Toyota Van A/C Compressor
Select vehicle to guarantee fit
Make
Model
Year
< Back to View All
A/C & Heating
- Department
- Condition
- Brands
- Prices
$168.35Product Specifications- Belt Width IN: 0.500
- Clutch Included: Yes
- Clutch Maximum Diameter: 5.625
- Coil Clock Position: Wire Lead
- Coil Voltage: 12
- Compatible Refrigerant Oil Type: PAG 46
- Compressor Type: 10P15C
- Distance From Clutch To Mounting Flange: 1.6875
- Mounting Hardware: Not Included
- Mounting Type: Tangent Mount
- New or Reman: Remanufactured
- O-Ring A Number/Desc: [24613] / Green O-Ring
- O-Ring A Quantity: 4
- O-Ring B Number/Desc: Not Required
- O-Ring B Quantity: NR
- Printed Foot Note: May Require use of OE Manifold
- Pulley Belt Type: V-Belt
- Pulley Diameter MM: 142.748
- Pulley Groove Quantity: 1
- Pulley Lip Diameter: 5.625
- Pulley Outside Diameter: 5.625
- Pulley Ridge Diameter: 5.625
- Refrigerant Type: R134a
- Reman w/o Clutch: [57310] / Clutch Assembly
- Suc Prt Typ Note: w/O-Ring
- Suction Port Type: Pad Mount
- Terminal Type: Spade
- UPC: 096361673021
- Part Description: Toyota Van Remanufactured A C Compressor With Clutch
$182.04Product Specifications- Clutch Included: Yes
- Clutch Maximum Diameter: 4.750
- Coil Clock Position: Wire Lead
- Coil Voltage: 12
- Compatible Refrigerant Oil Type: PAG 46
- Compressor Type: 10PA15C
- Distance From Clutch To Mounting Flange: 2.09375
- Mounting Hardware: Not Included
- Mounting Type: Tangent Mount
- New Compressor w/o Clutch: [58341] / Clutch Assembly
- New or Reman: Remanufactured
- O-Ring A Number/Desc: [24156] / Compressor Manifold Port Gasket
- O-Ring A Quantity: 1
- O-Ring B Number/Desc: Not Required
- O-Ring B Quantity: NR
- Printed Foot Note: May Require use of OE Manifold
- Pulley Belt Type: Serpentine
- Pulley Diameter MM: 120.650
- Pulley Groove Quantity: 4
- Pulley Lip Diameter: 4.750
- Pulley Outside Diameter: 4.750
- Pulley Ridge Diameter: 4.750
- Refrigerant Type: R134a
- Reman w/o Clutch: [57341] / Clutch Assembly
- Suction Port Type: Pad Mount
- Terminal Type: Pin
- UPC: 096361573697
- Part Description: Toyota Van Remanufactured A C Compressor With Clutch
$374.28Product Specifications- Clutch Included: Yes
- Clutch Maximum Diameter: 4.500
- Coil Clock Position: Wire Lead
- Coil Voltage: 12
- Compatible Refrigerant Oil Type: PAG 46
- Compressor Type: 10P15C
- Discharge Port Type: Pad Mount
- Distance From Clutch To Mounting Flange: 1.859375
- Mount Distance MM: 46.990
- Mounting Hardware: Not Included
- Mounting Type: Tangent Mount
- New or Reman: New
- O-Ring A Number/Desc: [24613] / Green O-Ring
- O-Ring A Quantity: 4
- O-Ring B Number/Desc: Not Required
- O-Ring B Quantity: NR
- O-Ring C Number/Desc: Not Required
- O-Ring C Quantity: NR
- Printed Foot Note: May Require use of OE Manifold
- Pulley Belt Type: V-Belt
- Pulley Diameter MM: 114.300
- Pulley Groove Quantity: 1
- Pulley Lip Diameter: 4.500
- Pulley Outside Diameter: 4.500
- Pulley Ridge Diameter: 4.500
- Refrigerant Type: R134a
- Suction Port Type: Pad Mount
- Terminal Type: Spade
- UPC: 096361683020
- Part Description: Toyota Van A C Compressor With Clutch
$174.43Product Specifications- Clutch Included: No
- Coil Clock Position: Non Clutch
- Coil Voltage: NR
- Compatible Refrigerant Oil Type: PAG 46
- Compressor Type: 10PA15C
- Mounting Hardware: Not Included
- Mounting Type: Tangent Mount
- New or Reman: New
- O-Ring A Number/Desc: [24156] / Compressor Manifold Port Gasket
- O-Ring A Quantity: 1
- O-Ring B Number/Desc: Not Required
- O-Ring B Quantity: NR
- Printed Foot Note: May Require use of OE Manifold
- Pulley Belt Type: Non-Clutch
- Pulley Groove Quantity: NR
- Refrigerant Type: R134a
- Suction Port Type: Pad Mount
- UPC: 096361583412
- Part Description: Toyota Van A C Compressor Without Clutch
$268.75Product Specifications- Clutch Included: Yes
- Clutch Maximum Diameter: 4.750
- Coil Clock Position: Wire Lead
- Coil Voltage: 12
- Compatible Refrigerant Oil Type: PAG 46
- Compressor Type: 10PA15C
- Discharge Port Type: Pad Mount
- Distance From Clutch To Mounting Flange: 1.609375
- Mount Distance MM: 40.894
- Mounting Hardware: Not Included
- Mounting Type: Tangent Mount
- New or Reman: New
- O-Ring A Number/Desc: [24156] / Compressor Manifold Port Gasket
- O-Ring A Quantity: 1
- O-Ring B Number/Desc: Not Required
- O-Ring B Quantity: NR
- O-Ring C Number/Desc: Not Required
- O-Ring C Quantity: NR
- Printed Foot Note: May Require use of OE Manifold
- Pulley Belt Type: Serpentine
- Pulley Diameter MM: 120.650
- Pulley Groove Quantity: 4
- Pulley Lip Diameter: 4.750
- Pulley Outside Diameter: 4.750
- Pulley Ridge Diameter: 4.750
- Refrigerant Type: R134a
- Suction Port Type: Pad Mount
- Terminal Type: Pin
- UPC: 096361583696
- Part Description: Toyota Van A C Compressor With Clutch
Product Specifications- Belt Type: Serpentine
- Clutch Included: Yes
- Coil Clock Position: Wire Lead
- Coil Voltage: 12V
- Connector Terminal Quantity: 2
- Connector Type: Female, 2 Blade
- Mounting Type: Bolt-tangent
- New or Remanufactured: New
- Oil in Compressor: Yes
- Oil Type: PAG
- Package Contents: O-rings/sealing washers included
- Pulley Groove Quantity: 7
- Refrigerant Type: R134A
- Switch Included: No
- Switch Service Port: No
- UPC: 689604203569
- Part Description: Toyota Van A C Compressor With Clutch
Product Specifications- Clutch Maximum Diameter: 140.0
- Compressor Mount Hole Quantity: 4
- Mounting Type: Bolt Tangent
- New or Remanufactured: Remanufactured
- Pulley Belt Type: V-Belt
- Refrigerant Type: R12
- UPC: 042511162518
- Part Description: Toyota Van Remanufactured A/C Compressor with Clutch
Product Specifications- Clutch Maximum Diameter: 140.0
- Compressor Mount Hole Quantity: 4
- Mounting Type: Bolt Tangent
- New or Remanufactured: Remanufactured
- Pulley Belt Type: V-Belt
- Refrigerant Type: R12
- UPC: 042511091368
- Part Description: Toyota Van Reman Compressor W/ Clutch
Product Specifications- Other Names: Compressor Assembly
- Item Weight: 11.90 Pounds
- Replaces: 88320-35170, 88320-35161, 88320-35330, 88320-28030, 88320-14340, 88320-22300, 88320-12460, 88320-28031, 88320-22270, 88320-35220, 88320-12480, 88320-01011, 88320-28090, 88320-35160, 88320-14320, 88320-14350, 88320-60151
- Part Description: Toyota Van Compressor Assembly
