1992 Saab 9000 A/C & Heating
My Vehicle Change Vehicle
1992 Saab 9000
Product Specifications- Notes: w/ SD709 Compressor; Reman w/ Clutch
- Clutch Included: Yes
- Clutch Maximum Diameter: 5.250
- Coil Clock Position: Wire Lead
- Coil Voltage: 12
- Comp Head Prt Config: Top-Vert-Pad
- Compatible Refrigerant Oil Type: PAG 100
- Compressor Head Type: QU
- Compressor Type: SD709
- Discharge Port Type: O-Ring
- Distance From Clutch To Mounting Flange: 1.34375
- Mounting Hardware: Not Included
- Mounting Type: Tangent Mount
- New or Reman: Remanufactured
- O-Ring A Number/Desc: [24615] / Green O-Ring
- O-Ring A Quantity: 2
- O-Ring B Number/Desc: Not Required
- O-Ring B Quantity: NR
- Pulley Belt Type: Serpentine
- Pulley Diameter MM: 133.350
- Pulley Groove Quantity: 6
- Pulley Lip Diameter: 5.250
- Pulley Outside Diameter: 5.250
- Pulley Ridge Diameter: 5.250
- Refrigerant Type: R134a
- Suction Port Type: O-Ring
- Terminal Type: Bullet
- UPC: 096361675582
- Part Description: 1992 Saab 9000 Remanufactured A C Compressor With Clutch
Vehicle Fitment- 1992 Saab 9000 | All Trims | All Engines
Product Specifications- Connector Pin Qty: 4
- Connector Shape: Other design
- Gender: Female
- Style: Harness Connector
- Terminal Gender: Female
- Terminal Quantity: 4
- UPC: 096361098336
- Wire Length IN: 6.000
- Part Description: 1992 Saab 9000 A C Clutch Control Relay Harness Connector
Vehicle Fitment- 1992 Saab 9000 | All Trims | All Engines
Product Specifications- Body Diameter: 3.000
- Body Length: 5.500
- Bracket: w/ Bracket
- Connector B Type: Male Insert O-Ring
- Connector Type: Male Insert O-Ring
- Desiccant: Yes
- Desiccant Replaceable: Not Replaceable
- Dia. MM: 76.200
- Fuse Plug: No
- Gasket / Seals: Included
- In Line Filter Material: Desiccant
- In Line Filter Outlet Fitting Type: Male
- Inlet Filter Fitting Thread Diameter: 0.625
- Inlet Filter Fitting Type: Male
- Inlet Fitting Diameter: 0.375
- Inlet Fitting Type: Male Insert O-Ring
- Inlet Fraction: 3/8
- Inlet IN: 0.375
- Inlet MM: 9.525
- Length MM: 139.700
- Material: Steel
- Meets / Exceeds OEM: Yes
- Moisture Indicator Window: No
- Mounting Bracket Included: Hardware not included
- New or Reman: New
- O-Ring A Number/Desc: [24606] / Green O-Ring
- O-Ring A Quantity: 2
- Outlet Fitting Type: Male Insert O-Ring
- Outlet Fraction: 3/8
- Outlet IN: 0.375
- Outlet MM: 9.525
- Overall Depth IN: 5.500
- P. R. V.: No
- Service Port: w/o Service Port
- Sight Glass: Yes
- Stud: No
- Style: Steel Filter Drier
- Switch Port: w/o Switch Port
- UPC: 096361336599
- Part Description: 1992 Saab 9000 A C Receiver Drier
Vehicle Fitment- 1992 Saab 9000 | All Trims | All Engines
Product Specifications- Color: Aluminum
- Liquid Inlet Fitting Gender: Female
- Liquid Inlet Fitting Thread Diameter: No. 6
- Liquid Inlet Style: FIO
- Liquid Inlet Type: Insert O-Ring
- Liquid Outlet Fitting Gender: Female
- Liquid Outlet Fitting Thread Diameter: No. 8
- Liquid Outlet Style: FIO
- Liquid Outlet Type: Insert O-Ring
- Material: Aluminum
- Meets / Exceeds OEM: Yes
- Mounting Hole Quantity: 2
- O-Ring A Number/Desc: [24606] / Green O-Ring
- O-Ring A Quantity: 1
- O-Ring B Number/Desc: [24608] / Green O-Ring
- O-Ring B Quantity: 1
- O-Ring C Number/Desc: [24610] / Green O-Ring
- O-Ring C Quantity: 1
- O-Ring D Number/Desc: [24612] / Green O-Ring
- O-Ring D Quantity: 1
- Refrigerant Type: R134A
- Style: w/o Solenoid
- Suction Inlet Fitting Gender: Female
- Suction Inlet Fitting Thread Diameter: No. 10
- Suction Inlet Style: FIO
- Suction Inlet Type: Insert O-Ring
- Suction Outlet Fitting Gender: Female
- Suction Outlet Fitting Thread Diameter: No. 12
- Suction Outlet Style: FIO
- Suction Outlet Type: Insert O-Ring
- Super Heat: 8.000
- Switch Included: Not Included
- Tonnage: 1.700
- UPC: 096361387720
- Part Description: 1992 Saab 9000 A C Expansion Valve
Vehicle Fitment- 1992 Saab 9000 | All Trims | All Engines
Product Specifications- Notes: Caps and Valve Core Seal Kit; w/ R12 or R134a Retrofit System
- Cap Color: Red, Blue, Black
- Cap Inside Diameter: Specific
- Cap Material: Plastic
- Material: Aluminum
- Refrigerant Type: R12, R134a
- Style: Cap & Valve Kit
- UPC: 096361267770
- Valve Core Material: Specific
- Part Description: 1992 Saab 9000 A C System Valve Core And Cap Kit
Vehicle Fitment- 1992 Saab 9000 | All Trims | All Engines
Product Specifications- Core Depth Fraction: 3-1/4; 3-1/8
- Core Depth MM: 79.375; 82.550
- Core Height Fraction: 11; 12-1/8
- Core Height MM: 279.400; 307.975
- Core Width Fraction: 9
- Core Width MM: 228.600
- Depth: 3.125; 3.250
- Height: 11.000; 12.125
- Inlet Fitting Outside Diameter: No. 8
- Material: Aluminum
- O-Ring A Number/Desc: [24604] / Green O-Ring
- O-Ring A Quantity: 1
- O-Ring B Number/Desc: [24608] / Green O-Ring
- O-Ring B Quantity: 1
- O-Ring C Number/Desc: [24610] / Green O-Ring
- O-Ring C Quantity: 1
- Outlet Fitting Outside Diameter: No. 10
- UPC: 096361546370
- Width: 9.000
- Part Description: 1992 Saab 9000 A C Evaporator Core
Vehicle Fitment- 1992 Saab 9000 | All Trims | All Engines
Product Specifications- Notes: For AC; OE Recommended Replacement filter; Premium electrostatically charged media; Captures ultra-fine particulates such as diesel carbon & smoke
- Filter Media Material: ELECTROSTATIC PARTICULATE
- Height: 1.1
- Length: 9.6
- Reusable: No
- UPC: 042511106987
- Width: 11.11
- Part Description: 1992 Saab 9000 Cabin Air Filter
Vehicle Fitment- 1992 Saab 9000 | All Trims | 4 Cyl 2.3L
Product Specifications- Notes: w/Sandend SD-709 AC Compressor
- Part Description: 1992 Saab 9000 A/C Compressor Clutch Ball Bearing
Vehicle Fitment- 1992 Saab 9000 | All Trims | All Engines
