Product Specifications- Notes: with California Emission System;with Steel Cover;Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
- Current Draw: 7
- Flow Rating: 50 gph
- Fuel Level Sender Assembly Included: Yes
- Fuel Type: Gas
- Gasket or Seal Included: No
- In Tank or External: In Tank
- Inlet Type: Strainer
- Internal or External Strainer: Internal
- Item Grade: Standard Replacement
- Maximum Pressure: 94.0 PSI
- Outlet Outside Diameter: 0.375''
- Outlet Quantity: 1
- Outlet Type: Quick Connect
- Pump Type: Electric
- Regulator Included: Yes
- Resistance Ohms Empty: 203.0
- Resistance Ohms Full: 11.0
- Strainer Included: Yes
- System Pressure: 51 psi
- Terminal Gender: Male
- Terminal Quantity: 4
- Terminal Type: Blade
- UPC: 689604232149
- Vapor Pressure Sensor: No
- Voltage: 12.0 VDC
- Part Description: 2004 Mazda 3 Fuel Pump Module Assembly
Vehicle Fitment- 2004 Mazda 3 | All Trims | 4 Cyl 2.0L
Product Specifications- Cam Type: Quick-On
- Cap Depth: 2.47"
- Locking: Yes
- Neck Diameter: 1.77"
- Shell Diameter: 2.91"
- Type: Regular Fuel Cap
- UPC: 770075377160
- Venting: Pressure Vacuum
- Part Description: 2004 Mazda 3 Locking Fuel Tank Cap
Vehicle Fitment- 2004 Mazda 3 | All Trims | 4 Cyl 2.0L
- 2004 Mazda 3 | All Trims | 4 Cyl 2.3L
Product Specifications- Notes: Terminals: 2
- Part Description: 2004 Mazda 3 Fuel Temperature Sensor
Vehicle Fitment- 2004 Mazda 3 | i | All Engines
- 2004 Mazda 3 | S | All Engines
Product Specifications- Cam Type: Quick-On
- Cap Depth: 2.47"
- Locking: No
- Neck Diameter: 1.77"
- Shell Diameter: 2.9"
- Type: OE Equivalent Fuel Cap
- UPC: 770075377177
- Venting: Pressure Vacuum
- Part Description: 2004 Mazda 3 Replacement Non Locking Fuel Tank Cap
Vehicle Fitment- 2004 Mazda 3 | All Trims | 4 Cyl 2.0L
- 2004 Mazda 3 | All Trims | 4 Cyl 2.3L
Product Specifications- Notes: California Models;with California Emissions System;with California Emissions System
- Average Current Draw(A): 9.4
- Average Flow Rating(GPH): 26.3
- Connector Gender: Male
- Connector Quantity: 1
- Connector Shape: Racetrack
- Country of Orign: China
- Fuel Filter Included: Yes
- Fuel Sending Unit Included: Yes
- Fuel Tank Pressure Sensor Included: No
- Gasket or Seal Included: No
- Grade Type: Performance
- Housing Material: POM
- In Tank or External: In Tank
- Inlet Size: 0.314
- Inlet Type: Strainer
- Installation Warnings: No
- Internal Or External Strainer: Internal
- Maximum Pump Pressure (PSI): 53.65
- Minimum Pump Pressure (PSI): 50.75
- Negative Ground: Yes
- Outlet Quantity: 1
- Outlet Size: 0.374
- Outlet Type: Quick Connect
- Product Height (in): 8.35
- Product Length (in): 10
- Product Width (in): 9.45
- Pump Type: Turbine
- Regulator Included: Yes
- Resistance Ohms Empty: 204
- Resistance Ohms Full: 10
- Strainer Included: Yes
- Terminal Gender: Male
- Terminal Quantity: 4
- Terminal Type: PIN
- UPC: 00072845145901
- Voltage: 12V
- Weight (lbs): 3.06
- Wire Harness Included: No
- Part Description: 2004 Mazda 3 Fuel Pump Module Assembly
Vehicle Fitment- 2004 Mazda 3 | All Trims | 4 Cyl 2.0L
- 2004 Mazda 3 | All Trims | 4 Cyl 2.3L
Product Specifications- Notes: with Plastic Cover;with Federal Emission System;Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
- Current Draw: 7
- Flow Rating: 50 gph
- Fuel Level Sender Assembly Included: Yes
- Fuel Type: Gas
- Gasket or Seal Included: No
- In Tank or External: In Tank
- Inlet Type: Strainer
- Internal or External Strainer: Internal
- Item Grade: Standard Replacement
- Maximum Pressure: 94.0 PSI
- Outlet Outside Diameter: 0.313''
- Outlet Quantity: 1
- Outlet Type: Quick Connect
- Pump Type: Electric
- Regulator Included: No
- Resistance Ohms Empty: 203.0
- Resistance Ohms Full: 9.0
- Strainer Included: Yes
- System Pressure: 51 psi
- Terminal Gender: Male
- Terminal Quantity: 4
- Terminal Type: Blade
- UPC: 689604232163
- Vapor Pressure Sensor: No
- Voltage: 12.0 VDC
- Part Description: 2004 Mazda 3 Fuel Pump Module Assembly
Vehicle Fitment- 2004 Mazda 3 | All Trims | 4 Cyl 2.0L
- 2004 Mazda 3 | All Trims | 4 Cyl 2.3L
Product Specifications- Notes: Except California Models
- Average Current Draw(A): 6
- Average Flow Rating(GPH): 19.81
- Connector Gender: Male
- Connector Quantity: 1
- Connector Shape: Rectangle
- Country of Orign: China
- Fuel Filter Included: No
- Fuel Sending Unit Included: Yes
- Fuel Tank Pressure Sensor Included: No
- Gasket or Seal Included: Yes
- Grade Type: Performance
- Housing Material: POM
- In Tank or External: In Tank
- Inlet Size: 0.433
- Inlet Type: Strainer
- Installation Warnings: No
- Internal Or External Strainer: Internal
- Maximum Pump Pressure (PSI): 130
- Minimum Pump Pressure (PSI): 80
- Mounting Hardware Included: No
- Negative Ground: Yes
- Outlet Quantity: 1
- Outlet Type: Quick Connect
- Product Height (in): 8.62
- Product Length (in): 9.37
- Product Width (in): 8.86
- Pump Type: Turbine
- Regulator Included: No
- Resistance Ohms Empty: 204
- Resistance Ohms Full: 10
- Strainer Included: Yes
- Terminal Gender: Male
- Terminal Quantity: 6
- Terminal Type: PIN
- UPC: 00072845145024
- Voltage: 12V
- Weight (lbs): 2.51
- Wire Harness Included: No
- Part Description: 2004 Mazda 3 Fuel Pump Module Assembly
Vehicle Fitment- 2004 Mazda 3 | All Trims | 4 Cyl 2.0L
- 2004 Mazda 3 | All Trims | 4 Cyl 2.3L
Product Specifications- Complete: Y
- Contains Applications: Y
- Release Wave: 03/29/2019
- UPC: 023913807412
- Part Description: 2004 Mazda 3 Multi Purpose O-Ring
Vehicle Fitment- 2004 Mazda 3 | All Trims | 4 Cyl 2.3L
- 2004 Mazda 3 | All Trims | 4 Cyl 2.0L
Product Specifications- Notes: w/Calif Emissions
- Gasket Included: N
- Hazardous Material: No
- Inlet Count: 1
- Inlet Type: Strainer
- Item Grade: Standard Replacement
- Maximum Free Flow Rate (gph): 60
- Maximum Pressure Rate (psi): 54
- Minimum Free Flow Rate (gph): 50
- Minimum Pressure Rate (psi): 54
- Outlet Count: 1
- Outlet Size: 3/8"
- Outlet Type: Quick Connect
- Package Contents: Pump & Kit
- Package Quantity: 1
- UPC: 080044016632
- Warranty: Lifetime Limited Warranty
- Part Description: 2004 Mazda 3 In-Tank Fuel Pump Module Assembly
Vehicle Fitment- 2004 Mazda 3 | All Trims | 4 Cyl 2.0L
Product Specifications- Notes: Fed Emissions
- Gasket or Seal Included: Yes
- Inlet Attachment: Inlet-Strainer
- Inlet Type: STRAINER
- Internal or External: Internal
- Internet Product Code (IPC): 33E15CACDE3
- Item Grade: STANDARD REPLACEMENT
- Item has MSDS (SDS): No
- Maximum Pressure (psi): 120
- MFG Brand Name: Airtex Products
- MFG Model # (Series): E8591M
- Minimum Pressure (psi): 59.0
- Outlet Attachment: Outlet-Quick Connect
- Outlet Size: Outlet - 5/16
- Outlet Type: QUICK CONNECT
- Package Contents: PUMP & KIT
- Package Quantity: 1
- Pump Type: Electrical
- Supplier Company Name: Airtex Products
- UPC: 080044023531
- Voltage [V]: 12V
- Wiring Harness Included: No
- Part Description: 2004 Mazda 3 In-Tank Fuel Pump Module Assembly
Vehicle Fitment- 2004 Mazda 3 | All Trims | 4 Cyl 2.3L
- 2004 Mazda 3 | All Trims | 4 Cyl 2.0L
Product Specifications- UPC: 671607134568
- Part Description: 2004 Mazda 3 Fuel Tank Strap
Vehicle Fitment- 2004 Mazda 3 | All Trims | All Engines
Product Specifications- Notes: Color Black
- Cam Type: Quick-On
- Cap Depth: 2.47"
- Neck Diameter: 1.77"
- Shell Diameter: 2.91"
- UPC: 033342084643
- Venting: Pressure Vacuum
- Part Description: 2004 Mazda 3 Regular Locking Fuel Cap
Vehicle Fitment- 2004 Mazda 3 | All Trims | 4 Cyl 2.0L
- 2004 Mazda 3 | All Trims | 4 Cyl 2.3L
Product Specifications- Notes: Color Black
- Cam Type: Quick-On
- Cap Depth: 2.47"
- Neck Diameter: 1.77"
- Shell Diameter: 2.9"
- UPC: 033342084681
- Venting: Pressure Vacuum
- Part Description: 2004 Mazda 3 Fuel Tank Cap
Vehicle Fitment- 2004 Mazda 3 | All Trims | 4 Cyl 2.0L
- 2004 Mazda 3 | All Trims | 4 Cyl 2.3L
Product Specifications- Gasket Included: N
- Item Grade: STANDARD REPLACEMENT
- Package Contents: TANK SEAL
- Package Quantity: 1
- UPC: 080044062998
- Part Description: 2004 Mazda 3 Fuel Pump Tank Seal
Vehicle Fitment- 2004 Mazda 3 | All Trims | 4 Cyl 2.0L
- 2004 Mazda 3 | All Trims | 4 Cyl 2.3L
Product Specifications- Notes: Cream
- Freight Class: 85
- UPC: 333420951820
- Part Description: 2004 Mazda 3 Fuel Cap Tester Adapter
Vehicle Fitment- 2004 Mazda 3 | All Trims | 4 Cyl 2.0L
- 2004 Mazda 3 | All Trims | 4 Cyl 2.3L
Product Specifications- Cap Depth: 2.500
- Color: Black
- Freight Class: 85
- Fuel Cap Venting: Pressure Relief
- Locking: Yes
- Material: Plastic
- Neck Diameter: 1.563
- Shell Diameter: 2.875
- Tether Included: No
- UPC: 333420846676
- Part Description: 2004 Mazda 3 Regular Keyed Alike Fuel Cap
Vehicle Fitment- 2004 Mazda 3 | All Trims | 4 Cyl 2.0L
- 2004 Mazda 3 | All Trims | 4 Cyl 2.3L
