Ford Ranger Valve Spring
Select vehicle to guarantee fit
Make
Model
Year
< Back to View All
Valves, Valve Covers & Valvetrain
- Department
- Brands
- Prices
$5.58 MSRP:$8.72You Save: $3.14 (37%)Product Specifications- Other Names: Valve Springs
- Item Weight: 0.40 Pounds
- Fitment Type: Direct Replacement
- Replaces: F77Z-6513-AA
- Part Description: Ford Ranger Valve Springs
- $4.29 MSRP:
$6.70You Save: $2.41 (36%)Product Specifications- Other Names: Valve Springs
- Item Weight: 0.40 Pounds
- Fitment Type: Direct Replacement
- Replaces: 3M4Z-6513-AA
- Part Description: Ford Ranger Valve Springs
- $24.44 MSRP:
$39.00You Save: $14.56 (38%)Product Specifications- Other Names: Valve Springs
- Item Weight: 0.40 Pounds
- Fitment Type: Direct Replacement
- Part Description: Ford Ranger Valve Springs
- $5.23 MSRP:
$8.18You Save: $2.95 (37%)Product Specifications- Other Names: Valve Springs
- Item Weight: 0.40 Pounds
- Fitment Type: Direct Replacement
- Part Description: Ford Ranger Valve Springs
- $4.89 MSRP:
$7.66You Save: $2.77 (37%)Product Specifications- Other Names: Valve Springs
- Item Weight: 0.40 Pounds
- Fitment Type: Direct Replacement
- Part Description: Ford Ranger Valve Springs
$3.70Product Specifications- OS Free Height: 46.7360
- OS Free Height (Inch): 1.8400
- OS Max OD: 33.1980
- OS Max OD (Inch): 1.3070
- OS Min Close: 40.0560
- OS Min Close (Inch): 1.5770
- OS Min Close LBS: 61
- OS Min ID: 23.4440
- OS Min ID (Inch): 0.9230
- OS Min Open: 29.3620
- OS Min Open (Inch): 1.1560
- OS Min Open LBS: 172
- OS Solid Height: 26.6700
- OS Solid Height (Inch): 1.0500
- OS Spring Rate: 263.7
- OS Total Coils: 5.9
- OS Wire Diameter: 4.6230
- OS Wire Diameter (Inch): 0.1820
- Spring Configuration: S Single
- UPC: 724956645749
- Part Description: Ford Ranger Engine Valve Spring
- Product Specifications
- Other Names: Valve Springs
- Item Weight: 0.40 Pounds
- Fitment Type: Direct Replacement
- Part Description: Ford Ranger Valve Springs
Product Specifications- OS Free Height: 55.2450
- OS Free Height (Inch): 2.1750
- OS Max OD: 34.3660
- OS Max OD (Inch): 1.3530
- OS Min Close: 38.6590
- OS Min Close (Inch): 1.5220
- OS Min Close LBS: 103
- OS Min ID: 25.1460
- OS Min ID (Inch): 0.9900
- OS Min Open: 29.7690
- OS Min Open (Inch): 1.1720
- OS Min Open LBS: 191
- OS Solid Height: 29.3370
- OS Solid Height (Inch): 1.1550
- OS Spring Rate: 242.8
- OS Total Coils: 6.9
- OS Wire Diameter: 4.3690
- OS Wire Diameter (Inch): 0.1720
- Spring Configuration: S Single
- UPC: 724956645800
- Part Description: Ford Ranger Engine Valve Spring
Product Specifications- OS Free Height: 53.2130
- OS Free Height (Inch): 2.0950
- OS Max OD: 34.3660
- OS Max OD (Inch): 1.3530
- OS Min Close: 38.1000
- OS Min Close (Inch): 1.5000
- OS Min Close LBS: 98
- OS Min ID: 25.5270
- OS Min ID (Inch): 1.0050
- OS Min Open: 29.2100
- OS Min Open (Inch): 1.1500
- OS Min Open LBS: 177
- OS Solid Height: 28.7020
- OS Solid Height (Inch): 1.1300
- OS Spring Rate: 225.7
- OS Total Coils: 6.8
- OS Wire Diameter: 4.3180
- OS Wire Diameter (Inch): 0.1700
- Package Alert: Carton of 250
- Spring Configuration: S Single
- UPC: 614046178250
- Part Description: Ford Ranger Engine Valve Spring
Product Specifications- OS Free Height: 52.0700
- OS Free Height (Inch): 2.0500
- OS Max OD: 34.0110
- OS Max OD (Inch): 1.3390
- OS Min Close: 40.3860
- OS Min Close (Inch): 1.5900
- OS Min Close LBS: 67.5
- OS Min ID: 25.5270
- OS Min ID (Inch): 1.0050
- OS Min Open: 30.2260
- OS Min Open (Inch): 1.1900
- OS Min Open LBS: 146.5
- OS Solid Height: 28.1940
- OS Solid Height (Inch): 1.1100
- OS Spring Rate: 209
- OS Total Coils: 6.9
- OS Wire Diameter: 4.1150
- OS Wire Diameter (Inch): 0.1620
- Spring Configuration: S/D Single with Damper
- UPC: 724956648108
- Part Description: Ford Ranger Engine Valve Spring
OEM (Genuine) Ford Ranger Valve Spring
PartNumber: E3TZ6513CProduct Specifications- Part Description: Ford Ranger Valve Spring
OEM (Genuine) Ford Ranger Valve Spring
PartNumber: E3TZ6513DProduct Specifications- Part Description: Ford Ranger Valve Spring
OEM (Genuine) Ford Ranger Valve Spring
PartNumber: E3TZ6513EProduct Specifications- Part Description: Ford Ranger Valve Spring
OEM (Genuine) Ford Ranger Valve Spring
PartNumber: E4ZZ6513AProduct Specifications- Part Description: Ford Ranger Valve Spring
OEM (Genuine) Ford Ranger Valve Spring
PartNumber: E5TZ6513CProduct Specifications- Part Description: Ford Ranger Valve Spring
OEM (Genuine) Ford Ranger Valve Spring
PartNumber: E6TZ6513AProduct Specifications- Part Description: Ford Ranger Valve Spring
OEM (Genuine) Ford Ranger Valve Springs
PartNumber: E7DZ6513AProduct Specifications- Other Names: Valve Springs
- Item Weight: 1.40 Pounds
- Fitment Type: Direct Replacement
- Part Description: Ford Ranger Valve Springs
- Product Specifications
- Other Names: Valve Springs
- Item Weight: 0.40 Pounds
- Fitment Type: Direct Replacement
- Part Description: Ford Ranger Valve Springs
OEM (Genuine) Ford Ranger Valve Spring
PartNumber: FOTZ6513AProduct Specifications- Part Description: Ford Ranger Valve Spring
