2000 Cadillac Escalade Fuel Pump
My Vehicle Change Vehicle
2000 Cadillac Escalade
< Back to View All
Fuel Systems
- Department
- Product Fit
- Brands
- Prices
OEM (Genuine) 2000 Cadillac Escalade Fuel Pump
PartNumber: 15754298$158.65 MSRP:$299.38You Save: $140.73 (48%)Product Specifications- Notes: All Models
- Item Dimensions: 7.0 x 4.3 x 3.3 inches
- Item Weight: 1.30 Pounds
- Fitment Type: Direct Replacement
- Replaces: 15018546
- Part Description: Fuel Pump
Product Specifications- Notes: w/Harness Code (GFU); wo/RPO Code K53 (Robust Fuel System Fuel Sender Assy)
- Connector Color: White
- Connector Gender: Female
- Connector Shape: Flat Plug
- Height: 270 mm
- Housing Length: 184 mm
- Housing Material: Plastic (Polybutylene Terephthalate)
- Housing Width: 94 mm
- Inlet Diameter: 7.89 mm
- Inlet Type: Male
- Length: 19.5 mm
- Lock Ring Included: No
- Maximum Flow Rating: 117 LPH
- Maximum Pressure: 0.8 MPA
- OE Part Number: 19179597, 25314022, 25314327, 25314329
- Outlet Diameter: 9.49 mm
- Outlet Quantity: 1
- Outlet Type: Male
- Seal Included: Yes
- Terminal Gender: Male Female
- Terminal Quantity: 4
- Terminal Type: Spade
- Top Mount Diameter: 6.35 mm
- Universal Or Specific Fit: Specific
- UPC: 747214016419
- Width: 6.35 mm
- Wire Gauge Measurement: 1.5 AWG
- Wire Quantity: 4
- Part Description: Fuel Tank Sending Unit
Product Specifications- Notes: Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
- Current Draw: 10
- Flow Rating: 32 gph
- Fuel Level Sender Assembly Included: Yes
- Fuel Type: Gas
- Gasket or Seal Included: Yes
- In Tank or External: In Tank
- Inlet Type: Strainer
- Internal or External Strainer: External
- Item Grade: Standard Replacement
- Maximum Pressure: 109.0 PSI
- Outlet Outside Diameter: 0.375''
- Outlet Quantity: 2
- Outlet Type: Quick Connect
- Pump Type: Electric
- Regulator Included: No
- Resistance Ohms Empty: 40.0
- Resistance Ohms Full: 250.0
- Strainer Included: Yes
- System Pressure: 62 psi
- Terminal Gender: Male
- Terminal Quantity: 4
- Terminal Type: Blade
- UPC: 689604060261
- Vapor Pressure Sensor: No
- Voltage: 13.0 VDC
- Part Description: Fuel Pump Module Assembly
Product Specifications- Notes: with Turbine Pump Technology,4WD;Includes Tank Seal, Connectors, & Wire Harness,4WD
- Average Current Draw(A): 7.5
- Average Flow Rating(GPH): 38
- Connector Gender: Male
- Connector Quantity: 1
- Connector Shape: Rectangle
- Country of Orign: China
- Fuel Filter Included: No
- Fuel Sending Unit Included: Yes
- Fuel Tank Pressure Sensor Included: No
- Gasket or Seal Included: Yes
- Gasket Or Seal Material: NBR
- Grade Type: Performance
- Housing Material: POM
- In Tank or External: In Tank
- Inlet Size: 0.433
- Inlet Type: Strainer
- Installation Warnings: No
- Internal Or External Strainer: External and Internal
- Maximum Pump Pressure (PSI): 145
- Minimum Pump Pressure (PSI): 87
- Mounting Hardware Included: No
- Negative Ground: No
- Outlet Quantity: 1
- Outlet Type: Quick Connect
- Product Height (in): 6.1
- Product Length (in): 11.97
- Product Width (in): 6.69
- Pump Type: Turbine
- Regulator Included: No
- Resistance Ohms Empty: 40
- Resistance Ohms Full: 250
- Strainer Included: Yes
- Terminal Gender: Male
- Terminal Quantity: 4
- Terminal Type: PIN
- UPC: 00072845129833
- Voltage: 12V
- Weight (lbs): 2.4
- Wire Harness Included: No
- Part Description: Fuel Pump Module Assembly
OEM (Genuine) 2000 Cadillac Escalade Gauge
PartNumber: 19331243$279.86 MSRP:$528.04You Save: $248.18 (48%)Product Specifications- Other Names: Fuel Pump, Gauge
- Item Dimensions: 20.4 x 12.1 x 10.6 inches
- Item Weight: 3.60 Pounds
- Fitment Type: Direct Replacement
- Replaced by: 19369887
- Part Description: Gauge
Product Specifications- Notes: Turbine Pump Technology; Includes Wiring Harness, Terminals & Tank Seal
- Gasket Included: Y
- Hazardous Material: No
- Inlet Count: 1
- Inlet Type: Strainer
- Item Grade: Standard Replacement
- Maximum Free Flow Rate (gph): 60
- Maximum Pressure Rate (psi): 100
- Minimum Free Flow Rate (gph): 50
- Minimum Pressure Rate (psi): 80
- Outlet Count: 1
- Outlet Size: 3/8"
- Outlet Type: Quick Connect
- Package Contents: Pump & Kit
- Package Quantity: 1
- UPC: 080044516347
- Warranty: Lifetime Limited Warranty
- Part Description: In-Tank Fuel Pump Module Assembly
Product Specifications- Notes: DENSO Solution Module Assy-Turbine Pump & Design Upgrade Over OE
- Gaskets Included: Yes
- Internet Product Code (IPC): D98015AA12F
- Item Grade: Premium Replacement
- Item has MSDS (SDS): Y
- MFG Brand Name: DENSO Auto Parts
- MFG Model # (Series): 953-0019
- MFG Name: DENSO
- Package Contents: Fuel Pump Module
- Supplier Company Name: DENSO
- Universal Or Specific Fit: Specific
- UPC: 042511193376
- Part Description: Fuel Pump Module
Product Specifications- Notes: Sell Out Reorder 953-0019
- Gaskets Included: Yes
- Internet Product Code (IPC): C6FDA0B93B3
- Item Grade: Premium Replacement
- Item has MSDS (SDS): Y
- MFG Brand Name: DENSO Auto Parts
- MFG Model # (Series): 953-5046
- MFG Name: DENSO
- Package Contents: Fuel Pump Module
- Supplier Company Name: DENSO
- UPC: 042511163607
- Part Description: Fuel Pump Module Assembly
