1996 GMC Jimmy Fuel Pump
My Vehicle Change Vehicle
1996 GMC Jimmy
< Back to View All
Fuel Systems
- Department
- Product Fit
- Brands
- Prices
Product Specifications- OE Part Number: 25163487
- UPC: 747214016457
- Part Description: 1996 GMC Jimmy Fuel Pump Module Assembly
Vehicle Fitment- 1996 GMC Jimmy | All Trims | All Engines
Product Specifications- Notes: Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
- Current Draw: 10
- Flow Rating: 18 gph
- Fuel Level Sender Assembly Included: Yes
- Fuel Type: Gas
- Gasket or Seal Included: Yes
- In Tank or External: In Tank
- Inlet Type: Strainer
- Internal or External Strainer: Internal
- Item Grade: Standard Replacement
- Maximum Pressure: 109.0 PSI
- Outlet Outside Diameter: 0.375''
- Outlet Quantity: 3
- Outlet Type: Quick Connect
- Pump Type: Electric
- Regulator Included: No
- Resistance Ohms Empty: 40.0
- Resistance Ohms Full: 250.0
- Strainer Included: Yes
- System Pressure: 62 psi
- Terminal Gender: Male
- Terminal Quantity: 4
- Terminal Type: Blade
- UPC: 689604059678
- Vapor Pressure Sensor: Yes
- Voltage: 13.0 VDC
- Part Description: 1996 GMC Jimmy Fuel Pump Module Assembly
Vehicle Fitment- 1996 GMC Jimmy | All Trims | 6 Cyl 4.3L
Product Specifications- Notes: Turbine Pump Technology; Includes Wiring Harness, Terminals & Tank Seal
- Gasket Included: Y
- Hazardous Material: No
- Inlet Count: 1
- Inlet Type: Strainer
- Item Grade: Standard Replacement
- Maximum Free Flow Rate (gph): 60
- Maximum Pressure Rate (psi): 95
- Minimum Free Flow Rate (gph): 50
- Minimum Pressure Rate (psi): 85
- Outlet Count: 1
- Outlet Size: 3/8"
- Outlet Type: Quick Connect
- Package Contents: Pump & Kit
- Package Quantity: 1
- UPC: 080044321231
- Warranty: Lifetime Limited Warranty
- Part Description: 1996 GMC Jimmy In-Tank Fuel Pump Module Assembly
Vehicle Fitment- 1996 GMC Jimmy | All Trims | 6 Cyl 4.3L
Product Specifications- Notes: with Turbine Pump Technology,2;Includes Tank Seal, Connectors, & Wire Harness,2
- Average Current Draw(A): 8.5
- Average Flow Rating(GPH): 41
- Connector Gender: Male
- Connector Quantity: 1
- Connector Shape: Rectangle
- Country of Orign: China
- Fuel Filter Included: No
- Fuel Sending Unit Included: Yes
- Fuel Tank Pressure Sensor Included: Yes
- Gasket or Seal Included: No
- Gasket Or Seal Material: NBR
- Grade Type: Regular
- Housing Material: POM
- In Tank or External: In Tank
- Inlet Size: 5/16
- Inlet Type: Quick Connect
- Installation Warnings: No
- Maximum Pump Pressure (PSI): 145
- Minimum Pump Pressure (PSI): 87
- Mounting Hardware Included: No
- Negative Ground: No
- Outlet Quantity: 1
- Outlet Type: Quick Connect
- Product Height (in): 6.3
- Product Length (in): 13.78
- Product Width (in): 7.95
- Pump Type: Turbine
- Regulator Included: No
- Resistance Ohms Empty: 1
- Resistance Ohms Full: 90
- Strainer Included: Yes
- Terminal Gender: Male
- Terminal Quantity: 4
- Terminal Type: PIN
- UPC: 00072845129307
- Voltage: 12V
- Weight (lbs): 2.24
- Wire Harness Included: Yes
- Part Description: 1996 GMC Jimmy Fuel Pump Module Assembly
Vehicle Fitment- 1996 GMC Jimmy | All Trims | 6 Cyl 4.3L
Product Specifications- Notes: Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
- Current Draw: 10
- Flow Rating: 18 gph
- Fuel Level Sender Assembly Included: Yes
- Fuel Type: Gas
- Gasket or Seal Included: Yes
- In Tank or External: In Tank
- Inlet Type: Strainer
- Internal or External Strainer: External
- Item Grade: Standard Replacement
- Maximum Pressure: 109.0 PSI
- Outlet Outside Diameter: 0.375''
- Outlet Quantity: 3
- Outlet Type: Quick Connect
- Pump Type: Electric
- Regulator Included: No
- Resistance Ohms Empty: 0.1
- Resistance Ohms Full: 90.0
- Strainer Included: Yes
- System Pressure: 62 psi
- Terminal Gender: Male
- Terminal Quantity: 4
- Terminal Type: Blade
- UPC: 689604059661
- Vapor Pressure Sensor: Yes
- Voltage: 13.0 VDC
- Part Description: 1996 GMC Jimmy Fuel Pump Module Assembly
Vehicle Fitment- 1996 GMC Jimmy | All Trims | 6 Cyl 4.3L
Product Specifications- Notes: with Turbine Pump Technology,4;Includes Tank Seal, Connectors, & Wire Harness,4
- Average Current Draw(A): 8.5
- Average Flow Rating(GPH): 41
- Connector Gender: Male
- Connector Quantity: 1
- Connector Shape: Rectangle
- Country of Orign: China
- Fuel Filter Included: No
- Fuel Sending Unit Included: Yes
- Fuel Tank Pressure Sensor Included: Yes
- Gasket or Seal Included: Yes
- Gasket Or Seal Material: NBR
- Grade Type: Regular
- Housing Material: POM
- In Tank or External: In Tank
- Inlet Size: 5/16
- Inlet Type: Quick Connect
- Installation Warnings: No
- Maximum Pump Pressure (PSI): 145
- Minimum Pump Pressure (PSI): 87
- Mounting Hardware Included: No
- Negative Ground: No
- Outlet Quantity: 1
- Outlet Type: Quick Connect
- Product Height (in): 6.12
- Product Length (in): 14.29
- Product Width (in): 8.15
- Pump Type: Turbine
- Regulator Included: No
- Resistance Ohms Empty: 2
- Resistance Ohms Full: 90
- Strainer Included: Yes
- Terminal Gender: Male
- Terminal Quantity: 4
- Terminal Type: PIN
- UPC: 00072845129369
- Voltage: 12V
- Weight (lbs): 2.26
- Wire Harness Included: Yes
- Part Description: 1996 GMC Jimmy Fuel Pump Module Assembly
Vehicle Fitment- 1996 GMC Jimmy | All Trims | 6 Cyl 4.3L
Product Specifications- Notes: Includes Two Tank Seals, Hose, Rubber Sleeve & Clamps
- Gasket Included: Y
- Hazardous Material: No
- Inlet Count: 1
- Inlet Type: Strainer
- Item Grade: Standard Replacement
- Maximum Free Flow Rate (gph): 60
- Maximum Pressure Rate (psi): 90
- Minimum Free Flow Rate (gph): 50
- Minimum Pressure Rate (psi): 80
- Outlet Count: 1
- Outlet Size: 5/16
- Outlet Type: Hose Connect
- Package Contents: Pump & Kit
- Package Quantity: 1
- Warranty: Lifetime Limited Warranty
- Part Description: 1996 GMC Jimmy In-Tank Electric Fuel Pump
Vehicle Fitment- 1996 GMC Jimmy | All Trims | 6 Cyl 4.3L
Product Specifications- Notes: S-Series; 4.3l; 4 Door, 1995-2000
- Other Names: Fuel Pump, Fuel Sender Unit, Sending Unit
- Item Dimensions: 21.3 x 8.0 x 5.8 inches
- Item Weight: 3.00 Pounds
- Replaces: 19179616, 25163487
- Part Description: 1996 GMC Jimmy Fuel Tank Fuel Pump Module Kit
Vehicle Fitment- 1996 GMC Jimmy | Base, SL, SLE, SLS, SLT | 6 Cyl 4.3 L GAS
Product Specifications- Notes: DENSO Solution Module Assy-Turbine Pump & Design Upgrade Over OE
- Gaskets Included: Yes
- Internet Product Code (IPC): F39717CC7B0
- Item Grade: Premium Replacement
- Item has MSDS (SDS): Y
- MFG Brand Name: DENSO Auto Parts
- MFG Model # (Series): 953-0006
- MFG Name: DENSO
- Package Contents: Fuel Pump Module
- Supplier Company Name: DENSO
- Universal Or Specific Fit: Specific
- UPC: 042511193246
- Part Description: 1996 GMC Jimmy Fuel Pump Module Assembly
Vehicle Fitment- 1996 GMC Jimmy | All Trims | 6 Cyl 4.3L
Product Specifications- Notes: Discontinued; 12V
- UPC: 760687051992
- Part Description: 1996 GMC Jimmy Fuel Pump
Vehicle Fitment- 1996 GMC Jimmy | All Trims | 6 Cyl 4.3L
Product Specifications- Notes: OE Replacement Module Assy
- Gaskets Included: Yes
- Internet Product Code (IPC): 2CA22921B64
- Item Grade: Premium Replacement
- Item has MSDS (SDS): Y
- MFG Brand Name: DENSO Auto Parts
- MFG Model # (Series): 953-5017
- MFG Name: DENSO
- Package Contents: Fuel Pump Module
- Supplier Company Name: DENSO
- Universal Or Specific Fit: Specific
- UPC: 042511163317
- Part Description: 1996 GMC Jimmy Fuel Pump Module Assembly
Vehicle Fitment- 1996 GMC Jimmy | All Trims | 6 Cyl 4.3L
Product Specifications- Notes: Sell out reorder 953-0006
- Gaskets Included: Yes
- Internet Product Code (IPC): D15507583E5
- Item Grade: Premium Replacement
- Item has MSDS (SDS): Y
- MFG Brand Name: DENSO Auto Parts
- MFG Model # (Series): 953-5018
- MFG Name: DENSO
- Package Contents: Fuel Pump Module
- Supplier Company Name: DENSO
- UPC: 042511163324
- Part Description: 1996 GMC Jimmy Fuel Pump Module Assembly
Vehicle Fitment- 1996 GMC Jimmy | All Trims | 6 Cyl 4.3L
Product Specifications- Notes: Turbine Pump Technology; Includes Wiring Harness, Terminals & Tank Seal
- Gasket or Seal Included: Yes
- Inlet Attachment: Inlet-Strainer
- Inlet Type: STRAINER
- Internal or External: Internal
- Internet Product Code (IPC): 7E1B3697C9C
- Item Grade: OEM Standard Part
- Item has MSDS (SDS): No
- Maximum Pressure (psi): 100
- MFG Brand Name: Airtex Products
- MFG Model # (Series): E3929M
- Minimum Pressure (psi): 90
- Outlet Attachment: Outlet-QuickConnect
- Outlet Size: Outlet - 3/8
- Outlet Type: QUICK CONNECT, RETURN LINE
- Package Contents: PUMP & KIT
- Package Quantity: 1
- Pump Type: Electrical
- Supplier Company Name: Airtex Products
- UPC: 080044321316
- Voltage [V]: 12V
- Wiring Harness Included: Yes
- Part Description: 1996 GMC Jimmy Electric Fuel Pump
Vehicle Fitment- 1996 GMC Jimmy | All Trims | 6 Cyl 4.3L
