OEM (Genuine) 2000 Oldsmobile Bravada Module
PartNumber: 19331269
Product Specifications- Notes: 4 Door, 1995-2000; S-Series; 4.3L; Blazer/Jimmy/Bravada; 4 Door
- Other Names: Fuel Pump, Module
- Item Dimensions: 16.5 x 8.3 x 5.8 inches
- Item Weight: 2.80 Pounds
- Fitment Type: Direct Replacement
- Replaced by: 19369939
- Part Description: Module
$280.30 MSRP:$528.87You Save: $248.57 (48%)
Delphi® Fuel Pump Module Assembly for 2000 Oldsmobile Bravada
PartNumber: FG0287Product Specifications- Notes: with Plastic Tank;Updated design w/Check Valve. Can be used to replace fuel pump modules built w/or w/o check valve; To be used only when failed fuel module cover contains a 3-pin black pressure sensor; Original OE design had a 2x2 connector, OE design upgraded to a 1x4 connector; A 1x4 splice kit included for vehicles w/2x2 connector; Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
- Current Draw: 9
- Flow Rating: 24 gph
- Fuel Level Sender Assembly Included: Yes
- Fuel Type: Gas
- Gasket or Seal Included: Yes
- In Tank or External: In Tank
- Inlet Type: Strainer
- Internal or External Strainer: External
- Item Grade: Standard Replacement
- Maximum Pressure: 109.0 PSI
- Outlet Outside Diameter: 0.375''
- Outlet Quantity: 3
- Outlet Type: Quick Connect
- Pump Type: Electric
- Regulator Included: No
- Resistance Ohms Empty: 40.0
- Resistance Ohms Full: 250.0
- Strainer Included: Yes
- System Pressure: 62 psi
- Terminal Gender: Male
- Terminal Quantity: 4
- Terminal Type: Blade
- UPC: 689604082485
- Vapor Pressure Sensor: Yes
- Voltage: 12.0 VDC
- Part Description: Fuel Pump Module Assembly
$212.41
TYC® Fuel Pump Module Assembly for 2000 Oldsmobile Bravada
PartNumber: 150019-AProduct Specifications- Notes: Plastic Fuel Tank
- Accessories Included: yes
- Connector Pins Qty On Main Connector: 4PINS
- Fuel Level Sensor Resitance Range: 39-250
- Fuel Tube Connection Type: Quick Connect
- GPH (Gallons Per Hour Flow): 48.6-57.7
- Maximum Air Pressure: 79.75-123.25
- OE Part Number: 15207041
- Strainer Included: yes
- UPC: 762405824154
- Part Description: Fuel Pump Module Assembly
$84.39
Airtex® In-Tank Fuel Pump Module Assembly for 2000 Oldsmobile Bravada
PartNumber: E3992MProduct Specifications- Notes: with Harness;Includes Seal;Turbine Pump Technology
- Gasket Included: Y
- Hazardous Material: No
- Inlet Count: 1
- Inlet Type: Strainer
- Item Grade: Standard Replacement
- Maximum Free Flow Rate (gph): 55
- Maximum Pressure Rate (psi): 90
- Minimum Free Flow Rate (gph): 45
- Minimum Pressure Rate (psi): 70
- Outlet Count: 1
- Outlet Size: 3/8"
- Outlet Type: Quick Connect, Return Line
- Package Contents: Pump & Kit
- Package Quantity: 1
- UPC: 080044516569
- Warranty: Lifetime Limited Warranty
- Part Description: In-Tank Fuel Pump Module Assembly
$92.14
Autobest® Fuel Pump Module Assembly for 2000 Oldsmobile Bravada
PartNumber: F2903AProduct Specifications- Notes: Except Export;Includes Fuel Pump, Sending Unit, Float, Fuel Reservoir, Fuel Strainer, Upgraded Wiring Harness and Tank Seal
- Gasket or Seal Included: Yes
- Inlet Size: 0.362
- Inlet Type: Strainer
- Internal or External: Internal
- Maximum Free Flow (GPH): 71.5
- Maximum Pump Pressure (PSI): 145
- Minimum Free Flow (GPH): 60.7
- Minimum Pump Pressure (PSI): 87
- Outlet Size: 0.373
- Outlet Type: Quick Connect
- Pump Type: Turbine
- Regulator Included: No
- UPC: 072845129031
- Part Description: Fuel Pump Module Assembly
$60.38
Delphi® Fuel Pump Module Assembly for 2000 Oldsmobile Bravada
PartNumber: FG0052Product Specifications- Notes: with Plastic Tank;Original design w/o Check Valve. Must only be used to replace fuel pump modules built w/o check valve. If you are unsure if your module has a check valve, then use FG0287; Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
- Current Draw: 10
- Flow Rating: 18 gph
- Fuel Level Sender Assembly Included: Yes
- Fuel Type: Gas
- Gasket or Seal Included: Yes
- In Tank or External: In Tank
- Inlet Type: Strainer
- Internal or External Strainer: Internal
- Item Grade: Standard Replacement
- Maximum Pressure: 109.0 PSI
- Outlet Outside Diameter: 0.375''
- Outlet Quantity: 3
- Outlet Type: Quick Connect
- Pump Type: Electric
- Regulator Included: No
- Resistance Ohms Empty: 40.0
- Resistance Ohms Full: 250.0
- Strainer Included: Yes
- System Pressure: 62 psi
- Terminal Gender: Male
- Terminal Quantity: 4
- Terminal Type: Blade
- UPC: 689604059890
- Vapor Pressure Sensor: Yes
- Voltage: 13.0 VDC
- Part Description: Fuel Pump Module Assembly
$173.12
Denso® Fuel Pump Module Assembly for 2000 Oldsmobile Bravada
PartNumber: 953-0021Product Specifications- Notes: DENSO Solution Module Assy-Turbine Pump & Design Upgrade Over OE
- Gaskets Included: Yes
- Internet Product Code (IPC): 00821518BFA
- Item Grade: Premium Replacement
- Item has MSDS (SDS): Y
- MFG Brand Name: DENSO Auto Parts
- MFG Model # (Series): 953-0021
- MFG Name: DENSO
- Package Contents: Fuel Pump Module
- Supplier Company Name: DENSO
- Universal Or Specific Fit: Specific
- UPC: 042511193390
- Part Description: Fuel Pump Module Assembly
OEM (Genuine) 2000 Oldsmobile Bravada Module
PartNumber: 19369950
Product Specifications- Notes: S-Series; 4.3L; Blazer/Jimmy/Bravada; 2 Door
- Other Names: Fuel Pump, Module
- Fitment Type: Direct Replacement
- Replaces: 19331273, 25344816, 25178732, 25314775, 19177256, 25320511, 25168012
- Part Description: Module
Denso® Fuel Pump Module Assembly for 2000 Oldsmobile Bravada
PartNumber: 953-5032Product Specifications- Notes: Sell out reorder 953-0021
- Gaskets Included: Yes
- Internet Product Code (IPC): EC2F71E3408
- Item Grade: Premium Replacement
- Item has MSDS (SDS): Y
- MFG Brand Name: DENSO Auto Parts
- MFG Model # (Series): 953-5032
- MFG Name: DENSO
- Package Contents: Fuel Pump Module
- Supplier Company Name: DENSO
- UPC: 042511163461
- Part Description: Fuel Pump Module Assembly
Autobest® Fuel Pump Module Assembly for 2000 Oldsmobile Bravada
PartNumber: HP2903AProduct Specifications- Gasket or Seal Included: Yes
- Height (in.): 10.4
- Inlet Size: 0.362
- Inlet Type: Strainer
- Internal or External: Internal
- Length (in.): 13.6
- Life Cycle Status Code: Superseded
- Maximum Free Flow (GPH): 82.225
- Maximum Pump Pressure (PSI): 145
- Minimum Free Flow (GPH): 69.805
- Minimum Pump Pressure (PSI): 87
- Outlet Size: 0.374
- Outlet Type: Quick Connect
- Package Contents: Pump & Module
- Pump Type: Turbine
- Regulator Included: No
- Short Description: High Performance Fuel Pump
- Superseded To: F2903A
- UPC: 072845169037
- Weight (lbs.): 4
- Width (in.): 6.9
- Part Description: Fuel Pump Module Assembly
