2005 Chevrolet Monte Carlo Heater Hose
My Vehicle Change Vehicle
2005 Chevrolet Monte Carlo
< Back to View All
A/C & Heating
- Department
- Brands
- Prices
Product Specifications- Notes: Thermostat Bypass Pipe; To Front Cover
- Color: Black
- Construction: Rubber
- Hardware: Use Existing Hardware
- OE Part Number: 24507875
- UPC: 019495356004
- Part Description: 2005 Chevrolet Monte Carlo Hvac Heater Hose Assembly
Vehicle Fitment- 2005 Chevrolet Monte Carlo | All Trims | 6 Cyl 3.4L
Product Specifications- Notes: Cut to Length, 20"
- Centerline Length: 50 ft
- End 1 Inside Diameter: 10 mm
- End 2 Inside Diameter: .375 in
- Material: EPDM
- OE Part Number: 8899
- UPC: 072053081183
- Weight Per Length: 8.25 lbs./Carton
- Working Pressure: 60 PSI
- Part Description: 2005 Chevrolet Monte Carlo Safety Stripe Hvac Heater Hose
Vehicle Fitment- 2005 Chevrolet Monte Carlo | All Trims | 6 Cyl 3.4L
- 2005 Chevrolet Monte Carlo | All Trims | 6 Cyl 3.8L
Product Specifications- Notes: Top Hose
- Color: Black
- Contains Heat Shield: N
- Contains Protective Sleeve: N
- End 1 Inside Diameter: 5/8
- End 2 Inside Diameter: 3/4
- Hose Type: Dual I.D. Hose
- Material: EPDM
- SAE Specification: SAE J20R3 Class D-1, SAE J1684 Type EC
- Trunk Height: 18
- UPC: 036687628459
- Part Description: 2005 Chevrolet Monte Carlo Upper Small Id Hvac Heater Hose
Vehicle Fitment- 2005 Chevrolet Monte Carlo | All Trims | 6 Cyl 3.8L
Product Specifications- Notes: Heater Hose Inlet Tube
- Color: Black/Coated
- Coolant Hose Heat Shield Included: No Heat Shield Required
- Coolant Hose Length: 10"
- Coolant Hose Material: Steel
- Coolant Hose Protective Sleeve Included: No Protective Sleeve Required
- Coolant Hose Type: Single I.D. (Inside Diameter)
- End 1 Attachment Type: Flange
- End 2 Attachment Type: Flared
- Hose End (1) Inside Diameter (In): 0.52"
- Hose End (1) Outside Diameter (In): 0.74"
- Hose End (2) Inside Diameter (In): 0.55"
- Hose End (2) Outside Diameter (In): 0.64"
- Maximum Working Pressure (psi): 100
- OE Part Number: 12568743
- Package Contents: Heater Hose Assembly
- SAE Standards: Not Applicable
- Thermostatically Controlled: No
- UPC: 037495332422
- With Clamps: No
- Part Description: 2005 Chevrolet Monte Carlo Hvac Heater Hose Assembly
Vehicle Fitment- 2005 Chevrolet Monte Carlo | All Trims | 6 Cyl 3.4L
Product Specifications- Notes: Cut to Length, 3"
- Centerline Length (in): 600"
- Inside Diameter 1 (in): 0.3125"
- OE Part Number: 49692
- UPC: 072053133226
- Weight Per Length: 7.25 lbs./Carton
- Working Pressure (psi): 60
- Part Description: 2005 Chevrolet Monte Carlo Safety Stripe Hvac Heater Hose
Vehicle Fitment- 2005 Chevrolet Monte Carlo | All Trims | 6 Cyl 3.4L
Product Specifications- Notes: Bottom Hose
- Color: Black
- Contains Heat Shield: N
- Contains Protective Sleeve: N
- End 1 Inside Diameter: 5/8
- End 2 Inside Diameter: 5/8
- Hose Type: Single I.D. Hose
- Material: EPDM
- SAE Specification: SAE J20R3 Class D-1, SAE J1684 Type EC
- Trunk Height: 19
- UPC: 036687616128
- Part Description: 2005 Chevrolet Monte Carlo Lower Small Id Hvac Heater Hose
Vehicle Fitment- 2005 Chevrolet Monte Carlo | All Trims | 6 Cyl 3.8L
Product Specifications- Notes: Thermostat Bypass Pipe; Part of the Lower Intake
- Color: Black
- Construction: Rubber
- Hardware: Use Existing Hardware
- OE Part Number: 12590279
- UPC: 019495291053
- Part Description: 2005 Chevrolet Monte Carlo Hvac Heater Hose Assembly
Vehicle Fitment- 2005 Chevrolet Monte Carlo | All Trims | 6 Cyl 3.4L
Product Specifications- Centerline Length (in): 21.4"
- Inside Diameter 1 (in): 0.62"
- Number of Branches: 0
- UPC: 072053466195
- Part Description: 2005 Chevrolet Monte Carlo Hvac Heater Molded Hose
Vehicle Fitment- 2005 Chevrolet Monte Carlo | All Trims | 6 Cyl 3.4L
Product Specifications- Notes: Bottom Hose
- Color: Black
- Contains Heat Shield: N
- Contains Protective Sleeve: N
- End 1 Inside Diameter: 5/8
- End 2 Inside Diameter: 3/4
- Hose Type: Dual I.D. Hose
- Material: EPDM
- SAE Specification: SAE J20R3 Class D-1, SAE J1684 Type EC
- Trunk Height: 10
- UPC: 038244598199
- Part Description: 2005 Chevrolet Monte Carlo Inlet Small Id Hvac Heater Hose
Vehicle Fitment- 2005 Chevrolet Monte Carlo | All Trims | 6 Cyl 3.4L
Product Specifications- Notes: Cut to fit
- Centerline Length (in): 9.6"
- Inside Diameter 1 (in): 0.38"
- Number of Branches: 0
- OE Part Number: 31072
- UPC: 072053178043
- Part Description: 2005 Chevrolet Monte Carlo Hvac Heater Molded Hose
Vehicle Fitment- 2005 Chevrolet Monte Carlo | All Trims | 6 Cyl 3.4L
Product Specifications- Branch Quantity: 0
- Centerline Length (in): 6
- Centerline Length (mm): 152
- End 1 Inside Diameter: 0.59 in
- End 2 Inside Diameter: 0.59 in
- Material: EPDM
- Molded: Yes
- Number of Quick Connect Fittings: 0
- OE Part Number: 2465
- UPC: 072053199383
- Part Description: 2005 Chevrolet Monte Carlo Engine Coolant Molded Bypass Hose
Vehicle Fitment- 2005 Chevrolet Monte Carlo | All Trims | 6 Cyl 3.4L
Product Specifications- Notes: 90 Degree Hose
- Color: Black
- Contains Heat Shield: N
- Contains Protective Sleeve: N
- End 1 Inside Diameter: 5/16
- End 2 Inside Diameter: 5/16
- Hose Type: Single I.D. Hose
- Material: EPDM
- SAE Specification: SAE J20R3 Class D-1, SAE J1684 Type EC
- Trunk Height: 8 1/4
- UPC: 038244597512
- Part Description: 2005 Chevrolet Monte Carlo Small Id Hvac Heater Hose
Vehicle Fitment- 2005 Chevrolet Monte Carlo | All Trims | 6 Cyl 3.4L
Product Specifications- Centerline Length (in): 19.3"
- Inside Diameter 1 (in): 0.64"
- Number of Branches: 0
- UPC: 072053553963
- Part Description: 2005 Chevrolet Monte Carlo Hvac Heater Molded Hose
Vehicle Fitment- 2005 Chevrolet Monte Carlo | All Trims | 6 Cyl 3.4L
Product Specifications- Centerline Length (in): 24.4"
- Inside Diameter 1 (in): 0.64"
- Inside Diameter 2 (in): 0.73"
- Number of Branches: 0
- UPC: 072053845792
- Part Description: 2005 Chevrolet Monte Carlo Upper Hvac Heater Molded Hose
Vehicle Fitment- 2005 Chevrolet Monte Carlo | All Trims | 6 Cyl 3.8L
Product Specifications- Centerline Length (in): 25.7"
- Inside Diameter 1 (in): 0.64"
- Number of Branches: 0
- UPC: 072053845815
- Part Description: 2005 Chevrolet Monte Carlo Lower Hvac Heater Molded Hose
Vehicle Fitment- 2005 Chevrolet Monte Carlo | All Trims | 6 Cyl 3.8L
