2000 Chevrolet Lumina Fuel Pump
My Vehicle Change Vehicle
2000 Chevrolet Lumina
< Back to View All
Fuel Systems
- Department
- Product Fit
- Brands
- Prices
$102.56Product Specifications- Notes: Includes Wire Harness
- Average Current Draw(A): 8.5
- Average Flow Rating(GPH): 41
- Connector Gender: Female
- Connector Quantity: 1
- Connector Shape: Rectangle
- Country of Orign: China
- Fuel Filter Included: No
- Fuel Sending Unit Included: Yes
- Fuel Tank Pressure Sensor Included: Yes
- Gasket or Seal Included: Yes
- Gasket Or Seal Material: NBR
- Grade Type: Regular
- Housing Material: POM
- In Tank or External: In Tank
- Inlet Size: 5/16
- Inlet Type: Quick Connect
- Installation Warnings: No
- Maximum Pump Pressure (PSI): 145
- Minimum Pump Pressure (PSI): 87
- Mounting Hardware Included: No
- Negative Ground: No
- Outlet Quantity: 1
- Outlet Type: Quick Connect
- Product Height (in): 6
- Product Length (in): 17
- Product Width (in): 13
- Pump Type: Turbine
- Regulator Included: No
- Resistance Ohms Empty: 40
- Resistance Ohms Full: 250
- Strainer Included: Yes
- Terminal Gender: Female
- Terminal Quantity: 6
- Terminal Type: PIN
- UPC: 00072845125309
- Voltage: 12V
- Weight (lbs): 3.25
- Wire Harness Included: No
- Part Description: Fuel Pump Module Assembly
$100.23Product Specifications- Average Current Draw(A): 8.5
- Average Flow Rating(GPH): 41
- Connector Gender: Female
- Connector Quantity: 1
- Connector Shape: Rectangle
- Country of Orign: China
- Fuel Filter Included: No
- Fuel Sending Unit Included: Yes
- Fuel Tank Pressure Sensor Included: Yes
- Gasket or Seal Included: Yes
- Gasket Or Seal Material: NBR
- Grade Type: Regular
- Housing Material: POM
- In Tank or External: In Tank
- Inlet Size: 5/16
- Inlet Type: Quick Connect
- Installation Warnings: No
- Maximum Pump Pressure (PSI): 108.8
- Minimum Pump Pressure (PSI): 79.8
- Mounting Hardware Included: No
- Negative Ground: No
- Outlet Quantity: 1
- Outlet Type: Quick Connect
- Product Height (in): 9
- Product Length (in): 22
- Product Width (in): 12
- Pump Type: Turbine
- Regulator Included: No
- Resistance Ohms Empty: 40
- Resistance Ohms Full: 250
- Strainer Included: Yes
- Terminal Gender: Female
- Terminal Quantity: 6
- Terminal Type: PIN
- UPC: 00072845125255
- Voltage: 12V
- Weight (lbs): 3.25
- Wire Harness Included: No
- Part Description: Fuel Pump Module Assembly
Product Specifications- Notes: Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
- Current Draw: 7
- Flow Rating: 17 gph
- Fuel Level Sender Assembly Included: Yes
- Fuel Type: Gas
- Gasket or Seal Included: Yes
- In Tank or External: In Tank
- Inlet Type: Strainer
- Internal or External Strainer: External
- Item Grade: Standard Replacement
- Maximum Pressure: 109.0 PSI
- Outlet Outside Diameter: 0.375''
- Outlet Quantity: 3
- Outlet Type: Female Quick Connect
- Pump Type: Electric
- Regulator Included: No
- Resistance Ohms Empty: 40.0
- Resistance Ohms Full: 250.0
- Strainer Included: Yes
- System Pressure: 52 psi
- Terminal Gender: Male
- Terminal Quantity: 6
- Terminal Type: Pin
- UPC: 689604060810
- Vapor Pressure Sensor: Yes
- Voltage: 13.0 VDC
- Part Description: Fuel Pump Module Assembly
Product Specifications- Notes: OE Replacement Module Assy
- Gaskets Included: Yes
- Internet Product Code (IPC): 55CD68CC170
- Item Grade: Premium Replacement
- Item has MSDS (SDS): Y
- MFG Brand Name: DENSO Auto Parts
- MFG Model # (Series): 953-5075
- MFG Name: DENSO
- Package Contents: Fuel Pump Module
- Supplier Company Name: DENSO
- Universal Or Specific Fit: Specific
- UPC: 042511163898
- Part Description: Fuel Pump Module Assembly
Product Specifications- Notes: Includes Wiring Harness
- Gasket or Seal Included: Yes
- Inlet Attachment: Inlet-Strainer
- Inlet Type: STRAINER
- Internal or External: Internal
- Internet Product Code (IPC): E66DB45EEDD
- Item Grade: OEM Standard Part
- Item has MSDS (SDS): No
- Maximum Free Flow Rate (gph): 75
- Maximum Pressure (psi): 90
- MFG Brand Name: Airtex Products
- MFG Model # (Series): E3529M
- Minimum Free Flow Rate (gph): 40
- Minimum Pressure (psi): 80
- Outlet Attachment: Outlet-QuickConnect
- Outlet Size: Outlet - 3/8
- Outlet Type: QUICK CONNECT
- Package Contents: PUMP & KIT
- Package Quantity: 1
- Pump Type: Electrical
- Supplier Company Name: Airtex Products
- UPC: 080044515685
- Voltage [V]: 12V
- Wiring Harness Included: Yes
- Part Description: Electric Fuel Pump
Product Specifications- Notes: 1997-01, 3.1 Liter
- Other Names: Fuel Pump, Fuel Sender Unit
- Item Dimensions: 27.5 x 12.4 x 12.5 inches
- Item Weight: 5.10 Pounds
- Replaces: 25322662, 25326603
- Part Description: Module Kit, Fuel Tank Fuel Pump
