resistance Ohms Empty: 105
- Resistance Ohms Full: 6
- Strainer Included: Yes
- Terminal Gender: Male
- Terminal Quantity: 5
- Terminal Type: PIN
- UPC: 00072845130617
- Voltage: 12V
- Weight (lbs): 3.88
- Wire Harness Included: No
- Part Description: 1993 Dodge Dakota Fuel Pump Module Assembly
Vehicle Fitment- 1993 Dodge Dakota | All Trims | 4 Cyl 2.5L
- 1993 Dodge Dakota | All Trims | 6 Cyl 3.9L
- 1993 Dodge Dakota | All Trims | 8 Cyl 5.2L
Product Specifications- Connector Color: White
- Connector Gender: Female
- Connector Shape: Square
- Gasket or Seal Included: Yes
- Height: 415
- Housing Length: 255
- Housing Material: Plastic
- Housing Width: 120
- Inlet Type: Filter
- Length: 220
- Lock Ring Included: No
- Maximum Flow Rating: 42.27
- Maximum Pressure: 110
- Outlet Diameter: 3/8 In.; 5/16 In.
- Outlet Quantity: 2
- Outlet Type: Male Quick Connect
- Package Contents: 1 Fuel Pump Module Assembly
- Terminal Gender: Male
- Terminal Quantity: 4
- Terminal Type: Spade
- Top Mount Diameter: 147.5
- Universal Or Specific Fit: Specific
- UPC: 747214016426
- Width: 147.5
- Wire Gauge Measurement: 15; 17
- Wire Quantity: 5
- Part Description: 1993 Dodge Dakota Fuel Tank Sending Unit
Vehicle Fitment- 1993 Dodge Dakota | All Trims | All Engines
Product Specifications- Other Names: Fuel Pump
- Part Description: 1993 Dodge Dakota PUMP & LEVEL UNIT (SERVICE
Vehicle Fitment- 1993 Dodge Dakota | Base, LE, S, SE, Sport | 4 Cyl 2.5 L GAS, 6 Cyl 3.9 L GAS, 8 Cyl 5.2 L GAS
Product Specifications- Notes: Module Assy
- Gaskets Included: Yes
- Internet Product Code (IPC): CF27996D470
- Item Grade: Premium Replacement
- Item has MSDS (SDS): Y
- MFG Brand Name: DENSO Auto Parts
- MFG Model # (Series): 953-3069
- MFG Name: DENSO
- Package Contents: Fuel Pump Module
- Supplier Company Name: DENSO
- UPC: 042511204553
- Part Description: 1993 Dodge Dakota Fuel Pump Module Assembly
Vehicle Fitment- 1993 Dodge Dakota | All Trims | 4 Cyl 2.5L
- 1993 Dodge Dakota | All Trims | 6 Cyl 3.9L
- 1993 Dodge Dakota | All Trims | 8 Cyl 5.2L
Product Specifications- Notes: with 15 or 22 Gallon Tank
- Gasket or Seal Included: Yes
- Inlet Attachment: Inlet-Strainer
- Inlet Type: STRAINER
- Internal or External: Internal
- Internet Product Code (IPC): B7A21C37BAD
- Item Grade: STANDARD REPLACEMENT
- Item has MSDS (SDS): No
- Maximum Pressure (psi): 80
- MFG Brand Name: Airtex Products
- MFG Model # (Series): E7050M
- Minimum Pressure (psi): 40.0
- Outlet Attachment: Outlet-QuickConnect
- Outlet Size: 3/8
- Outlet Type: QUICK CONNECT, RETURN LINE
- Package Contents: Fuel Pump Module Assembly
- Package Quantity: 1
- Pump Type: Electrical
- Supplier Company Name: Airtex Products
- UPC: 080044137214
- Voltage [V]: 12V
- Wiring Harness Included: No
- Part Description: 1993 Dodge Dakota In-Tank Fuel Pump Module Assembly
Vehicle Fitment- 1993 Dodge Dakota | All Trims | 4 Cyl 2.5L
- 1993 Dodge Dakota | All Trims | 6 Cyl 3.9L
- 1993 Dodge Dakota | All Trims | 8 Cyl 5.2L
Product Specifications- Notes: Sell out reorder 953-3069
- Gaskets Included: Yes
- Internet Product Code (IPC): 77868BA2F91
- Item Grade: Premium Replacement
- Item has MSDS (SDS): Y
- Meets or Exceeds Original Equipment Manufacture Specifications: YES
- MFG Brand Name: DENSO Auto Parts
- MFG Model # (Series): 953-6000
- MFG Name: DENSO
- Package Contents: Fuel Pump Module
- Seal And Lock Ring Included: NO
- Supplier Company Name: DENSO
- Universal Or Specific Fit: Specific
- UPC: 042511159600
- Part Description: 1993 Dodge Dakota Fuel Pump Module Assembly
Vehicle Fitment- 1993 Dodge Dakota | All Trims | 4 Cyl 2.5L
- 1993 Dodge Dakota | All Trims | 6 Cyl 3.9L
- 1993 Dodge Dakota | All Trims | 8 Cyl 5.2L
