Volkswagen Beetle Wheel Hub
Select vehicle to guarantee fit
Make
Model
Year
< Back to View All
Wheel Hubs, Bearings & Seals
- Department
- Series
- Brands
- Prices
Dorman® OE Solutions Front Passenger Side Wheel Bearing And Hub Assembly for Volkswagen Beetle
PartNumber: 686-200$179.58Product Specifications- Anti Lock Brake Sensor Included: No
- Anti Lock Braking System: Yes
- Anti Lock Braking System Type: Sensor
- Bolt Circle Diameter: 100 mm
- Brake Pilot Diameter: 65 mm
- Flange Bolt Hole Diameter: 100 mm
- Flange Bolt Hole Quantity: 5
- Flange Bolts Included: No
- Flange Diameter: 126 mm
- Flange Included: Yes
- Flange Offset: 44.7 mm
- Flange Shape: Circular
- Hub Pilot Diameter: 40 mm
- Package Contents: 1 load Knuckle
- Spline Quantity: 36
- UPC: 889245539007
- Wheel Pilot Diameter: 57 mm
- Wheel Stud Quantity: 5
- Wheel Stud Size: M14-1.5
- Wheel Studs Included: Yes
- Part Description: Volkswagen Beetle OE Solutions Front Passenger Side Wheel Bearing And Hub Assembly
$114.54Product Specifications- Inner Diameter: 1.2598"
- UPC: 085311446716
- Part Description: Volkswagen Beetle Rear Driver Side Wheel Bearing And Hub Assembly
$83.82Product Specifications- Flange Diameter (Inch): 5.373
- Gasket or Seal Included: Yes
- Greaseable: No
- Hub Pilot Diameter (Inch): 3.12
- Material: Steel
- Product Condition: New
- Stud Quantity: 5
- UPC: 029175926588
- Wheel Stud Size MM: M14 x 1.5
- Wiring Harness Included: No
- Part Description: Volkswagen Beetle WHEEL BEARING AND HUB ASSEMBLY
$29.15Product Specifications- Bolt Hole Circle Diameter [mm]: 100
- Braking / Drive Dynamics: for vehicles with ABS
- Diameter [mm]: 40
- Drive Shaft: with ABS ring
- Height [mm]: 75
- Number of Holes: 5
- Packaging height [cm]: 12,1
- Packaging width [cm]: 16,4
- Quantity per Axle: 2
- Rim Hole Number: 5
- Supplementary Article/Supplementary Info: without add-on material
- Weight [kg]: 1,683
- Part Description: Volkswagen Beetle Front Driver or Passenger Side Wheel Hub
$24.83Product Specifications- Hub Material: Steel
- Hub Pilot Diameter: 1.575"
- Lug Pattern: 5
- Package Contents: Wheel Hub
- UPC: 019495213451
- Wheel Pilot Diameter: 4.992"
- Part Description: Volkswagen Beetle OE Solutions Front Passenger Side Wheel Hub
$134.64Product Specifications- Bolt Circle Diameter A: 4.4094"
- Bolt Circle Diameter B: 4.2125"
- Bolt Hole Size: M12x1.5
- Bolt Size: M14x1.5
- Flange Diameter: 5.3740"
- Flange Offset: 1.8897"
- Inner Diameter: 1.0039"
- Number of Bolts: 5
- Number of Holes: 5
- Number of Splines: 36
- Sensor Ring: Yes
- UPC: 085311446723
- Wheel Pilot Diameter: 2.2440"
- Part Description: Volkswagen Beetle Front Passenger Side Wheel Bearing And Hub Assembly
$68.94Product Specifications- Flange Diameter (Inch): 5.385
- Gasket or Seal Included: Yes
- Greaseable: No
- Hub Pilot Diameter (Inch): 3.346
- Material: Steel
- Product Condition: New
- Spline Quantity: 36
- Stud Quantity: 5
- UPC: 029175924164
- Wheel Stud Size MM: M14 x 1.5
- Wiring Harness Included: No
- Part Description: Volkswagen Beetle WHEEL BEARING AND HUB ASSEMBLY
$71.78Product Specifications- Inner Diameter: 1.1811"
- UPC: 085311260176
- Part Description: Volkswagen Beetle Rear Driver Side Wheel Bearing And Hub Assembly
$53.93Product Specifications- Flange Diameter (Inch): 5.373
- Gasket or Seal Included: Yes
- Greaseable: No
- Hub Pilot Diameter (Inch): 3.131
- Material: Steel
- Product Condition: New
- Stud Quantity: 5
- UPC: 029175926410
- Wheel Stud Size MM: M14 x 1.5
- Wiring Harness Included: No
- Part Description: Volkswagen Beetle WHEEL BEARING AND HUB ASSEMBLY
$40.66Product Specifications- Flange Diameter (Inch): 4.725
- Gasket or Seal Included: Yes
- Greaseable: No
- Material: Steel
- Product Condition: New
- Stud Quantity: 5
- UPC: 029175928674
- Wheel Stud Size MM: M14 x 1.5
- Wiring Harness Included: No
- Part Description: Volkswagen Beetle WHEEL BEARING AND HUB ASSEMBLY
Centric® Premium™ Rear Passenger Side Wheel Bearing and Hub Assembly for Volkswagen Beetle
PartNumber: 400.33000Product Specifications- UPC: 805890562764
- Part Description: Volkswagen Beetle Premium™ Rear Passenger Side Wheel Bearing and Hub Assembly
Centric® Premium™ Rear Driver Side Wheel Bearing and Hub Assembly for Volkswagen Beetle
PartNumber: 405.33003Product Specifications- UPC: 805890565161
- Part Description: Volkswagen Beetle Premium™ Rear Driver Side Wheel Bearing and Hub Assembly
Centric® Premium™ Rear Driver Side Wheel Bearing and Hub Assembly for Volkswagen Beetle
PartNumber: 405.33004Product Specifications- UPC: 805890565178
- Part Description: Volkswagen Beetle Premium™ Rear Driver Side Wheel Bearing and Hub Assembly
Centric® Premium™ Rear Non-Driven Wheel Bearing and Hub Assembly for Volkswagen Beetle
PartNumber: 406.33000Product Specifications- UPC: 805890566526
- Part Description: Volkswagen Beetle Premium™ Rear Non-Driven Wheel Bearing and Hub Assembly
