Notes: This Fuel System Requires more than one Fuel Pump. System Requires In-Tank Low Pressure Fuel Pump(s) & In-Line High Pressure Fuel Pump;1 Mounted In Tank;2 Fuel Pumps may be Required - 1 Externally Mounted &
Average Current Draw(A): 2.5
Average Flow Rating(GPH): 29
Connector Gender: Male
Connector Quantity: 1
Connector Shape: Elliptic
Country of Orign: China
Fuel Filter Included: No
Fuel Sending Unit Included: Yes
Fuel Tank Pressure Sensor Included: No
Gasket or Seal Included: Yes
Gasket Or Seal Material: NBR
Grade Type: Performance
In Tank or External: In Tank
Inlet Size: 0.311
Installation Warnings: No
Internal Or External Strainer: External
Mounting Hardware Included: No
Negative Ground: No
Outlet Quantity: 1
Outlet Size: 0.374
Outlet Type: Hose Bead
Product Height (in): 3.69
Product Length (in): 7.95
Product Width (in): 3.69
Pump Type: Turbine
Regulator Included: No
Resistance Ohms Empty: 70
Resistance Ohms Full: 10
Strainer Included: Yes
Terminal Gender: Male
Terminal Quantity: 4
Terminal Type: PIN
UPC: 00072845110077
Voltage: 12V
Weight (lbs): 1.16
Wire Harness Included: No
Part Description: 1988 Ford Ranger Fuel Pump And Sender Assembly
Notes: with Midship Tank;Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Autobest recommends cleaning the fuel tank before installing a new pump.
Current Draw: 6
Flow Rating: 29 gph
Fuel Level Sender Assembly Included: Yes
Fuel Type: Gas
Gasket or Seal Included: Yes
In Tank or External: In Tank
Inlet Type: Strainer
Internal or External Strainer: External
Item Grade: Standard Replacement
Maximum Pressure: 6.5 PSI
Outlet Outside Diameter: 0.375''
Outlet Quantity: 2
Outlet Type: Quick Connect
Pump Type: Electric
Resistance Ohms Empty: 70.0
Resistance Ohms Full: 10.0
Strainer Included: Yes
System Pressure: 4.5 psi
Terminal Gender: Male
Terminal Quantity: 4
Terminal Type: Pin
UPC: 689604226636
Voltage: 12.0 VDC
Part Description: 1988 Ford Ranger Fuel Pump Hanger Assembly
Notes: with Aft Axle Tank;Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Autobest recommends cleaning the fuel tank before installing a new pump.
Current Draw: 7
Flow Rating: 29 gph
Fuel Level Sender Assembly Included: Yes
Fuel Type: Gas
Gasket or Seal Included: Yes
In Tank or External: In Tank
Inlet Type: Strainer
Internal or External Strainer: External
Item Grade: Standard Replacement
Maximum Pressure: 6.5 PSI
Outlet Outside Diameter: 0.375''
Outlet Quantity: 2
Outlet Type: Quick Connect
Pump Type: Electric
Resistance Ohms Empty: 70.0
Resistance Ohms Full: 10.0
Strainer Included: Yes
System Pressure: 4.5 psi
Terminal Gender: Male
Terminal Quantity: 4
Terminal Type: Pin
UPC: 689604226650
Voltage: 12.0 VDC
Part Description: 1988 Ford Ranger Fuel Pump Hanger Assembly
Notes: 2 Fuel Pumps may be Required - 1 Externally Mounted & 1 Mounted In Tank;Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Autobest recommends cleaning the fuel tank before installing a new pump.
Current Draw: 5
Flow Rating: 28 gph
Fuel Type: Gas
Gasket or Seal Included: No
In Tank or External: External
Inlet Outside Diameter: 0.313''
Inlet Type: Quick Connect
Item Grade: Standard Replacement
Maximum Pressure: 99.0 PSI
Outlet Outside Diameter: 0.313''
Outlet Type: Quick Connect
Pump Type: Electric
Strainer Included: No
System Pressure: 44 psi
Terminal Gender: Male
Terminal Quantity: 2
Terminal Type: Threaded
UPC: 689604032619
Voltage: 12 VDC
Wiring Harness Included: No
Part Description: 1988 Ford Ranger In Line Electric Fuel Pump
Notes: Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Autobest recommends cleaning the fuel tank before installing a new pump.
Current Draw: 2
Flow Rating: 29 gph
Fuel Type: Gas
Gasket or Seal Included: Yes
In Tank or External: In Tank
Inlet Type: Strainer
Item Grade: Standard Replacement
Maximum Pressure: 6.5 PSI
Outlet Outside Diameter: 0.375''
Outlet Type: Straight
Pump Type: Electric
Strainer Included: No
System Pressure: 5 psi
Terminal Gender: Male
Terminal Quantity: 2
Terminal Type: Threaded
UPC: 689604033333
Voltage: 12 VDC
Wiring Harness Included: No
Part Description: 1988 Ford Ranger In Tank Electric Fuel Pump
Notes: Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Autobest recommends cleaning the fuel tank before installing a new pump.
Item Grade: Standard Replacement
Micron Rating: 60
Strainer Material: Saran
UPC: 689604062067
Part Description: 1988 Ford Ranger Fuel Pump Strainer
