2008 Cadillac SRX Radiator Hose
My Vehicle Change Vehicle
2008 Cadillac SRX
< Back to View All
Cooling Systems, Fans & Radiators
- Department
- Brands
- Prices
Product Specifications- Notes: W/O HD Cool.
- Branch Quantity: 0
- Contains Spring: No
- End 1 Inside Diameter: 1.25 in
- End 2 Inside Diameter: 1.5 in
- Material: EPDM
- Modular Hose: No
- Molded: Yes
- Number of Quick Connect Fittings: 0
- OE Part Number: 5579
- UPC: 770075144816
- Part Description: 2008 Cadillac SRX Engine Coolant Molded Radiator Hose
Vehicle Fitment- 2008 Cadillac SRX | All Trims | 8 Cyl 4.6L
Product Specifications- Notes: w/o Tow Pkg
- Color: Black
- Contains Heat Shield: N
- Contains Protective Sleeve: Y
- End 1 Inside Diameter: 1 5/16
- End 1 Outside Diameter: 1 21/32
- End 2 Inside Diameter: 1 1/2
- End 2 Outside Diameter: 1 29/32
- Hose Type: Dual I.D. Hose
- Material: EPDM
- SAE Specification: SAE J20R4 Class D-1, SAE J1684 Type EC
- Trunk Height: 22 1/2
- UPC: 036687834379
- Part Description: 2008 Cadillac SRX Engine Coolant Curved Radiator Hose
Vehicle Fitment- 2008 Cadillac SRX | All Trims | 8 Cyl 4.6L
Product Specifications- Notes: W/O HD Cool.
- Branch Quantity: 0
- Contains Spring: No
- End 1 Inside Diameter: 1.25 in
- End 2 Inside Diameter: 1.25 in
- Material: EPDM
- Modular Hose: No
- Molded: Yes
- Number of Quick Connect Fittings: 0
- OE Part Number: 5577
- UPC: 770075144779
- Part Description: 2008 Cadillac SRX Engine Coolant Molded Radiator Hose
Vehicle Fitment- 2008 Cadillac SRX | All Trims | 8 Cyl 4.6L
Product Specifications- Notes: w/o Tow Pkg
- Color: Black
- Contains Heat Shield: N
- Contains Protective Sleeve: N
- End 1 Inside Diameter: 1 5/16
- End 2 Inside Diameter: 1 5/16
- Hose Type: Single I.D. Hose
- Material: EPDM
- OE Part Number: 10360707, 89023438
- SAE Specification: SAE J20R4 Class D-1, SAE J1684 Type EC
- Trunk Height: 12 1/2
- UPC: 036687804006
- Part Description: 2008 Cadillac SRX Engine Coolant Curved Radiator Hose
Vehicle Fitment- 2008 Cadillac SRX | All Trims | 8 Cyl 4.6L
Product Specifications- Branch Quantity: 0
- Contains Spring: No
- End 1 Inside Diameter: 1.25 in
- End 2 Inside Diameter: 1.5 in
- Material: EPDM, Plastic
- Modular Hose: No
- Molded: Yes
- Number of Quick Connect Fittings: 0
- OE Part Number: 5832
- UPC: 770075144694
- Part Description: 2008 Cadillac SRX Engine Coolant Molded Radiator Hose
Vehicle Fitment- 2008 Cadillac SRX | All Trims | 6 Cyl 3.6L
Product Specifications- Notes: Cut to Fit
- Color: Black
- Contains Heat Shield: N
- Contains Protective Sleeve: N
- End 1 Inside Diameter: 1 5/16
- End 2 Inside Diameter: 1 5/16
- Hose Type: Single I.D. Hose
- Material: EPDM
- SAE Specification: SAE J20R4 Class D-1, SAE J1684 Type EC
- Trunk Height: 6
- UPC: 038244243273
- Part Description: 2008 Cadillac SRX Engine Coolant Curved Radiator Hose
Vehicle Fitment- 2008 Cadillac SRX | All Trims | 8 Cyl 4.6L
Product Specifications- Branch Quantity: 0
- Contains Spring: No
- End 1 Inside Diameter: 1.3 in
- End 2 Inside Diameter: 1.3 in
- Material: EPDM
- Modular Hose: No
- Molded: Yes
- Number of Quick Connect Fittings: 0
- OE Part Number: 5782
- UPC: 770075327479
- Part Description: 2008 Cadillac SRX Engine Coolant Molded Radiator Hose
Vehicle Fitment- 2008 Cadillac SRX | All Trims | 6 Cyl 3.6L
Product Specifications- UPC: 038244148035
- Part Description: 2008 Cadillac SRX 90 Degree Engine Coolant Molded Radiator Hose
Vehicle Fitment- 2008 Cadillac SRX | All Trims | 8 Cyl 4.6L
Product Specifications- Notes: Cut to fit
- Branch Quantity: 0
- Contains Spring: No
- End 1 Inside Diameter: 1.26 in
- End 2 Inside Diameter: 1.26 in
- Material: EPDM
- Modular Hose: No
- Molded: Yes
- Number of Quick Connect Fittings: 0
- OE Part Number: 32322
- UPC: 072053057287
- Part Description: 2008 Cadillac SRX Engine Coolant Molded Bypass Hose
Vehicle Fitment- 2008 Cadillac SRX | All Trims | 8 Cyl 4.6L
Product Specifications- UPC: 038244148127
- Part Description: 2008 Cadillac SRX Molded Heater Hose
Vehicle Fitment- 2008 Cadillac SRX | All Trims | 8 Cyl 4.6L
Product Specifications- Branch Quantity: 0
- Contains Spring: No
- End 1 Inside Diameter: 0.61 in
- End 2 Inside Diameter: 0.75 in
- Material: EPDM
- Modular Hose: No
- Molded: Yes
- Number of Quick Connect Fittings: 0
- OE Part Number: 32147
- UPC: 072053052305
- Part Description: 2008 Cadillac SRX Engine Coolant Molded Radiator Hose
Vehicle Fitment- 2008 Cadillac SRX | All Trims | 8 Cyl 4.6L
Product Specifications- Branch Quantity: 1
- Centerline Length: 60.1"
- Contains Spring: No
- End 1 Inside Diameter: 0.32"
- End 2 Inside Diameter: 0.32"
- End 3 Inside Diameter: 0.32"
- Material: EPDM, Plastic
- Modular Components: Branch
- Modular Hose: Yes
- Molded: Yes
- Number of Quick Connect Fittings: 0
- UPC: 770075295341
- Part Description: 2008 Cadillac SRX Premium Modular Coolant Hose
Vehicle Fitment- 2008 Cadillac SRX | All Trims | 6 Cyl 3.6L
Product Specifications- Branch Quantity: 1
- Centerline Length: 1527 mm
- Contains Spring: No
- End 1 Inside Diameter: .32 in
- End 2 Inside Diameter: .32 in
- End 3 Inside Diameter: .24 in
- Material: EPDM, Plastic
- OE Part Number: 48195
- UPC: 770075295075
- Part Description: 2008 Cadillac SRX Engine Coolant Molded Radiator Hose
Vehicle Fitment- 2008 Cadillac SRX | All Trims | 8 Cyl 4.6L
Product Specifications- Notes: 4.6 Liter, W/O Trailer Package; 4.6 Liter, W/Trailer Package
- Other Names: Outlet Hose, Outlet Pipe, Overflow Hose
- Item Dimensions: 36.9 x 8.8 x 5.4 inches
- Item Weight: 0.50 Pounds
- Fitment Type: Direct Replacement
- Part Description: 2008 Cadillac SRX Outlet Hose
Vehicle Fitment- 2008 Cadillac SRX | Base | 8 Cyl 4.6 L GAS
Product Specifications- Notes: Srx; 3.6l; 3.6 Liter, 2nd Design
- Other Names: Lower Hose
- Item Dimensions: 24.3 x 6.4 x 4.6 inches
- Item Weight: 0.30 Pounds
- Fitment Type: Direct Replacement
- Replaces: 19130218
- Part Description: 2008 Cadillac SRX Lower Hose
Vehicle Fitment- 2008 Cadillac SRX | Base | 6 Cyl 3.6 L GAS
Product Specifications- Notes: 4.6 Liter, W/O Trailer Package
- Other Names: Inlet Hose
- Item Dimensions: 14.0 x 13.2 x 3.7 inches
- Item Weight: 2.20 Pounds
- Fitment Type: Direct Replacement
- Part Description: 2008 Cadillac SRX Radiator Surge Tank Inlet Hose Assembly
Vehicle Fitment- 2008 Cadillac SRX | Base | 8 Cyl 4.6 L GAS
Product Specifications- Notes: 4.6 Liter, W/Trailer Package
- Other Names: Inlet Hose
- Item Dimensions: 24.6 x 13.8 x 1.3 inches
- Item Weight: 2.90 Pounds
- Fitment Type: Direct Replacement
- Part Description: 2008 Cadillac SRX Radiator Surge Tank Inlet Hose
Vehicle Fitment- 2008 Cadillac SRX | Base | 8 Cyl 4.6 L GAS
Product Specifications- Notes: Srx; 4.6l; 4.6 Liter, W/O Trailer Package
- Other Names: Lower Hose
- Item Dimensions: 25.8 x 22.2 x 10.5 inches
- Item Weight: 2.50 Pounds
- Fitment Type: Direct Replacement
- Part Description: 2008 Cadillac SRX Radiator Outlet Hose Assembly
Vehicle Fitment- 2008 Cadillac SRX | Base | 8 Cyl 4.6 L GAS
Product Specifications- Notes: Srx; 4.6l; 4.6 Liter, W/Trailer Package
- Other Names: Upper Hose
- Item Dimensions: 15.0 x 10.7 x 7.0 inches
- Item Weight: 1.20 Pounds
- Fitment Type: Direct Replacement
- Replaces: 25974695
- Part Description: 2008 Cadillac SRX Radiator Inlet Hose (Upper)
Vehicle Fitment- 2008 Cadillac SRX | Base | 8 Cyl 4.6 L GAS
Product Specifications- Notes: w/Tow Pkg
- Color: Black
- Contains Heat Shield: N
- Contains Protective Sleeve: N
- End 1 Inside Diameter: 1 5/16
- End 1 Outside Diameter: 1 3/4
- End 2 Inside Diameter: 1 5/16
- End 2 Outside Diameter: 1 3/4
- Hose Type: Single I.D. Hose
- Material: EPDM
- SAE Specification: SAE J20R4 Class D-1, SAE J1684 Type EC
- Trunk Height: 13 1/2
- UPC: 036687886422
- Part Description: 2008 Cadillac SRX Engine Coolant Curved Radiator Hose
Vehicle Fitment- 2008 Cadillac SRX | All Trims | 8 Cyl 4.6L
Product Specifications- Notes: 4.6 Liter, W/Trailer Package
- Other Names: Lower Hose
- Item Dimensions: 32.0 x 17.3 x 4.9 inches
- Item Weight: 3.00 Pounds
- Fitment Type: Direct Replacement
- Part Description: 2008 Cadillac SRX Radiator Outlet Hose (Lower)
Vehicle Fitment- 2008 Cadillac SRX | Base | 8 Cyl 4.6 L GAS
Product Specifications- Notes: 3.6 Liter
- Other Names: Outlet Hose
- Item Dimensions: 14.4 x 4.4 x 4.4 inches
- Item Weight: 1.20 Pounds
- Fitment Type: Direct Replacement
- Replaces: 89022532
- Part Description: 2008 Cadillac SRX Radiator Surge Tank Outlet Hose
Vehicle Fitment- 2008 Cadillac SRX | Base | 6 Cyl 3.6 L GAS
Product Specifications- Notes: 3.6 Liter; 4.6 Liter, W/O Trailer Package; 4.6 Liter, W/Trailer Package
- Other Names: Overflow Hose
- Item Dimensions: 7.7 x 6.2 x 5.0 inches
- Item Weight: 0.70 Pounds
- Fitment Type: Direct Replacement
- Part Description: 2008 Cadillac SRX Radiator Surge Tank Overflow Hose
Vehicle Fitment- 2008 Cadillac SRX | Base | 6 Cyl 3.6 L GAS, 8 Cyl 4.6 L GAS
Product Specifications- Notes: 3.6 Liter
- Other Names: Inlet Hose
- Item Dimensions: 17.4 x 17.3 x 5.9 inches
- Item Weight: 1.00 Pounds
- Fitment Type: Direct Replacement
- Part Description: 2008 Cadillac SRX Radiator Surge Tank Inlet Hose
Vehicle Fitment- 2008 Cadillac SRX | Base | 6 Cyl 3.6 L GAS
Product Specifications- Notes: Srx; 3.6l; 3.6 Liter
- Other Names: Upper Hose
- Item Dimensions: 14.7 x 14.8 x 4.3 inches
- Item Weight: 0.90 Pounds
- Fitment Type: Direct Replacement
- Part Description: 2008 Cadillac SRX Radiator Inlet Hose (Upper)
Vehicle Fitment- 2008 Cadillac SRX | Base | 6 Cyl 3.6 L GAS
Product Specifications- Notes: 3.6 Liter
- Other Names: Outlet Pipe
- Item Dimensions: 25.0 x 16.8 x 10.4 inches
- Item Weight: 4.70 Pounds
- Fitment Type: Direct Replacement
- Part Description: 2008 Cadillac SRX Radiator Coolant Outlet Pipe Assembly
Vehicle Fitment- 2008 Cadillac SRX | Base | 6 Cyl 3.6 L GAS
Product Specifications- Notes: Srx; 4.6l; 4.6 Liter, W/O Trailer Package
- Other Names: Upper Hose
- Item Dimensions: 14.1 x 5.8 x 4.6 inches
- Item Weight: 0.90 Pounds
- Fitment Type: Direct Replacement
- Replaces: 88957426, 89023438
- Part Description: 2008 Cadillac SRX Radiator Coolant Hose Assembly
Vehicle Fitment- 2008 Cadillac SRX | Base | 8 Cyl 4.6 L GAS
Product Specifications- Notes: 4.6 Liter, W/Trailer Package
- Other Names: Outlet Hose, Water Pump Tube
- Item Dimensions: 10.3 x 3.8 x 1.6 inches
- Item Weight: 0.50 Pounds
- Fitment Type: Direct Replacement
- Part Description: 2008 Cadillac SRX Auxiliary Water Pump Outlet Hose
Vehicle Fitment- 2008 Cadillac SRX | Base | 8 Cyl 4.6 L GAS
FAQ for Radiator Hose Repair
Q: How to install the Radiator Inlet Hose (LY7-Gas, 6 Cylinder, 3.6L, SFI, V6)?
A:
You should install the inlet radiator hose into the vehicle, lubricate the inside diameters of the hoses with clean coolant, disengage the tension on the hose clamp and the radiator inlet hose to the radiator, slide the clamp into the original position, disengage the tension on the hose clamp and install the radiator inlet hose to the thermostat housing, slide the clamp into the original position and fill the cooling system.
By Bob
GM Specialist
01/11/2022Q: How to remove the Radiator Inlet Hose (LY7-Gas, 6 Cylinder, 3.6L, SFI, V6)?
A:
You should drain the coolant, use the J 38185 to disengage the tension on the hose clamp, remove the radiator inlet hose from the thermostat housing, disengage the tension on the hose clamp and remove the radiator inlet hose from the radiator and the radiator inlet hose from the vehicle.
By Bob
GM Specialist
01/11/2022Q: How to remove the Radiator Outlet Hose (LY7-Gas, 6 Cylinder, 3.6L, SFI, V6)?
A:
You should drain the coolant, remove the radiator inlet hose, disengage the tension on the hose clamp, remove the radiator outlet hose from the thermostat housing, disconnect the radiator outlet hose from the engine support bracket, remove the air cleaner intake duct, disengage the tension on the hose clamp and remove the radiator outlet hose from the radiator and the radiator outlet hose from the vehicle.
By Bob
GM Specialist
01/11/2022
