2002 Ford Explorer Sport Trac Fuel Pump
My Vehicle Change Vehicle
2002 Ford Explorer Sport Trac
< Back to View All
Fuel Systems
- Department
- Location
- Operation
- Product Fit
- Brands
- Prices
Product Specifications- Notes: To 03/04/02; DENSO Mfg. Replacement Fuel Pump & Strainer Kit;To 03/04/2002; DENSO Fuel Pump & Strainer Kit
- Fuel Pump Type: Electrical
- Pump Placement: In Tank
- Strainer Fitting Diameter: 0.43''
- Strainer Length: 159.0 mm
- Strainer Width: 94.00 mm
- UPC: 042511079953
- Part Description: Fuel Pump and Strainer Set
Product Specifications- Notes: To 03/04/2002;with 5 Pin Connector;Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
- Current Draw: 6
- Flow Rating: 21 gph
- Fuel Level Sender Assembly Included: Yes
- Fuel Type: Gas
- Gasket or Seal Included: Yes
- Inlet Type: Strainer
- Internal or External Strainer: External
- Item Grade: Standard Replacement
- Maximum Pressure: 80.0 PSI
- Outlet Outside Diameter: 0.375''
- Outlet Quantity: 2
- Outlet Type: Quick Connect
- Pump Location: In Tank
- Pump Type: Electric
- Resistance Ohms Empty: 160.0
- Resistance Ohms Full: 16.0
- Strainer Included: Yes
- System Pressure: 60 psi
- Terminal Gender: Male
- Terminal Quantity: 7
- Terminal Type: Pin
- UPC: 689604202906
- Voltage: 12.5 VDC
- Part Description: Fuel Pump And Sender Assembly
Product Specifications- Notes: From 3/4/02;with 4 Pin Connector
- Average Current Draw(A): 7
- Average Flow Rating(GPH): 34.4
- Connector Gender: Female
- Connector Quantity: 1
- Connector Shape: Round
- Country of Orign: China
- Fuel Filter Included: No
- Fuel Sending Unit Included: Yes
- Fuel Tank Pressure Sensor Included: No
- Gasket or Seal Included: Yes
- Gasket Or Seal Material: FKM
- Grade Type: Regular
- In Tank or External: In Tank
- Inlet Size: 0.433
- Inlet Type: Strainer
- Installation Warnings: No
- Internal Or External Strainer: Internal
- Maximum Pump Pressure (PSI): 63.8
- Minimum Pump Pressure (PSI): 58
- Mounting Hardware Included: No
- Negative Ground: No
- Outlet Quantity: 1
- Outlet Type: Quick Connect
- Product Height (in): 7.48
- Product Length (in): 12.28
- Product Width (in): 7.87
- Pump Type: Turbine
- Regulator Included: Yes
- Resistance Ohms Empty: 16
- Resistance Ohms Full: 161
- Strainer Included: Yes
- Terminal Gender: Male
- Terminal Quantity: 8
- Terminal Type: PIN
- UPC: 00072845113597
- Voltage: 12V
- Weight (lbs): 2.32
- Wire Harness Included: No
- Part Description: Fuel Pump Module Assembly
Product Specifications- Notes: To 03/04/2002; DENSO Fuel Pump
- Gasket or Seal Included: No
- Inlet Outside Diameter: 11 mm
- Internal or External: Internal
- Mounting Bracket Included: No
- Mounting Hardware Included: Yes
- Negative Ground: Yes
- New or Remanufactured: New
- Outlet Quantity: 1
- Regulator Included: No
- Seal And Lock Ring Included: No
- Strainer Included: No
- UPC: 042511072442
- Voltage: 12 VDC
- Part Description: Electric Fuel Pump
Product Specifications- Notes: with 4 Pin Connector;From 03/04/2002;Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
- Current Draw: 8
- Flow Rating: 45 gph
- Fuel Level Sender Assembly Included: Yes
- Fuel Type: Gas
- Gasket or Seal Included: Yes
- In Tank or External: In Tank
- Inlet Type: Strainer
- Internal or External Strainer: External
- Item Grade: Standard Replacement
- Maximum Pressure: 80.0 PSI
- Outlet Outside Diameter: 0.375''
- Outlet Quantity: 2
- Outlet Type: Quick Connect
- Pump Type: Electric
- Regulator Included: Yes
- Resistance Ohms Empty: 15.0
- Resistance Ohms Full: 160.0
- Strainer Included: Yes
- System Pressure: 58 psi
- Terminal Gender: Male
- Terminal Quantity: 4
- Terminal Type: Pin
- UPC: 689604232996
- Vapor Pressure Sensor: No
- Voltage: 12.0 VDC
- Part Description: Fuel Pump Module Assembly
Product Specifications- Notes: To 3/4/02;Includes Hose, Clamps, Wire Harness, & Tank Seals
- Average Current Draw(A): 5.5
- Average Flow Rating(GPH): 130
- Connector Gender: Male
- Connector Quantity: 1
- Connector Shape: Rectangle
- Country of Orign: China
- Gasket or Seal Included: No
- Grade Type: Performance
- In Tank or External: In Tank
- Inlet Size: 0.433
- Inlet Type: Filter
- Installation Warnings: No
- Internal Or External Strainer: External
- Maximum Pump Pressure (PSI): 130.5
- Minimum Pump Pressure (PSI): 87
- Outlet Quantity: 1
- Outlet Size: 0.36
- Outlet Type: Male tube / 1 barb
- Product Height (in): 1.5
- Product Length (in): 4.51
- Product Width (in): 1.5
- Pump Type: Turbine
- Regulator Included: No
- Terminal Gender: Male
- Terminal Quantity: 2
- Terminal Type: Inserts
- UPC: 00072845113443
- Voltage: 12V
- Weight (lbs): 0.77
- Part Description: In Tank Electric Fuel Pump
Product Specifications- Notes: To 03/04/2002;Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
- Current Draw: 8
- Flow Rating: 21 gph
- Fuel Type: Gas
- Gasket or Seal Included: Yes
- In Tank or External: In Tank
- Inlet Type: Strainer
- Item Grade: Standard Replacement
- Maximum Pressure: 80.0 PSI
- Outlet Outside Diameter: 0.375''
- Outlet Type: Hose
- Pump Type: Electric
- Strainer Included: No
- System Pressure: 51 psi
- Terminal Gender: Male
- Terminal Quantity: 2
- Terminal Type: Blade
- UPC: 689604035139
- Voltage: 12 VDC
- Wiring Harness Included: Yes
- Part Description: In Tank Electric Fuel Pump
Product Specifications- Notes: To 03/03/2002; Includes Hose, Clamps, Wiring Harness & Tank Seals
- Gasket Included: Y
- Hazardous Material: No
- Inlet Count: 1
- Inlet Type: Strainer
- Item Grade: Standard Replacement
- Maximum Free Flow Rate (gph): 55
- Maximum Pressure Rate (psi): 95
- Minimum Free Flow Rate (gph): 45
- Minimum Pressure Rate (psi): 80
- Outlet Count: 1
- Outlet Size: .345
- Outlet Type: Hose Connect
- Package Contents: Pump & Kit
- Package Quantity: 1
- UPC: 080044008651
- Warranty: Lifetime Limited Warranty
- Part Description: In-Tank Electric Fuel Pump
Product Specifications- Other Names: Fuel Gauge Sending Unit, Fuel Pump
- Item Dimensions: 16.3 x 8.0 x 9.2 inches
- Item Weight: 3.30 Pounds
- Replaces: PFS-422, XL2Z-9H307-AL, XL2Z-9H307-AK
- Part Description: Fuel Pump
Product Specifications- Notes: To 03/04/2002; 2 Tube Port
- Gasket or Seal Included: Yes
- Inlet Attachment: Inlet-Strainer
- Inlet Type: STRAINER
- Internal or External: Internal
- Internet Product Code (IPC): 3974AF2E34A
- Item Grade: STANDARD REPLACEMENT
- Item has MSDS (SDS): No
- Maximum Pressure (psi): 110
- MFG Brand Name: Airtex Products
- MFG Model # (Series): E2332S
- Minimum Pressure (psi): 90
- Outlet Attachment: Outlet-QuickConnect
- Outlet Size: 3/8
- Package Contents: Fuel Pump Assembly
- Package Quantity: 1
- Pump Type: Electrical
- Supplier Company Name: Airtex Products
- UPC: 080044538400
- Voltage [V]: 12V
- Wiring Harness Included: No
- Part Description: Fuel Pump and Sender Assembly
Product Specifications- Notes: From 03/04/2002; 4 Pin Connector
- Gasket Included: Y
- Hazardous Material: No
- Inlet Count: 1
- Inlet Type: Strainer
- Item Grade: Standard Replacement
- Maximum Free Flow Rate (gph): 55
- Maximum Pressure Rate (psi): 90
- Minimum Free Flow Rate (gph): 45
- Minimum Pressure Rate (psi): 75
- Outlet Count: 1
- Outlet Size: 3/8"
- Outlet Type: Quick Connect
- Package Contents: Pump & Kit
- Package Quantity: 1
- Warranty: Lifetime Limited Warranty
- Part Description: In-Tank Fuel Pump Module Assembly
Product Specifications- Notes: Metal Flange;2 Tube Port;with 2 Tube Ports
- Average Current Draw(A): 7.5
- Average Flow Rating(GPH): 48
- Connector Gender: MaleFemale
- Connector Quantity: 2
- Connector Shape: Rectangle+Round
- Country of Orign: China
- Fuel Filter Included: No
- Fuel Sending Unit Included: Yes
- Fuel Tank Pressure Sensor Included: No
- Gasket or Seal Included: Yes
- Gasket Or Seal Material: NBR
- Grade Type: Performance
- In Tank or External: In Tank
- Inlet Size: 0.433
- Inlet Type: Strainer
- Installation Warnings: No
- Internal Or External Strainer: External
- Maximum Pump Pressure (PSI): 110
- Minimum Pump Pressure (PSI): 90
- Mounting Hardware Included: No
- Negative Ground: No
- Outlet Quantity: 1
- Outlet Type: Quick Connect
- Product Height (in): 6.69
- Product Length (in): 12.99
- Product Width (in): 6.69
- Pump Type: Turbine
- Regulator Included: Yes
- Resistance Ohms Empty: 13
- Resistance Ohms Full: 160
- Strainer Included: Yes
- Terminal Gender: MaleFemale
- Terminal Quantity: 10
- Terminal Type: PIN
- UPC: 00072845113436
- Voltage: 12V
- Weight (lbs): 2.64
- Wire Harness Included: No
- Part Description: Electric Fuel Pump
Product Specifications- Notes: w/2 Tube Ports, Plastic Flange, 5 Pin Connector; FROM 3/4/2002; Incls Fuel Pump, Sending Unit, Float, Fuel Strainer & Tank Seal
- Gasket Included: Y
- Inlet Count: 1
- Inlet Type: STRAINER
- Item Grade: STANDARD REPLACEMENT
- Maximum Free Flow Rate (gph): 60
- Maximum Pressure Rate (psi): 100
- Minimum Free Flow Rate (gph): 50
- Minimum Pressure Rate (psi): 90
- Outlet Count: 1
- Outlet Size: 3/8
- Outlet Type: QUICK CONNECT
- Package Contents: PUMP & KIT
- Package Quantity: 1
- UPC: 080044023197
- Part Description: In-Tank Fuel Pump Module Assembly
Product Specifications- Notes: with 2 Tube Ports, Plastic Flange, 5 Pin Connector;Incls Fuel Pump, Sending Unit, Float, Fuel Strainer & Tank Seal
- Average Current Draw(A): 7.5
- Average Flow Rating(GPH): 39.7
- Connector Gender: Female
- Connector Quantity: 1
- Connector Shape: Round
- Country of Orign: China
- Fuel Filter Included: No
- Fuel Sending Unit Included: Yes
- Fuel Tank Pressure Sensor Included: No
- Gasket or Seal Included: Yes
- Gasket Or Seal Material: FKM
- Grade Type: Regular
- In Tank or External: In Tank
- Inlet Size: 0.433
- Inlet Type: Strainer
- Installation Warnings: No
- Internal Or External Strainer: Internal
- Maximum Pump Pressure (PSI): 100
- Minimum Pump Pressure (PSI): 90
- Mounting Hardware Included: No
- Negative Ground: No
- Outlet Quantity: 1
- Outlet Type: Quick Connect
- Product Height (in): 7.87
- Product Length (in): 12.83
- Product Width (in): 8.27
- Pump Type: Turbine
- Regulator Included: Yes
- Resistance Ohms Empty: 8
- Resistance Ohms Full: 142
- Strainer Included: Yes
- Terminal Gender: Male
- Terminal Quantity: 5
- Terminal Type: PIN
- UPC: 00072845114556
- Voltage: 12V
- Weight (lbs): 2.58
- Wire Harness Included: No
- Part Description: Fuel Pump Module Assembly
