1997 Pontiac Grand Prix Fuel Pump
My Vehicle Change Vehicle
1997 Pontiac Grand Prix
< Back to View All
Fuel Systems
- Department
- Product Fit
- Brands
- Prices
OEM (Genuine) 1997 Pontiac Grand Prix Fuel Pump
PartNumber: 19180105$265.70 MSRP:$483.11You Save: $217.41 (46%)Product Specifications- Notes: 3.1 Liter, 1st Design;3.1 Liter, 2nd Design;3.8 Liter Mfi, 1st Design;3.8 Liter Mfi, 2nd Design
- Other Names: Fuel Pump, Sending Unit
- Item Dimensions: 8.4 x 5.3 x 16.8 inches
- Item Weight: 3.30 Pounds
- Fitment Type: Direct Replacement
- Replaced by: 19331290
- Part Description: 1997 Pontiac Grand Prix Fuel Pump
Vehicle Fitment- 1997 Pontiac Grand Prix | GT, SE | 6 Cyl 3.1 L GAS, 6 Cyl 3.8 L GAS
Product Specifications- Notes: Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
- Current Draw: 7
- Flow Rating: 26 gph
- Fuel Level Sender Assembly Included: Yes
- Fuel Type: Gas
- Gasket or Seal Included: Yes
- In Tank or External: In Tank
- Inlet Type: Strainer
- Internal or External Strainer: Internal
- Item Grade: Standard Replacement
- Maximum Pressure: 109.0 PSI
- Outlet Outside Diameter: 0.375''
- Outlet Quantity: 3
- Outlet Type: Quick Connect
- Pump Type: Electric
- Regulator Included: No
- Resistance Ohms Empty: 0.1
- Resistance Ohms Full: 90.0
- Strainer Included: Yes
- System Pressure: 62 psi
- Terminal Gender: Male
- Terminal Quantity: 4
- Terminal Type: Pin
- UPC: 689604060124
- Vapor Pressure Sensor: No
- Voltage: 12.0 VDC
- Part Description: 1997 Pontiac Grand Prix Fuel Pump Module Assembly
Vehicle Fitment- 1997 Pontiac Grand Prix | GTP | 6 Cyl 3.8L
Product Specifications- Notes: includes Tank Seal, Connectors & Wire Harness;Includes Tank Seal, Connectors, & Wire Harness
- Average Current Draw(A): 8.5
- Average Flow Rating(GPH): 41
- Connector Gender: Male
- Connector Quantity: 1
- Connector Shape: Rectangle
- Country of Orign: China
- Fuel Filter Included: No
- Fuel Sending Unit Included: Yes
- Fuel Tank Pressure Sensor Included: No
- Gasket or Seal Included: Yes
- Gasket Or Seal Material: NBR
- Grade Type: Regular
- Housing Material: POM
- In Tank or External: In Tank
- Inlet Size: 5/16
- Inlet Type: Quick Connect
- Installation Warnings: No
- Maximum Pump Pressure (PSI): 108.75
- Minimum Pump Pressure (PSI): 79.75
- Mounting Hardware Included: No
- Negative Ground: No
- Outlet Quantity: 1
- Outlet Type: Quick Connect
- Product Height (in): 6.42
- Product Length (in): 12.6
- Product Width (in): 7.09
- Pump Type: Turbine
- Regulator Included: No
- Resistance Ohms Empty: 2
- Resistance Ohms Full: 90
- Strainer Included: Yes
- Terminal Gender: Male
- Terminal Quantity: 4
- Terminal Type: PIN
- UPC: 00072845129406
- Voltage: 12V
- Weight (lbs): 2.18
- Wire Harness Included: Yes
- Part Description: 1997 Pontiac Grand Prix Fuel Pump Module Assembly
Vehicle Fitment- 1997 Pontiac Grand Prix | All Trims | 6 Cyl 3.1L
- 1997 Pontiac Grand Prix | All Trims | 6 Cyl 3.8L
Product Specifications- Notes: Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
- Current Draw: 8
- Flow Rating: 17 gph
- Fuel Level Sender Assembly Included: Yes
- Fuel Type: Gas
- Gasket or Seal Included: Yes
- In Tank or External: In Tank
- Inlet Type: Strainer
- Internal or External Strainer: External
- Item Grade: Standard Replacement
- Maximum Pressure: 109.0 PSI
- Outlet Outside Diameter: 0.375''
- Outlet Quantity: 3
- Outlet Type: Quick Connect
- Pump Type: Electric
- Regulator Included: No
- Resistance Ohms Empty: 0.1
- Resistance Ohms Full: 90.0
- Strainer Included: Yes
- System Pressure: 54 psi
- Terminal Gender: Male
- Terminal Quantity: 4
- Terminal Type: Pin
- UPC: 689604060117
- Vapor Pressure Sensor: No
- Voltage: 12.0 VDC
- Part Description: 1997 Pontiac Grand Prix Fuel Pump Module Assembly
Vehicle Fitment- 1997 Pontiac Grand Prix | SE | 6 Cyl 3.1L
- 1997 Pontiac Grand Prix | GT | 6 Cyl 3.8L
- 1997 Pontiac Grand Prix | SE | 6 Cyl 3.8L
Product Specifications- Average Current Draw(A): 8.5
- Average Flow Rating(GPH): 41
- Connector Gender: Male
- Connector Quantity: 1
- Connector Shape: Rectangle
- Country of Orign: China
- Fuel Filter Included: No
- Fuel Sending Unit Included: Yes
- Fuel Tank Pressure Sensor Included: No
- Gasket or Seal Included: Yes
- Gasket Or Seal Material: NBR
- Grade Type: Regular
- Housing Material: POM
- In Tank or External: In Tank
- Inlet Size: 5/16
- Inlet Type: Quick Connect
- Installation Warnings: No
- Maximum Pump Pressure (PSI): 145
- Minimum Pump Pressure (PSI): 87
- Mounting Hardware Included: No
- Negative Ground: No
- Outlet Quantity: 1
- Outlet Type: Quick Connect
- Product Height (in): 6.42
- Product Length (in): 12.6
- Product Width (in): 7.09
- Pump Type: Turbine
- Regulator Included: No
- Resistance Ohms Empty: 2
- Resistance Ohms Full: 90
- Strainer Included: Yes
- Terminal Gender: Male
- Terminal Quantity: 4
- Terminal Type: PIN
- UPC: 00072845129802
- Voltage: 12V
- Weight (lbs): 2.18
- Wire Harness Included: Yes
- Part Description: 1997 Pontiac Grand Prix Fuel Pump Module Assembly
Vehicle Fitment- 1997 Pontiac Grand Prix | All Trims | 6 Cyl 3.8L
Product Specifications- Notes: with Tag Code Marked WFA,Chevrolet;with Tag Code Marked WFA,Chevrolet
- Average Current Draw(A): 7
- Average Flow Rating(GPH): 33
- Connector Gender: Male
- Connector Quantity: 1
- Connector Shape: Rectangle
- Country of Orign: China
- Fuel Filter Included: No
- Fuel Sending Unit Included: Yes
- Fuel Tank Pressure Sensor Included: No
- Gasket or Seal Included: Yes
- Gasket Or Seal Material: NBR
- Grade Type: Regular
- Housing Material: POM
- In Tank or External: In Tank
- Inlet Size: 5/16
- Inlet Type: Quick Connect
- Installation Warnings: No
- Maximum Pump Pressure (PSI): 108.75
- Minimum Pump Pressure (PSI): 79.75
- Mounting Hardware Included: No
- Negative Ground: No
- Outlet Quantity: 1
- Outlet Type: Quick Connect
- Product Height (in): 6.42
- Product Length (in): 12.99
- Product Width (in): 7.09
- Pump Type: Turbine
- Regulator Included: No
- Resistance Ohms Empty: 2
- Resistance Ohms Full: 90
- Strainer Included: Yes
- Terminal Gender: Male
- Terminal Quantity: 4
- Terminal Type: PIN
- UPC: 00072845129895
- Voltage: 12V
- Weight (lbs): 2.56
- Wire Harness Included: Yes
- Part Description: 1997 Pontiac Grand Prix Fuel Pump Module Assembly
Vehicle Fitment- 1997 Pontiac Grand Prix | All Trims | 6 Cyl 3.1L
Product Specifications- Notes: OE Replacement Module Assy
- Gaskets Included: Yes
- Internet Product Code (IPC): 2D13AD667E1
- Item Grade: Premium Replacement
- Item has MSDS (SDS): Y
- MFG Brand Name: DENSO Auto Parts
- MFG Model # (Series): 953-5037
- MFG Name: DENSO
- Package Contents: Fuel Pump Module
- Supplier Company Name: DENSO
- Universal Or Specific Fit: Specific
- UPC: 042511163515
- Part Description: 1997 Pontiac Grand Prix Fuel Pump Module Assembly
Vehicle Fitment- 1997 Pontiac Grand Prix | All Trims | 6 Cyl 3.1L
- 1997 Pontiac Grand Prix | All Trims | 6 Cyl 3.8L
Product Specifications- Notes: Includes Wiring Harness, Terminals & Tank Seal
- Fuel Pump Maximum Free Flow Rate: 65
- Fuel Pump Maximum Pressure Range: 100
- Fuel Pump Minimum Free Flow Rate: 50
- Fuel Pump Minimum Pressure Range: 70
- Gasket or Seal Included: Yes
- Inlet Attachment: Inlet-Strainer
- Inlet Count: 1
- Inlet Type: STRAINER
- Internal or External: Internal
- Internet Product Code (IPC): 8C7CBA96815
- Item Grade: OEM Standard
- Item has MSDS: No
- Maximum Free Flow Rate (gph): 70
- Maximum Pressure (psi): 105
- MFG Brand Name: Airtex Products
- MFG Model # (Series): E3939M
- Minimum Free Flow Rate (gph): 50
- Minimum Pressure (psi): 60.0
- Outlet Attachment: Outlet-Quick Connect
- Outlet Count: 1
- Outlet Size: 3/8
- Outlet Type: QUICK CONNECT, RETURN LINE
- Package Contents: Fuel Pump Module Assembly
- Package Quantity: 1
- Pump Type: Electrical
- Supplier Company Name: Airtex Products
- UPC: 080044398899
- Voltage [V]: 12V
- Wiring Harness Included: No
- Part Description: 1997 Pontiac Grand Prix Fuel Pump Module Assembly
Vehicle Fitment- 1997 Pontiac Grand Prix | All Trims | 6 Cyl 3.8L
Product Specifications- Notes: Discontinued; From Chassis# 238198; 12V
- UPC: 760687049128
- Part Description: 1997 Pontiac Grand Prix Fuel Pump
Vehicle Fitment- 1997 Pontiac Grand Prix | All Trims | 6 Cyl 3.1L
- Product Specifications
- Notes: 3.8 Supercharged, 1st Design;3.8 Supercharged, 2nd Design
- Other Names: Fuel Pump, Sending Unit
- Item Dimensions: 16.1 x 8.1 x 5.6 inches
- Item Weight: 2.60 Pounds
- Replaces: 25179345, 25166710
- Part Description: 1997 Pontiac Grand Prix Fuel Tank Fuel Pump Module Kit
Vehicle Fitment- 1997 Pontiac Grand Prix | GTP | 6 Cyl 3.8 L GAS
Product Specifications- Notes: OE Replacement Module Assy
- Gaskets Included: Yes
- Internet Product Code (IPC): 1969639FA23
- Item Grade: Premium Replacement
- Item has MSDS (SDS): Y
- MFG Brand Name: DENSO Auto Parts
- MFG Model # (Series): 953-5038
- MFG Name: DENSO
- Package Contents: Fuel Pump Module
- Supplier Company Name: DENSO
- Universal Or Specific Fit: Specific
- UPC: 042511163522
- Part Description: 1997 Pontiac Grand Prix Fuel Pump Module Assembly
Vehicle Fitment- 1997 Pontiac Grand Prix | All Trims | 6 Cyl 3.8L
Product Specifications- Gasket or Seal Included: Yes
- Inlet Attachment: Inlet-Strainer
- Inlet Type: STRAINER
- Internal or External: Internal
- Internet Product Code (IPC): 7BB896EBF91
- Item Grade: OEM Standard Part
- Item has MSDS (SDS): No
- Maximum Pressure (psi): 100
- MFG Brand Name: Airtex Products
- MFG Model # (Series): E3978M
- Minimum Pressure (psi): 80
- Outlet Attachment: Outlet-QuickConnect
- Outlet Size: 3/8
- Outlet Type: QUICK CONNECT, RETURN LINE
- Package Contents: Fuel Pump Module Assembly
- Package Quantity: 1
- Pump Type: Electrical
- Supplier Company Name: Airtex Products
- UPC: 080044516460
- Voltage [V]: 12V
- Wiring Harness Included: No
- Part Description: 1997 Pontiac Grand Prix In-Tank Fuel Pump Module Assembly
Vehicle Fitment- 1997 Pontiac Grand Prix | All Trims | 6 Cyl 3.1L
Product Specifications- Notes: Discontinued; To Chassis# 238198; 12V
- UPC: 760687049135
- Part Description: 1997 Pontiac Grand Prix Fuel Pump
Vehicle Fitment- 1997 Pontiac Grand Prix | All Trims | 6 Cyl 3.1L
