32 products about 1996 Isuzu Hombre A/C & Heating found
Filter Results
Sort
View by
Product Specifications- Notes: Cut to Length, 3"
- Centerline Length: 50 ft
- End 1 Inside Diameter: 19 mm
- End 2 Inside Diameter: 19 mm
- Material: EPDM
- OE Part Number: 49693
- UPC: 072053066326
- Weight Per Length: 13.20 lbs./Carton
- Working Pressure: 50 PSI
- Part Description: 1996 Isuzu Hombre Safety Stripe Hvac Heater Hose
More Info Vehicle Fitment- 1996 Isuzu Hombre | All Trims | 4 Cyl 2.2L
Product Specifications- Notes: w/ V5 Compressor; Reman w/ Clutch
- Clutch Included: Yes
- Clutch Maximum Diameter: 4.250
- Coil Clock Position: 2
- Coil Voltage: 12
- Compatible Refrigerant Oil Type: PAG 150
- Compressor Type: V5
- Distance From Clutch To Mounting Flange: 1.15625
- Mounting Hardware: Not Included
- Mounting Type: Ear Mount
- New or Reman: Remanufactured
- O-Ring A Number/Desc: [24354] / Sealing Washer
- O-Ring A Quantity: 2
- O-Ring B Number/Desc: Not Required
- O-Ring B Quantity: NR
- Pulley Belt Type: Serpentine
- Pulley Diameter MM: 107.950
- Pulley Groove Quantity: 6
- Pulley Lip Diameter: 4.250
- Pulley Outside Diameter: 4.250
- Pulley Ridge Diameter: 4.250
- Refrigerant Type: R134a
- Suc Prt Typ Note: w/ 5/8" x 5/8" Ports
- Suction Port Type: Sealing Washer
- Terminal Type: 8mm Pin Connector
- UPC: 096361579934
- Part Description: 1996 Isuzu Hombre Remanufactured A C Compressor With Clutch
More Info Vehicle Fitment- 1996 Isuzu Hombre | All Trims | All Engines
Product Specifications- Color: Black
- Contains Heat Shield: N
- Contains Protective Sleeve: N
- End 1 Inside Diameter: 5/8
- End 2 Inside Diameter: 3/4
- Hose Type: Dual I.D. Hose
- Material: EPDM
- SAE Specification: SAE J20R3 Class D-1, SAE J1684 Type EC
- Trunk Height: 60
- UPC: 038244598021
- Part Description: 1996 Isuzu Hombre Small Id Hvac Heater Hose
More Info Vehicle Fitment- 1996 Isuzu Hombre | All Trims | All Engines
Product Specifications- Notes: Cut to fit
- Centerline Length (in): 9.6"
- Inside Diameter 1 (in): 0.62"
- Inside Diameter 2 (in): 0.75"
- Number of Branches: 0
- UPC: 072053178173
- Part Description: 1996 Isuzu Hombre Hvac Heater Molded Hose
More Info Vehicle Fitment- 1996 Isuzu Hombre | All Trims | 4 Cyl 2.2L
Product Specifications- Box Height (in): 8
- Box Length (in): 34 2/3
- Box Weight (lbs): 10
- Box Width (in): 18
- Construction: parallel flow
- Core Length: 26 1/2
- Core Thickness: 5/7
- Core Width: 14 2/7
- Hazardous Material: No
- Inlet Tube: Thread
- OE Part Number: 52474647, GM3030156, 5047 4647
- Outlet Tube: Thread
- UPC: 710353106006
- Part Description: 1996 Isuzu Hombre A/C Condenser
More Info Vehicle Fitment- 1996 Isuzu Hombre | All Trims | 4 Cyl 2.2L
Product Specifications- Notes: Cut to fit
- Angle: 90
- Arm Length 1 (in): 8"
- Arm Length 2 (in): 18"
- Centerline Length (in): 26"
- Inside Diameter 1 (in): 0.625"
- UPC: 072053062038
- Part Description: 1996 Isuzu Hombre 90 Degree Hvac Heater Molded Hose
More Info Vehicle Fitment- 1996 Isuzu Hombre | All Trims | 4 Cyl 2.2L
Product Specifications- Notes: w/ V5 Compressor; New
- Belt Type: Serpentine
- Belt Width IN: 0.875
- Can Size: w/ Coil
- Clutch Maximum Diameter: 4.250
- Coil: w/ Coil
- Coil Number: [48257] / Clutch Assembly
- Coil Voltage: 12
- Color: Black
- Groove: 6
- Lead Wire : Lead Wires
- Material: Steel
- Meets / Exceeds OEM: Yes
- Mounting Type: Press Fit
- Pulley Number: [48222] / Clutch Assembly
- Rotation: CCW-CW
- Style: Harrison V5 Variable Displacement
- Thermal Or Non Thermal: NR
- UPC: 096361476547
- Part Description: 1996 Isuzu Hombre A C Compressor Clutch
More Info Vehicle Fitment- 1996 Isuzu Hombre | All Trims | All Engines
Product Specifications- Core Depth Fraction: 2-7/8; 4
- Core Depth MM: 101.600; 73.025
- Core Height Fraction: 9-1/2; 9-3/8
- Core Height MM: 238.125; 241.300
- Core Width Fraction: 13-1/2; 13-3/8; 13-7/16
- Core Width MM: 339.725; 342.900
- Depth: 2.875; 4.000
- Height: 9.375; 9.500
- Material: Aluminum
- O-Ring A Number/Desc: [24608] / Green O-Ring
- O-Ring A Quantity: 1
- O-Ring B Number/Desc: [24612] / Green O-Ring
- O-Ring B Quantity: 1
- O-Ring C Number/Desc: [38623] / Orifice Tube
- O-Ring C Quantity: 1
- Outlet Fitting Outside Diameter: No. 12
- UPC: 096361545977
- Width: 13.375; 13.4375; 13.500
- Part Description: 1996 Isuzu Hombre A C Evaporator Core
More Info Vehicle Fitment- 1996 Isuzu Hombre | All Trims | All Engines
Product Specifications- Notes: w/Wheel; w/Molded Vent Tube; w/AC
- Cage Wheel Included: w/ Wheel
- Connector Gender: Female
- Connector qty: 1
- Flanged End: Yes
- Material: Metal
- Motor Diameter: 3.250
- Motor Length: 4.3125
- Mount Type: OE Mount
- New or Reman: New
- Number of Terminals: 2
- O.E. Replacement: Yes
- Rotation: CW
- Shaft Diameter: 0.3125
- Shaft Length: 1.3125
- Style: Flanged
- Terminal Type: 2 Terminal Connector
- UPC: 096361757639
- Vented: Vented
- Voltage: 12
- Wheel Dia. IN: 5.750
- Wheel Height IN: 3.625
- Part Description: 1996 Isuzu Hombre Hvac Blower Motor With Wheel
More Info Vehicle Fitment- 1996 Isuzu Hombre | All Trims | All Engines
Product Specifications- Notes: w/o ATC
- Connector Shape: Rectangle
- Gender: Male
- Style: Harness Connector
- Terminal Gender: Female
- Terminal Pin Qty.: 6
- Terminal Quantity: 6
- Terminal Type: Pin
- UPC: 096361007949
- Wiring Harness Length: 12.000
- Part Description: 1996 Isuzu Hombre Hvac Heater Blend Door Actuator Connector
More Info Vehicle Fitment- 1996 Isuzu Hombre | All Trims | All Engines
Product Specifications- Notes: w/Wheel; w/o Molded Vent Tube; w/AC
- Cage Wheel Included: w/ Wheel
- Connector Gender: Female
- Connector qty: 1
- Flanged End: Yes
- Material: Metal
- Motor Diameter: 3.250
- Motor Length: 4.3125
- Mount Type: OE Mount
- New or Reman: New
- Number of Terminals: 2
- O.E. Replacement: Yes
- Rotation: CW
- Shaft Diameter: 0.3125
- Shaft Length: 1.3125
- Style: Flanged
- Terminal Type: 2 Terminal Connector
- UPC: 096361353442
- Vented: Vented
- Voltage: 12
- Wheel Dia. IN: 5.750
- Wheel Height IN: 3.625
- Part Description: 1996 Isuzu Hombre Hvac Blower Motor With Wheel
More Info Vehicle Fitment- 1996 Isuzu Hombre | All Trims | All Engines
Product Specifications- Notes: w/o ATC
- Door Linkage: Female
- Mounting Ear Qty.: 3
- Style: Recirculation Door Actuator
- Terminal Pin Qty.: 5
- UPC: 096361730076
- Wire Quantity: Not Applicable
- Part Description: 1996 Isuzu Hombre Hvac Heater Blend Door Actuator
More Info Vehicle Fitment- 1996 Isuzu Hombre | All Trims | All Engines
Product Specifications- Notes: Harness Connector-Repair
- Connector Shape: Round
- Gender: Male
- Printed Foot Note: Harness Connector
- Style: Harness Connector
- Terminal Gender: Female
- Terminal Quantity: 3
- UPC: 096361372368
- Part Description: 1996 Isuzu Hombre Coolant Temperature Sensor Connector
More Info Vehicle Fitment- 1996 Isuzu Hombre | All Trims | All Engines
Product Specifications- Notes: Blower Motor Relay Connector; 5 Term.;Compressor Relay Connector; 5 Term.;Blower Motor Relay Connector; 4 Term.
- Connector Pin Qty: 5
- Connector Shape: Square
- Gender: Male
- Printed Foot Note: Harness Connector for 5 Terminal Relay
- Style: Harness Connector
- Terminal Gender: Female
- Terminal Quantity: 5
- UPC: 096361372320
- Part Description: 1996 Isuzu Hombre A C Clutch Control Relay Harness Connector
More Info Vehicle Fitment- 1996 Isuzu Hombre | All Trims | All Engines
Product Specifications- Notes: w/V5 Compressor; Harness Connector-Repair
- Connector Pin Qty: 2
- Connector Shape: Other design
- Connector Type: Pin
- Gender: Male
- Printed Foot Note: Coil Harness w/ Diode
- Style: Harness Connector
- Terminal Gender: Female
- Terminal Quantity: 2
- UPC: 096361372153
- Part Description: 1996 Isuzu Hombre A C Compressor Wiring Harness
More Info Vehicle Fitment- 1996 Isuzu Hombre | All Trims | All Engines
Product Specifications- Notes: Optional Auto Adjusting Orifice Tube For Severe Climates Over 105 Degrees
- Color: White
- Pack in Qty of: 1
- Style: AAOT
- UPC: 096361389045
- Part Description: 1996 Isuzu Hombre A C Orifice Tube
More Info Vehicle Fitment- 1996 Isuzu Hombre | All Trims | All Engines
Product Specifications- Notes: Caps and Valve Core Seal Kit; w/ JRA Valves
- Cap Color: Red, Blue
- Cap Inside Diameter: Specific
- Cap Material: Plastic
- Material: Aluminum
- Refrigerant Type: R12, R134a
- Style: Cap & Valve Kit
- UPC: 096361267831
- Valve Core Material: Specific
- Part Description: 1996 Isuzu Hombre A C System Valve Core And Cap Kit
More Info Vehicle Fitment- 1996 Isuzu Hombre | All Trims | All Engines
Product Specifications- Notes: w/V5 Compressor; Harness Connector-Extender
- Connector B Gender: Female
- Connector B Shape: Oval
- Connector B Type: Pin
- Connector Shape: Oval
- Connector Type: Pin
- Printed Foot Note: Wire Harness Connector
- Style: Harness Connector Adapter
- UPC: 096361372337
- Wire Length IN: 6.000
- Wire Length MM: 152.400
- Part Description: 1996 Isuzu Hombre Harness Connector Adapter
More Info Vehicle Fitment- 1996 Isuzu Hombre | All Trims | All Engines
Product Specifications- Notes: w/V5 Compressor; Harness Connector-Conversion
- Connector B Gender: Female
- Connector B Shape: Rectangle
- Connector Shape: Rectangle
- Connector Type: Pin
- Gender: Male
- Printed Foot Note: Harness Connector Adapter
- Style: Harness Connector Adapter
- Terminal Gender: Female
- Terminal Quantity: 2
- UPC: 096361372184
- Wire Length IN: 6.000
- Part Description: 1996 Isuzu Hombre Harness Connector Adapter
More Info Vehicle Fitment- 1996 Isuzu Hombre | All Trims | All Engines
Product Specifications- Notes: Optional Auto Adjusting Orifice Tube For Normal Climates Under 105 Degrees
- Color: Red
- Pack in Qty of: 1
- Style: AAOT
- UPC: 096361389021
- Part Description: 1996 Isuzu Hombre A C Orifice Tube
More Info Vehicle Fitment- 1996 Isuzu Hombre | All Trims | All Engines
Product Specifications- Notes: O-Ring and Gasket Seal Kit
- Material: Green O-Rings, Black Aluminum Gaskets
- Style: O-Ring & Gasket Kit
- UPC: 096361267428
- Part Description: 1996 Isuzu Hombre A C System O Ring And Gasket Kit
More Info Vehicle Fitment- 1996 Isuzu Hombre | All Trims | All Engines
Product Specifications- Notes: OE Replacement; Single Tube
- Color: White
- Orifice Dia. IN: 0.072
- Orifice Dia. MM: 1.803 to 1.854
- Pack in Qty of: 1
- Printed Foot Note: Optional AAOT Part No. [38902], For climates above 105Deg use (Severe Duty) AAOT [38904]; Bulk Package of 10 [623]; Bulk Package of 25 [8623].
- Style: Standard
- UPC: 096361386235
- Part Description: 1996 Isuzu Hombre A C Orifice Tube
More Info Vehicle Fitment- 1996 Isuzu Hombre | All Trims | All Engines
Product Specifications- Notes: Bulk Pkg of 25 Orifice Tubes
- Color: White
- Orifice Dia. IN: 0.071 to 0.073
- Orifice Dia. MM: 1.803 to 1.854
- Style: Standard
- UPC: 096361086234
- Part Description: 1996 Isuzu Hombre White Orifice Tube 25 pkg
More Info Vehicle Fitment- 1996 Isuzu Hombre | All Trims | All Engines
Product Specifications- Notes: (Condenser Only; Drier Not Incld)
- Color / Finish: Silver or Black
- Fitting 1 Gender: Female
- Fitting 2 Gender: Female
- Height: 14.125
- Installation Instructions Included: No
- Internet Product Code (IPC): F123919CA24
- Item Grade: OEM Standard
- Item has MSDS (SDS): N
- Material: Aluminum
- MFG Brand Name: Spectra Premium
- MFG Model # (Series): 7-4560
- MFG Name: Spectra Premium Industries
- Package Contents: 1 x Condenser
- Product Condition: New
- Refrigerant Compatibility: All
- Supplier Company Name: Spectra Premium Industries
- UPC: 671607167313
- Part Description: 1996 Isuzu Hombre A/C Condenser
More Info Vehicle Fitment- 1996 Isuzu Hombre | All Trims | All Engines
Product Specifications- Notes: Bulk Pkg of 10 Orifice Tubes
- Color: White
- Orifice Dia. IN: 0.071 to 0.073
- Orifice Dia. MM: 1.803 to 1.854
- Style: Standard
- UPC: 096361006232
- Part Description: 1996 Isuzu Hombre White Orifice Tube 10 pkg
More Info Vehicle Fitment- 1996 Isuzu Hombre | All Trims | All Engines
Product Specifications- Body Diameter: 3.500
- Body Length: 8.000
- Dia. MM: 88.900
- Inlet Fitting Diameter: 3/4
- Inlet Fitting Type: Dual O-Ring
- Inlet Thread Size: M27x2.000
- Length MM: 203.200
- Material: Aluminum
- Meets / Exceeds OEM: Yes
- Mounting Hardware: Hardware not included.
- O-Ring A Number/Desc: [24222] / Spring
- O-Ring A Quantity: 1
- O-Ring B Number/Desc: [24672] / Green O-Ring
- O-Ring B Quantity: 3
- O-Ring C Number/Desc: [24612] / Green O-Ring
- O-Ring C Quantity: 2
- Outlet Fitting Type: Male Insert O-Ring
- Outlet Fraction: 3/4
- Outlet Thread Size: M27x2.000
- Style: Complete Unit
- Switch: w/o Switch Port
- Switch Service Port: w/o Service Port
- UPC: 096361331365
- Part Description: 1996 Isuzu Hombre A C Accumulator
More Info Vehicle Fitment- 1996 Isuzu Hombre | All Trims | All Engines
Product Specifications- Notes: w/Wheel; w/o Molded Vent Tube; w/o AC; Vent tube may be Reqd if the OE motor has a molded vent tube.
- Cage Wheel Included: w/ Wheel
- Connector Gender: Female
- Connector qty: 1
- Flanged End: Yes
- Material: Metal
- Motor Diameter: 3.250
- Motor Length: 4.3125
- Mount Type: OE Mount
- New or Reman: New
- Number of Terminals: 2
- O.E. Replacement: Yes
- Rotation: CW
- Shaft Diameter: 0.3125
- Shaft Length: 1.3125
- Style: Flanged
- Terminal Type: 2 Terminal Connector
- UPC: 096361354067
- Vented: Vented
- Voltage: 12
- Wheel Dia. IN: 5.750
- Wheel Height IN: 2.750
- Part Description: 1996 Isuzu Hombre Hvac Blower Motor With Wheel
More Info Vehicle Fitment- 1996 Isuzu Hombre | All Trims | All Engines
Product Specifications- Notes: w/ V5 Compressor; New w/ Clutch
- Clutch Included: Yes
- Clutch Maximum Diameter: 4.250
- Coil Clock Position: 2
- Coil Voltage: 12
- Compatible Refrigerant Oil Type: PAG 150
- Compressor Type: V5
- Discharge Port Type: Sealing Washer
- Distance From Clutch To Mounting Flange: 1.15625
- Mount Distance MM: 29.210
- Mounting Hardware: Not Included
- Mounting Type: Ear Mount
- New or Reman: New
- O-Ring A Number/Desc: [24354] / Sealing Washer
- O-Ring A Quantity: 2
- O-Ring B Number/Desc: Not Required
- O-Ring B Quantity: NR
- O-Ring C Number/Desc: Not Required
- O-Ring C Quantity: NR
- Pulley Belt Type: Serpentine
- Pulley Diameter MM: 107.950
- Pulley Groove Quantity: 6
- Pulley Lip Diameter: 4.250
- Pulley Outside Diameter: 4.250
- Pulley Ridge Diameter: 4.250
- Refrigerant Type: R134a
- Suction Port Type: Sealing Washer
- Terminal Type: 8mm Pin Connector
- UPC: 096361589933
- Part Description: 1996 Isuzu Hombre A C Compressor With Clutch
More Info Vehicle Fitment- 1996 Isuzu Hombre | All Trims | All Engines
Product Specifications- Notes: w/ V5 Compressor; Reman
- Belt Type: Serpentine
- Belt Width IN: 0.875
- Can Size: w/ Coil
- Clutch Maximum Diameter: 4.250
- Coil: w/ Coil
- Coil Number: [48257] / Clutch Assembly
- Coil Voltage: 12
- Color: Black
- Groove: 6
- Lead Wire : One Piece Coil
- Material: Steel
- Meets / Exceeds OEM: Yes
- Mounting Type: Press Fit
- Pulley Number: [48222] / Clutch Assembly
- Rotation: CCW-CW
- Style: Harrison V5 Variable Displacement
- Thermal Or Non Thermal: NR
- UPC: 096361486546
- Part Description: 1996 Isuzu Hombre Reman GM Harrison V5 Variable Displacement Clutch Assembly w/ Coil
More Info Vehicle Fitment- 1996 Isuzu Hombre | All Trims | All Engines
Product Specifications- Notes: w/Harrison HT-6 AC Compressor;w/Harrison V-5 AC Compressor
- Bore (in): 1.574
- Bore (mm): 39.987
- Design: Double Row Angular Contact
- Inner Race Radius (in): 0.040
- Inner Race Radius (mm): 1.016
- Outside Diameter (In): 2.441
- Outside Diameter (mm): 62.004
- Series: SPECIAL
- Type: D-3
- Width (in): 0.812
- Width (mm): 20.625
- Part Description: 1996 Isuzu Hombre A/C Compressor Bearing
More Info Vehicle Fitment- 1996 Isuzu Hombre | All Trims | All Engines
