2007 Chevrolet Monte Carlo Heater Hose
My Vehicle Change Vehicle
2007 Chevrolet Monte Carlo
< Back to View All
A/C & Heating
- Department
- Brands
- Prices
Product Specifications- Notes: Inlet & Outlet; Heater Pipe
- Color: Black
- Construction: Rubber
- Hardware: Use Existing Hardware
- OE Part Number: 12598522
- UPC: 885484533677
- Part Description: 2007 Chevrolet Monte Carlo Hvac Heater Hose Assembly
Vehicle Fitment- 2007 Chevrolet Monte Carlo | All Trims | 6 Cyl 3.5L
Product Specifications- Notes: Cut to Length, 6";Cut to Length, 3";Cut to Length, 10"
- Centerline Length: 50 ft
- End 1 Inside Diameter: .625 in
- End 2 Inside Diameter: .625 in
- Material: EPDM
- OE Part Number: 8990
- UPC: 072053066319
- Weight Per Length: 11.70 lbs./Carton
- Working Pressure: 60 PSI
- Part Description: 2007 Chevrolet Monte Carlo Safety Stripe Hvac Heater Hose
Vehicle Fitment- 2007 Chevrolet Monte Carlo | All Trims | 6 Cyl 3.5L
- 2007 Chevrolet Monte Carlo | All Trims | 8 Cyl 5.3L
Product Specifications- Notes: Inlet & Outlet; Heater Pipe
- Branch Quantity: 2
- Color/Finish: Black/Coated
- Contains Spring: No
- Coolant Hose Heat Shield Included: No
- Coolant Hose Length: 16.5"
- Coolant Hose Material: Aluminum and Rubber
- Coolant Hose Protective Sleeve Included: No
- Coolant Hose Type: Dual I.D. (Inside Diameter)
- End 1 Attachment Type: Barbed
- End 2 Attachment Type: Barbed
- End 3 Attachment Type: Hose
- Grade Type: Regular
- Hose End (1) Inside Diameter (In): 0.504"
- Hose End (1) Outside Diameter (In): 0.633"
- Hose End (2) Inside Diameter (In): 0.504"
- Hose End (2) Outside Diameter (In): 0.633"
- Hose End (3) Inside Diameter (In): 0.636"
- Hose End (3) Outside Diameter (In): 0.983"
- Hose Shape: Molded Assembly
- Maximum Working Pressure (psi): 100 PSI
- OE Part Number: 12603834, 12612347
- Thermostatically Controlled: No
- UPC: 885484391352
- With Clamps: Yes
- Part Description: 2007 Chevrolet Monte Carlo Hvac Heater Hose Assembly
Vehicle Fitment- 2007 Chevrolet Monte Carlo | All Trims | 6 Cyl 3.5L
Product Specifications- Notes: Cut to Length, 20";Cut to Length, 44";Cut to Length, 10"
- Centerline Length: 50 ft
- End 1 Inside Diameter: 10 mm
- End 2 Inside Diameter: .375 in
- Material: EPDM
- OE Part Number: 8899
- UPC: 072053081183
- Weight Per Length: 8.25 lbs./Carton
- Working Pressure: 60 PSI
- Part Description: 2007 Chevrolet Monte Carlo Safety Stripe Hvac Heater Hose
Vehicle Fitment- 2007 Chevrolet Monte Carlo | All Trims | 6 Cyl 3.5L
- 2007 Chevrolet Monte Carlo | All Trims | 8 Cyl 5.3L
Product Specifications- Notes: Cut to Fit
- Color: Black
- Contains Heat Shield: N
- Contains Protective Sleeve: N
- End 1 Inside Diameter: 1/4
- End 2 Inside Diameter: 1/4
- Hose Type: Single I.D. Hose
- Material: EPDM
- SAE Specification: SAE J20R3 Class D-1, SAE J1684 Type EC
- Trunk Height: 14 1/4
- UPC: 038244597482
- Part Description: 2007 Chevrolet Monte Carlo Small Id Hvac Heater Hose
Vehicle Fitment- 2007 Chevrolet Monte Carlo | All Trims | 8 Cyl 5.3L
Product Specifications- Notes: Cut to Length, 14"
- Centerline Length (in): 600"
- Inside Diameter 1 (in): 0.25"
- OE Part Number: 34580
- UPC: 072053133219
- Weight Per Length: 6 lbs./Carton
- Working Pressure (psi): 60
- Part Description: 2007 Chevrolet Monte Carlo Safety Stripe Hvac Heater Hose
Vehicle Fitment- 2007 Chevrolet Monte Carlo | All Trims | 8 Cyl 5.3L
Product Specifications- Notes: Cut to Fit
- Color: Black
- Contains Heat Shield: N
- Contains Protective Sleeve: N
- End 1 Inside Diameter: 5/8
- End 2 Inside Diameter: 5/8
- Hose Type: Single I.D. Hose
- Material: EPDM
- SAE Specification: SAE J20R3 Class D-1, SAE J1684 Type EC
- Trunk Height: 7
- UPC: 038244598045
- Part Description: 2007 Chevrolet Monte Carlo Small Id Hvac Heater Hose
Vehicle Fitment- 2007 Chevrolet Monte Carlo | All Trims | 6 Cyl 3.5L
Product Specifications- Notes: Cut to fit
- Centerline Length (in): 11.5"
- Inside Diameter 1 (in): 0.62"
- Number of Branches: 0
- UPC: 072053411508
- Part Description: 2007 Chevrolet Monte Carlo Hvac Heater Molded Hose
Vehicle Fitment- 2007 Chevrolet Monte Carlo | All Trims | 6 Cyl 3.5L
Product Specifications- Centerline Length (in): 17.7"
- Inside Diameter 1 (in): 0.62"
- Number of Branches: 0
- UPC: 072053179316
- Part Description: 2007 Chevrolet Monte Carlo Hvac Heater Molded Hose
Vehicle Fitment- 2007 Chevrolet Monte Carlo | All Trims | 6 Cyl 3.5L
Product Specifications- Centerline Length (in): 18.4"
- Inside Diameter 1 (in): 0.62"
- Inside Diameter 2 (in): 0.75"
- Number of Branches: 0
- UPC: 770075327448
- Part Description: 2007 Chevrolet Monte Carlo Hvac Heater Molded Hose
Vehicle Fitment- 2007 Chevrolet Monte Carlo | All Trims | 6 Cyl 3.5L
Product Specifications- Branch Quantity: 0
- Centerline Length (in): 7.1
- Centerline Length (mm): 180
- End 1 Inside Diameter: 0.59 in
- End 2 Inside Diameter: 0.59 in
- Material: EPDM
- Molded: Yes
- Number of Quick Connect Fittings: 0
- OE Part Number: 2728
- UPC: 072053186147
- Part Description: 2007 Chevrolet Monte Carlo Hvac Heater Molded Hose
Vehicle Fitment- 2007 Chevrolet Monte Carlo | All Trims | 6 Cyl 3.5L
Product Specifications- Branch Quantity: 0
- Centerline Length (in): 8.1
- Centerline Length (mm): 206
- End 1 Inside Diameter: 0.73 in
- End 2 Inside Diameter: 0.73 in
- Material: EPDM
- Molded: Yes
- Number of Quick Connect Fittings: 0
- OE Part Number: 3120
- UPC: 072053524970
- Part Description: 2007 Chevrolet Monte Carlo Engine Coolant Molded Bypass Hose
Vehicle Fitment- 2007 Chevrolet Monte Carlo | All Trims | 6 Cyl 3.5L
Product Specifications- Centerline Length (in): 29.2"
- Inside Diameter 1 (in): 0.63"
- Inside Diameter 2 (in): 0.75"
- Number of Branches: 0
- UPC: 770075309826
- Part Description: 2007 Chevrolet Monte Carlo Hvac Heater Molded Hose
Vehicle Fitment- 2007 Chevrolet Monte Carlo | All Trims | 8 Cyl 5.3L
Product Specifications- Color: Black
- Contains Heat Shield: N
- Contains Protective Sleeve: N
- End 1 Inside Diameter: 5/8
- End 1 Outside Diameter: 31/32
- End 2 Inside Diameter: 3/4
- End 2 Outside Diameter: 1 3/32
- Hose Type: Dual I.D. Hose
- Material: EPDM
- SAE Specification: SAE J20R3 Class D-1, SAE J1684 Type EC
- Trunk Height: 15 1/2
- UPC: 036687886477
- Part Description: 2007 Chevrolet Monte Carlo Molded Heater Hose
Vehicle Fitment- 2007 Chevrolet Monte Carlo | All Trims | 8 Cyl 5.3L
FAQ for Heater Hose Repair
Q: How do you remove the heater hose?
A:
You can drain the coolant, and remove the surge tank, and the heater outlet hose.
By Omar
GM Specialist
14/03/2022Q: What is the proper way to install the heater hose?
A:
The proper way is to install the heater outlet hose clamps, the heater outlet hose, and the surge tank, and fill up the coolant.
By Bob
GM Specialist
10/03/2022Q: What is the proper way to remove the heater inlet hose?
A:
The proper way is to drain the coolant, reposition the heater inlet hose clamp, and remove the heater inlet hose as well as the clamp.
By Omar
GM Specialist
10/03/2022Q: What should you do before you remove the heater pipes?
A:
You should drain the vehicle's cooling system.
By Bob
GM Specialist
08/03/2022
