2001 Chevrolet Camaro Fuel Pump
My Vehicle Change Vehicle
2001 Chevrolet Camaro
< Back to View All
Fuel Systems
- Department
- Product Fit
- Brands
- Prices
OEM (Genuine) 2001 Chevrolet Camaro Fuel Pump
PartNumber: 19331246$454.22 MSRP:$878.69You Save: $424.47 (49%)Product Specifications- Other Names: Fuel Pump, Sending Unit
- Item Dimensions: 8.3 x 5.2 x 17.0 inches
- Item Weight: 2.20 Pounds
- Fitment Type: Direct Replacement
- Replaced by: 19369891
- Part Description: 2001 Chevrolet Camaro Fuel Pump
Product Specifications- Connector Color: White
- Connector Gender: Female
- Connector Shape: Flat Plug
- Height: 230 mm
- Housing Length: 184 mm
- Housing Material: Plastic (Polybutylene Terephthalate)
- Housing Width: 94 mm
- Inlet Diameter: 9.49 mm
- Inlet Type: Male
- Length: 19.5 mm
- Lock Ring Included: No
- Maximum Flow Rating: 97 LPH
- Maximum Pressure: 0.8 MPA
- OE Part Number: 19177237, 25316320
- Outlet Diameter: 9.49 mm
- Outlet Quantity: 1
- Outlet Type: Male
- Seal Included: Yes
- Terminal Gender: Female
- Terminal Quantity: 4
- Terminal Type: Spade
- Top Mount Diameter: 6.35 mm
- Universal Or Specific Fit: Specific
- UPC: 747214154395
- Width: 6.35 mm
- Wire Gauge Measurement: 1.5 AWG
- Wire Quantity: 4
- Part Description: 2001 Chevrolet Camaro Fuel Tank Sending Unit
Vehicle Fitment- 2001 Chevrolet Camaro | All Trims | 6 Cyl 3.8L
Product Specifications- Notes: Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
- Current Draw: 10
- Flow Rating: 29 gph
- Fuel Level Sender Assembly Included: Yes
- Fuel Type: Gas
- Gasket or Seal Included: Yes
- In Tank or External: In Tank
- Inlet Type: Strainer
- Internal or External Strainer: Internal
- Item Grade: Standard Replacement
- Maximum Pressure: 109.0 PSI
- Outlet Outside Diameter: 0.375''
- Outlet Quantity: 3
- Outlet Type: Quick Connect
- Pump Type: Electric
- Regulator Included: Yes
- Resistance Ohms Empty: 40.0
- Resistance Ohms Full: 250.0
- Strainer Included: Yes
- System Pressure: 58 psi
- Terminal Gender: Male
- Terminal Quantity: 4
- Terminal Type: Blade
- UPC: 689604060919
- Vapor Pressure Sensor: Yes
- Voltage: 13.0 VDC
- Part Description: 2001 Chevrolet Camaro Fuel Pump Module Assembly
Vehicle Fitment- 2001 Chevrolet Camaro | Z28 | 8 Cyl 5.7L
- 2001 Chevrolet Camaro | Z28 SS | 8 Cyl 5.7L
Product Specifications- Average Current Draw(A): 8.5
- Average Flow Rating(GPH): 140
- Connector Gender: Male
- Connector Quantity: 1
- Connector Shape: Rectangle
- Country of Orign: China
- Fuel Filter Included: No
- Fuel Sending Unit Included: Yes
- Fuel Tank Pressure Sensor Included: Yes
- Gasket or Seal Included: Yes
- Gasket Or Seal Material: NBR
- Grade Type: Regular
- Housing Material: POM
- In Tank or External: In Tank
- Inlet Size: 3/8
- Inlet Type: Quick Connect
- Installation Warnings: No
- Maximum Pump Pressure (PSI): 58
- Minimum Pump Pressure (PSI): 52
- Mounting Hardware Included: No
- Negative Ground: No
- Outlet Quantity: 1
- Outlet Type: Quick Connect
- Product Height (in): 12
- Product Length (in): 7.7
- Product Width (in): 7.8
- Pump Type: Turbine
- Regulator Included: Yes
- Resistance Ohms Empty: 40
- Resistance Ohms Full: 250
- Strainer Included: Yes
- Terminal Gender: Male
- Terminal Quantity: 4
- Terminal Type: PIN
- UPC: 00072845123794
- Voltage: 12V
- Weight (lbs): 2.16
- Wire Harness Included: Yes
- Part Description: 2001 Chevrolet Camaro Fuel Pump Module Assembly
Vehicle Fitment- 2001 Chevrolet Camaro | All Trims | 8 Cyl 5.7L
Product Specifications- Notes: Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
- Current Draw: 7
- Flow Rating: 18 gph
- Fuel Level Sender Assembly Included: Yes
- Fuel Type: Gas
- Gasket or Seal Included: Yes
- In Tank or External: In Tank
- Inlet Type: Strainer
- Internal or External Strainer: Internal
- Item Grade: Standard Replacement
- Maximum Pressure: 109.0 PSI
- Outlet Outside Diameter: 0.375''
- Outlet Quantity: 3
- Outlet Type: Quick Connect
- Pump Type: Electric
- Regulator Included: No
- Resistance Ohms Empty: 40.0
- Resistance Ohms Full: 250.0
- Strainer Included: Yes
- System Pressure: 51 psi
- Terminal Gender: Male
- Terminal Quantity: 4
- Terminal Type: Blade
- UPC: 689604060391
- Vapor Pressure Sensor: Yes
- Voltage: 13.0 VDC
- Part Description: 2001 Chevrolet Camaro Fuel Pump Module Assembly
Vehicle Fitment- 2001 Chevrolet Camaro | Base | 6 Cyl 3.8L
Product Specifications- Average Current Draw(A): 8.5
- Average Flow Rating(GPH): 41
- Connector Gender: Male
- Connector Quantity: 1
- Connector Shape: Rectangle
- Country of Orign: China
- Fuel Filter Included: No
- Fuel Sending Unit Included: Yes
- Fuel Tank Pressure Sensor Included: Yes
- Gasket or Seal Included: Yes
- Gasket Or Seal Material: NBR
- Grade Type: Regular
- Housing Material: POM
- In Tank or External: In Tank
- Inlet Size: 3/8
- Inlet Type: Quick Connect
- Installation Warnings: No
- Maximum Pump Pressure (PSI): 145
- Minimum Pump Pressure (PSI): 87
- Mounting Hardware Included: No
- Negative Ground: No
- Outlet Quantity: 1
- Outlet Type: Quick Connect
- Product Height (in): 7.36
- Product Length (in): 11.81
- Product Width (in): 8.07
- Pump Type: Turbine
- Regulator Included: No
- Resistance Ohms Empty: 40
- Resistance Ohms Full: 250
- Strainer Included: Yes
- Terminal Gender: Male
- Terminal Quantity: 4
- Terminal Type: PIN
- UPC: 00072845123701
- Voltage: 12V
- Weight (lbs): 2.26
- Wire Harness Included: Yes
- Part Description: 2001 Chevrolet Camaro Fuel Pump Module Assembly
Vehicle Fitment- 2001 Chevrolet Camaro | All Trims | 6 Cyl 3.8L
OEM (Genuine) 2001 Chevrolet Camaro Fuel Pump
PartNumber: 19369884$356.61 MSRP:$691.97You Save: $335.36 (49%)Product Specifications- Notes: All Models; 3.8l; 3.8 Liter
- Other Names: Fuel Pump, Sending Unit
- Fitment Type: Direct Replacement
- Replaces: 19177237, 25316320, 19331241
- Part Description: 2001 Chevrolet Camaro Fuel Pump
Vehicle Fitment- 2001 Chevrolet Camaro | Base | 6 Cyl 3.8 L GAS
Autobest® High Performance Fuel Pump Module Assembly for 2001 Chevrolet Camaro
PartNumber: HP2379A$95.06Product Specifications- Average Current Draw(A): 8.5
- Average Flow Rating(GPH): 140
- Connector Gender: Male
- Connector Quantity: 1
- Connector Shape: Rectangle
- Country of Orign: China
- Fuel Filter Included: No
- Fuel Sending Unit Included: Yes
- Fuel Tank Pressure Sensor Included: Yes
- Gasket or Seal Included: Yes
- Gasket Or Seal Material: NBR
- Grade Type: Regular
- Housing Material: POM
- In Tank or External: In Tank
- Inlet Size: 0.362
- Inlet Type: Strainer
- Installation Warnings: No
- Maximum Pump Pressure (PSI): 58
- Minimum Pump Pressure (PSI): 52
- Mounting Hardware Included: No
- Negative Ground: No
- Outlet Quantity: 1
- Outlet Size: 0.374
- Outlet Type: Quick Connect
- Product Height (in): 12
- Product Length (in): 7.7
- Product Width (in): 7.8
- Pump Type: Turbine
- Regulator Included: No
- Resistance Ohms Empty: 40
- Resistance Ohms Full: 250
- Strainer Included: Yes
- Terminal Gender: Male
- Terminal Quantity: 4
- Terminal Type: PIN
- UPC: 00072845163790
- Voltage: 12V
- Weight (lbs): 2.16
- Wire Harness Included: Yes
- Part Description: 2001 Chevrolet Camaro High Performance Fuel Pump Module Assembly
Vehicle Fitment- 2001 Chevrolet Camaro | All Trims | 8 Cyl 5.7L
Product Specifications- Gasket Included: Y
- Hazardous Material: No
- Inlet Count: 1
- Inlet Type: Strainer
- Item Grade: Standard Replacement
- Maximum Free Flow Rate (gph): 50
- Maximum Pressure Rate (psi): 90
- Minimum Free Flow Rate (gph): 40
- Minimum Pressure Rate (psi): 70
- Outlet Count: 1
- Outlet Size: 3/8"
- Outlet Type: Quick Connect, Return Line
- Package Contents: Pump & Kit
- Package Quantity: 1
- Warranty: Lifetime Limited Warranty
- Part Description: 2001 Chevrolet Camaro In-Tank Fuel Pump Module Assembly
Vehicle Fitment- 2001 Chevrolet Camaro | All Trims | 6 Cyl 3.8L
Product Specifications- Notes: OE Replacement Module Assy
- Gaskets Included: Yes
- Internet Product Code (IPC): 3F55989547E
- Item Grade: Premium Replacement
- Item has MSDS (SDS): Y
- MFG Brand Name: DENSO Auto Parts
- MFG Model # (Series): 953-5058
- MFG Name: DENSO
- Package Contents: Fuel Pump Module
- Supplier Company Name: DENSO
- Universal Or Specific Fit: Specific
- UPC: 042511163720
- Part Description: 2001 Chevrolet Camaro Fuel Pump Module Assembly
Vehicle Fitment- 2001 Chevrolet Camaro | All Trims | 6 Cyl 3.8L
Product Specifications- Notes: OE Replacement Module Assy
- Gaskets Included: Yes
- Internet Product Code (IPC): 752D2D94DA0
- Item Grade: Premium Replacement
- Item has MSDS (SDS): Y
- MFG Brand Name: DENSO Auto Parts
- MFG Model # (Series): 953-5082
- MFG Name: DENSO
- Package Contents: Fuel Pump Module
- Supplier Company Name: DENSO
- Universal Or Specific Fit: Specific
- UPC: 042511163966
- Part Description: 2001 Chevrolet Camaro Fuel Pump Module Assembly
Vehicle Fitment- 2001 Chevrolet Camaro | All Trims | 8 Cyl 5.7L
Product Specifications- Gasket or Seal Included: Yes
- Inlet Attachment: Strainer
- Inlet Type: STRAINER
- Internal or External: Internal
- Internet Product Code (IPC): AE7673F901F
- Item Grade: OEM Standard
- Item has MSDS (SDS): No
- Maximum Pressure (psi): 105
- MFG Brand Name: Airtex Products
- MFG Model # (Series): E3368M
- Minimum Pressure (psi): 85
- Outlet Attachment: Quick Connect
- Outlet Count: 1
- Outlet Type: QUICK CONNECT, RETURN LINE
- Package Contents: PUMP & KIT
- Package Quantity: 1
- Pump Type: Electrical
- Supplier Company Name: Airtex Products
- UPC: 080044515395
- Voltage [V]: 12V
- Wiring Harness Included: Yes
- Part Description: 2001 Chevrolet Camaro In-Tank Fuel Pump Module Assembly
Vehicle Fitment- 2001 Chevrolet Camaro | All Trims | 8 Cyl 5.7L
Product Specifications- Part Description: 2001 Chevrolet Camaro Fuel Pump Module Assembly
