Toyota Cressida A/C Compressor
Select vehicle to guarantee fit
Make
Model
Year
< Back to View All
A/C & Heating
- Department
- Condition
- Brands
- Prices
$168.35Product Specifications- Belt Width IN: 0.500
- Clutch Included: Yes
- Clutch Maximum Diameter: 5.625
- Coil Clock Position: Wire Lead
- Coil Voltage: 12
- Compatible Refrigerant Oil Type: PAG 46
- Compressor Type: 10P15C
- Distance From Clutch To Mounting Flange: 1.6875
- Mounting Hardware: Not Included
- Mounting Type: Tangent Mount
- New or Reman: Remanufactured
- O-Ring A Number/Desc: [24613] / Green O-Ring
- O-Ring A Quantity: 4
- O-Ring B Number/Desc: Not Required
- O-Ring B Quantity: NR
- Printed Foot Note: May Require use of OE Manifold
- Pulley Belt Type: V-Belt
- Pulley Diameter MM: 142.748
- Pulley Groove Quantity: 1
- Pulley Lip Diameter: 5.625
- Pulley Outside Diameter: 5.625
- Pulley Ridge Diameter: 5.625
- Refrigerant Type: R134a
- Reman w/o Clutch: [57310] / Clutch Assembly
- Suc Prt Typ Note: w/O-Ring
- Suction Port Type: Pad Mount
- Terminal Type: Spade
- UPC: 096361673021
- Part Description: Toyota Cressida Remanufactured A C Compressor With Clutch
$178.84Product Specifications- Belt Width IN: 0.500
- Clutch Included: Yes
- Clutch Maximum Diameter: 5.250
- Coil Clock Position: Wire Lead
- Coil Voltage: 12
- Compatible Refrigerant Oil Type: PAG 46
- Compressor Type: 10P15C
- Discharge Port Type: Pad Mount
- Distance From Clutch To Mounting Flange: 1.921875
- Mounting Hardware: Not Included
- Mounting Type: Tangent Mount
- New or Reman: Remanufactured
- O-Ring A Number/Desc: [24613] / Green O-Ring
- O-Ring A Quantity: 4
- O-Ring B Number/Desc: Not Required
- O-Ring B Quantity: NR
- Printed Foot Note: May Require use of OE Manifold
- Pulley Belt Type: V-Belt
- Pulley Diameter MM: 133.350
- Pulley Groove Quantity: 1
- Pulley Lip Diameter: 5.250
- Pulley Outside Diameter: 5.250
- Pulley Ridge Diameter: 5.250
- Refrigerant Type: R134a
- Reman w/o Clutch: [57310] / Clutch Assembly
- Suction Port Type: Pad Mount
- Terminal Type: Butt
- UPC: 096361573895
- Part Description: Toyota Cressida Remanufactured A C Compressor With Clutch
$332.54Product Specifications- Clutch Included: Yes
- Clutch Maximum Diameter: 4.734375
- Coil Clock Position: Wire Lead
- Coil Voltage: 12
- Compatible Refrigerant Oil Type: PAG 46
- Compressor Type: 10PA20C
- Discharge Port Type: Pad Mount
- Distance From Clutch To Mounting Flange: 1.90625
- Mounting Hardware: Not Included
- Mounting Type: Tangent Mount
- New or Reman: New
- O-Ring A Number/Desc: [24156] / Compressor Manifold Port Gasket
- O-Ring A Quantity: 1
- O-Ring B Number/Desc: Not Required
- O-Ring B Quantity: NR
- O-Ring C Number/Desc: Not Required
- O-Ring C Quantity: NR
- Printed Foot Note: May Require use of OE Manifold
- Pulley Belt Type: Serpentine
- Pulley Diameter MM: 120.142
- Pulley Groove Quantity: 4
- Pulley Lip Diameter: 4.734375
- Pulley Outside Diameter: 4.734375
- Pulley Ridge Diameter: 4.734375
- Refrigerant Type: R134a
- Suction Port Type: Pad Mount
- Terminal Type: Spade
- UPC: 096361683761
- Part Description: Toyota Cressida A C Compressor With Clutch
$374.28Product Specifications- Clutch Included: Yes
- Clutch Maximum Diameter: 4.500
- Coil Clock Position: Wire Lead
- Coil Voltage: 12
- Compatible Refrigerant Oil Type: PAG 46
- Compressor Type: 10P15C
- Discharge Port Type: Pad Mount
- Distance From Clutch To Mounting Flange: 1.859375
- Mount Distance MM: 46.990
- Mounting Hardware: Not Included
- Mounting Type: Tangent Mount
- New or Reman: New
- O-Ring A Number/Desc: [24613] / Green O-Ring
- O-Ring A Quantity: 4
- O-Ring B Number/Desc: Not Required
- O-Ring B Quantity: NR
- O-Ring C Number/Desc: Not Required
- O-Ring C Quantity: NR
- Printed Foot Note: May Require use of OE Manifold
- Pulley Belt Type: V-Belt
- Pulley Diameter MM: 114.300
- Pulley Groove Quantity: 1
- Pulley Lip Diameter: 4.500
- Pulley Outside Diameter: 4.500
- Pulley Ridge Diameter: 4.500
- Refrigerant Type: R134a
- Suction Port Type: Pad Mount
- Terminal Type: Spade
- UPC: 096361683020
- Part Description: Toyota Cressida A C Compressor With Clutch
$239.35Product Specifications- Belt Width IN: 0.500
- Belt Width MM: 12.700
- Clutch Included: Yes
- Clutch Maximum Diameter: 5.250
- Coil Clock Position: Wire Lead
- Coil Voltage: 12
- Compatible Refrigerant Oil Type: PAG 46
- Compressor Type: 10PA17C
- Discharge Port Type: Pad Mount
- Distance From Clutch To Mounting Flange: 2.796875
- Mount Distance MM: 71.120
- Mounting Hardware: Not Included
- Mounting Type: Tangent Mount
- New or Reman: New
- O-Ring A Number/Desc: [24156] / Compressor Manifold Port Gasket
- O-Ring A Quantity: 1
- O-Ring B Number/Desc: Not Required
- O-Ring B Quantity: NR
- O-Ring C Number/Desc: Not Required
- O-Ring C Quantity: NR
- Printed Foot Note: May Require use of OE Manifold
- Pulley Belt Type: V-Belt
- Pulley Diameter MM: 133.350
- Pulley Groove Quantity: 1
- Pulley Lip Diameter: 5.250
- Pulley Outside Diameter: 5.250
- Pulley Ridge Diameter: 5.250
- Refrigerant Type: R134a
- Suction Port Type: Pad Mount
- Terminal Type: Spade
- UPC: 096361683716
- Part Description: Toyota Cressida A C Compressor With Clutch
$199.69Product Specifications- Clutch Included: No
- Coil Clock Position: Non Clutch
- Coil Voltage: NR
- Compatible Refrigerant Oil Type: PAG 46
- Compressor Type: 10PA17C
- Mounting Hardware: Not Included
- Mounting Type: Tangent Mount
- New or Reman: New
- O-Ring A Number/Desc: [24156] / Compressor Manifold Port Gasket
- O-Ring A Quantity: 1
- O-Ring B Number/Desc: Not Required
- O-Ring B Quantity: NR
- Printed Foot Note: May Require use of OE Manifold
- Pulley Belt Type: Non-Clutch
- Pulley Groove Quantity: NR
- Refrigerant Type: R134a
- Suc Prt Typ Note: w/Gasket
- Suction Port Type: Pad Mount
- UPC: 096361583627
- Part Description: Toyota Cressida A C Compressor Without Clutch
Product Specifications- Clutch Included: Yes
- Clutch Maximum Diameter: 4.750
- Coil Clock Position: Wire Lead
- Coil Voltage: 12
- Compatible Refrigerant Oil Type: PAG 46
- Compressor Type: 10PA20C
- Discharge Port Type: Pad Mount
- Distance From Clutch To Mounting Flange: 1.90625
- Mount Distance MM: 48.000
- Mounting Hardware: Not Included
- Mounting Type: Tangent Mount
- New or Reman: Remanufactured
- O-Ring A Number/Desc: [24156] / Compressor Manifold Port Gasket
- O-Ring A Quantity: 1
- O-Ring B Number/Desc: Not Required
- O-Ring B Quantity: NR
- Printed Foot Note: May Require use of OE Manifold
- Pulley Belt Type: Serpentine
- Pulley Diameter MM: 120.650
- Pulley Groove Quantity: 4
- Pulley Lip Diameter: 4.750
- Pulley Outside Diameter: 4.750
- Pulley Ridge Diameter: 4.750
- Refrigerant Type: R134a
- Suction Port Type: Pad Mount
- Terminal Type: Spade
- UPC: 096361673762
- Part Description: Toyota Cressida Remanufactured A C Compressor With Clutch
Product Specifications- Clutch Maximum Diameter: 140.0 mm
- Compressor Mount Hole Quantity: 4
- Mounting Type: Bolt Tangent
- OE Part Number: 8832001011, 8832014340, 8831022360
- Pulley Belt Type: V-Belt
- Refrigerant Type: R12
- UPC: 042511161313
- Part Description: Toyota Cressida A/C Compressor
Product Specifications- Clutch Maximum Diameter: 140.0
- Compressor Mount Hole Quantity: 4
- Mounting Type: Bolt Tangent
- New or Remanufactured: Remanufactured
- Pulley Belt Type: V-Belt
- Refrigerant Type: R12
- UPC: 042511161344
- Part Description: Toyota Cressida A/C Compressor
Product Specifications- Clutch Maximum Diameter: 120.0 mm
- Compressor Mount Hole Quantity: 4
- Mounting Type: Bolt Tangent
- OE Part Number: 8831022560, 8832022580
- Pulley Belt Type: Serpentine
- Refrigerant Type: R12
- UPC: 042511165571
- Part Description: Toyota Cressida A/C Compressor
Product Specifications- Belt Width IN: 0.500
- Belt Width MM: 12.700
- Clutch Included: Yes
- Clutch Maximum Diameter: 5.250
- Coil Clock Position: Wire Lead
- Coil Voltage: 12
- Compatible Refrigerant Oil Type: PAG 46
- Compressor Type: 10PA17C
- Discharge Port Type: Pad Mount
- Distance From Clutch To Mounting Flange: 2.796875
- Mount Distance MM: 71.120
- Mounting Hardware: Not Included
- Mounting Type: Tangent Mount
- New or Reman: Remanufactured
- O-Ring A Number/Desc: [24156] / Compressor Manifold Port Gasket
- O-Ring A Quantity: 1
- O-Ring B Number/Desc: Not Required
- O-Ring B Quantity: NR
- Printed Foot Note: May Require use of OE Manifold
- Pulley Belt Type: V-Belt
- Pulley Diameter MM: 133.350
- Pulley Groove Quantity: 1
- Pulley Lip Diameter: 5.250
- Pulley Outside Diameter: 5.250
- Pulley Ridge Diameter: 5.250
- Refrigerant Type: R134a
- Suction Port Type: Pad Mount
- Terminal Type: Spade
- UPC: 096361673717
- Part Description: Toyota Cressida Remanufactured A C Compressor With Clutch
Product Specifications- Other Names: Compressor Assembly
- Item Weight: 11.90 Pounds
- Replaces: 88320-35170, 88320-35161, 88320-35330, 88320-28030, 88320-14340, 88320-22300, 88320-12460, 88320-28031, 88320-22270, 88320-35220, 88320-12480, 88320-01011, 88320-28090, 88320-35160, 88320-14320, 88320-14350, 88320-60151
- Part Description: Toyota Cressida Compressor Assembly
- Product Specifications
- Item Dimensions: 11.8 x 7.1 x 7.9 inches
- Item Weight: 11.30 Pounds
- Replaces: 88320-35340, 88320-14560, 88320-60320, 88320-14520, 88320-35320, 88320-35350, 88320-14760, 88320-14521, 88320-35240, 88320-14520-84
- Part Description: Toyota Cressida Compressor
- Product Specifications
- Item Dimensions: 11.6 x 7.4 x 7.9 inches
- Item Weight: 18.80 Pounds
- Replaces: 88320-22580
- Part Description: Toyota Cressida REMAN A/C Compressor
- Product Specifications
- Item Dimensions: 11.9 x 7.4 x 8.2 inches
- Item Weight: 19.60 Pounds
- Replaces: 88320-22430
- Part Description: Toyota Cressida REMAN A/C Compressor
