Sealed Power® Recessed Top Piston for Mercury Montego
PartNumber: 354PProduct Specifications- Bore: 4.1300"
- Compression Distance: 1.665
- Head Illustration: 31
- Head Type: Recessed Head .120 deep - 10.2:1 C.R.
- Minimum Clearance: 0.0015 @ 2.570 from top of head
- Part Material: Cast
- Pin Diameter: 0.9753"
- Pin Offset: 0.06"
- Ring 1 Qty: 2
- Ring 1 Width: 5/64
- Ring 2 Qty: 1
- Ring 2 Width: 3/16
- UPC: 724956346516
- Part Description: Mercury Montego Recessed Top Piston
$49.24
Sealed Power® Engine Piston for Mercury Montego
PartNumber: H418CPProduct Specifications- Bore: 110.7400 mm
- Compression Distance: 1.752"
- Dome Volume CC: - 021.0
- Head Illustration: 44
- Material: Hypereutectic
- Minimum Clearance: See Piston Fitting Information on carton label
- Pin Diameter: 1.0402"
- Pin Offset: 1.524 mm
- Ring 1 Qty: 2
- Ring 1 Width: 5/64"
- Ring 2 Qty: 1
- Ring 2 Width: 3/16"
- Size: Standard
- UPC: 614046227347
- Part Description: Mercury Montego Engine Piston
$26.14
Sealed Power® Duroshield Flat Top Cast Piston for Mercury Montego
PartNumber: H273CPProduct Specifications- Bore: 4"
- Compression Distance: 1.605"
- Dome Volume CC: -8
- Head Illustration: 183
- Lock Ring: Included
- Material: Hypereutectic
- Minimum Clearance: 0.0015
- Pin Diameter: 0.912"
- Pin Offset: 0.06"
- Pin Type: F
- Pin Weight Gram: 152
- Ring 1 Qty: 2
- Ring 1 Width: 5/64"
- Ring 2 Qty: 1
- Ring 2 Width: 3/16"
- Size: Standard
- UPC: 614046227095
- Weight W Pin Gram: 731
- Weight w/o Pin Gram: 579
- Part Description: Mercury Montego Duroshield Flat Top Cast Piston
$22.86
Sealed Power® Engine Piston for Mercury Montego
PartNumber: 427NPProduct Specifications- Compression Distance: 1.630
- Head Illustration: 165
- Head Type: Recessed Head .145 deep x 3.000 dia. w/2 valve reliefs - 7.9:1 C.R.
- Minimum Clearance: 0.0015 @ 2.320 from top of head
- Note 1: Standard Size
- Part Material: Cast
- Pin Diameter: 24.768
- Pin Diameter (Inch): 0.9751
- Pin Offset: 1.524
- Pin Offset (Inch): 0.06
- Ring 1 Qty: 2
- Ring 1 Width: 5/64
- Ring 2 Qty: 1
- Ring 2 Width: 3/16
- Standard Size: Standard
- UPC: 019826083401
- Weight W Pin Gram: 751
- Part Description: Mercury Montego Engine Piston
Sealed Power® Flat Top Piston for Mercury Montego
PartNumber: 273APProduct Specifications- Bore: 4.0000"
- Compression Distance: 1.585"
- Dome Volume CC: - 005.0
- Head Illustration: 26
- Material: Cast
- Minimum Clearance: 0.0015 @ 2.300 from top of head
- Oversize: 0.020"
- Pin Diameter: 23.17 mm
- Pin Offset: 1.524 mm
- Ring 1 Qty: 2
- Ring 1 Width: 5/64"
- Ring 2 Qty: 1
- Ring 2 Width: 3/16"
- Size: Standard
- UPC: 724956340743
- Part Description: Mercury Montego Flat Top Piston
Sealed Power® Engine Piston for Mercury Montego
PartNumber: 336PProduct Specifications- Bore: 101.6000
- Bore (Inch): 4.0000
- Compression Distance: 1.719
- Head Illustration: 53
- Head Type: Flat Head w/4 valve reliefs - 8.7:1 C.R.
- Minimum Clearance: 0.0015 @ 2.430 from top of head
- Note 1: Standard Size
- Part Material: Cast
- Pin Diameter: 23.17
- Pin Diameter (Inch): 0.9122
- Pin Offset: 1.524
- Pin Offset (Inch): 0.06
- Ring 1 Qty: 2
- Ring 1 Width: 5/64
- Ring 2 Qty: 1
- Ring 2 Width: 3/16
- Standard Size: Standard
- UPC: 724956344987
- Part Description: Mercury Montego Engine Piston
Sealed Power® Engine Piston for Mercury Montego
PartNumber: 416PProduct Specifications- Bore: 101.6000
- Bore (Inch): 4.0000
- Compression Distance: 1.720
- Head Illustration: 14
- Head Type: Recessed Head .240 deep - 7.7:1 C.R.
- Minimum Clearance: 0.0015 @ 2.430 from top of head
- Note 1: Standard Size
- Part Material: Cast
- Pin Diameter: 23.17
- Pin Diameter (Inch): 0.9122
- Pin Offset: 1.524
- Pin Offset (Inch): 0.06
- Ring 1 Qty: 2
- Ring 1 Width: 5/64
- Ring 2 Qty: 1
- Ring 2 Width: 3/16
- Standard Size: Standard
- UPC: 724956351220
- Part Description: Mercury Montego Engine Piston
Sealed Power® Engine Piston for Mercury Montego
PartNumber: H304PProduct Specifications- Bore: 101.6000
- Bore (Inch): 4.0500
- Compression Distance: 1.759
- Head Illustration: 184
- Head Type: Recessed Head .080 deep x 3.220 dia. w/4 valve reliefs
- Minimum Clearance: 0.001 @ 2.800 from top of head
- Note 1: Standard Size
- Part Material: Hypereutectic
- Pin Diameter: 24.768
- Pin Diameter (Inch): 0.9751
- Pin Offset: 1.524
- Pin Offset (Inch): 0.06
- Ring 1 Qty: 1
- Ring 1 Width: 5/64
- Ring 2 Qty: 1
- Ring 2 Width: 3/32
- Ring 3 Qty: 1
- Ring 3 Width: 3/16
- Standard Size: Standard
- UPC: 724956679706
- Part Description: Mercury Montego Engine Piston
Sealed Power® Engine Piston for Mercury Montego
PartNumber: W272APProduct Specifications- Bore: 101.6000
- Bore (Inch): 4.0000
- Compression Distance: 1.585
- Dome Volume CC: Negative 012.5
- Head Illustration: 29
- Head Type: Recessed Head .110 deep x 2.910 dia. w/4 valve reliefs - 8.9:1 C.R.
- Minimum Clearance: 0.0015 @ 2.300 from top of head
- Note 1: Standard Size
- Note 2: Single Piston
- Package Alert: Single Piston
- Part Material: Cast
- Pin Diameter: 23.17
- Pin Diameter (Inch): 0.9122
- Pin Offset: 1.524
- Pin Offset (Inch): 0.06
- Ring 1 Qty: 2
- Ring 1 Width: 5/64
- Ring 2 Qty: 1
- Ring 2 Width: 3/16
- Standard Size: Standard
- UPC: 614046661998
- Part Description: Mercury Montego Engine Piston
Sealed Power® Engine Piston for Mercury Montego
PartNumber: W273APProduct Specifications- Bore: 101.6000
- Compression Distance: 1.585
- Dome Volume CC: Negative 005.0
- Head Illustration: 26
- Head Type: Flat Head w/4 valve reliefs - 8.2:1 C.R. w/64cc cyl. head
- Minimum Clearance: 0.0015 @ 2.300 from top of head
- Note 1: Standard Size
- Package Alert: Single Piston
- Part Alert: Single Piston
- Part Material: Cast
- Pin Diameter: 0.9122
- Pin Offset: 1.524
- Ring 1 Qty: 2
- Ring 1 Width: 5/64
- Ring 2 Qty: 1
- Ring 2 Width: 3/16
- Standard Size: Standard
- UPC: 614046662025
- Part Description: Mercury Montego Engine Piston
Sealed Power® Engine Piston for Mercury Montego
PartNumber: WH418CPProduct Specifications- Bore: 4.3600"
- Compression Distance: 1.752"
- Dome Volume CC: - 021.0
- Head Illustration: 44
- Material: Hypereutectic
- Minimum Clearance: See Piston Fitting Information on carton label
- Pin Diameter: 26.421 mm
- Pin Offset: 0.06"
- Ring 1 Qty: 2
- Ring 1 Width: 5/64"
- Ring 2 Qty: 1
- Ring 2 Width: 3/16"
- Size: Standard
- UPC: 614046687998
- Part Description: Mercury Montego Engine Piston
