StrongArm® Back Door Lift Support
PartNumber: 6213$36.84Product Specifications- Body: 19.00
- BODY CONNECTION: blade w/bracket
- Brackets: Yes
- Compressed Length: 14.10
- Extended Length: 21.85
- Force: 31.00
- Hardware Kit: No
- High Performance Item: N
- Internal Springs: No
- Is Application Specific: Y
- Material: Heavy gauge steel pressure tube provides long life; Rubber o-ring piston seal for controlled lift; Teflon backup ring gives enhanced performance
- Shaft: 8.00
- SHAFT CONNECTION: blade (.460 dia. hole)
- Stroke: 7.75
- UPC: 845998005015
- Part Description: Back Door Lift Support
StrongArm® Door Lift Support
PartNumber: 4107$21.09Product Specifications- Body: 22.00
- BODY CONNECTION: ball socket (steel) 13mm
- Brackets: No
- Compressed Length: 9.14
- Extended Length: 14.31
- Force: 261.00
- Hardware Kit: No
- High Performance Item: N
- Internal Springs: No
- Is Application Specific: Y
- Material: Heavy gauge steel pressure tube provides long life; Rubber o-ring piston seal for controlled lift; Teflon backup ring gives enhanced performance
- Shaft: 10.00
- SHAFT CONNECTION: ball socket (steel) 13mm
- Stroke: 5.18
- UPC: 845998001024
- Part Description: Door Lift Support
StrongArm® Door Lift Support
PartNumber: 6173$19.77Product Specifications- Body: 19.00
- BODY CONNECTION: off-set blade (.460 dia. hole)
- Brackets: No
- Compressed Length: 12.37
- Extended Length: 19.12
- Force: 58.00
- Hardware Kit: PM09068
- High Performance Item: N
- Internal Springs: No
- Is Application Specific: Y
- Material: Heavy gauge steel pressure tube provides long life; Rubber o-ring piston seal for controlled lift; Teflon backup ring gives enhanced performance
- Shaft: 8.00
- SHAFT CONNECTION: ball socket (nylon) 10mm
- Stroke: 3.25
- UPC: 845998009419
- Part Description: Door Lift Support
StrongArm® Back Door Lift Support
PartNumber: 6289$19.50Product Specifications- Body: 18.00
- BODY CONNECTION: ball socket (steel) 10mm
- Brackets: No
- Compressed Length: 16.00
- Extended Length: 25.00
- Force: 56.00
- Hardware Kit: No
- High Performance Item: N
- Internal Springs: No
- Is Application Specific: Y
- Material: Heavy gauge steel pressure tube provides long life; Rubber o-ring piston seal for controlled lift; Teflon backup ring gives enhanced performance
- Shaft: 8.00
- SHAFT CONNECTION: ball socket (steel) 10mm
- Stroke: 9.00
- UPC: 845998012181
- Part Description: Back Door Lift Support
StrongArm® Front Access Door Lift Support
PartNumber: 6900$18.59Product Specifications- Body: 15.00
- BODY CONNECTION: ball socket (nylon) 10mm
- Brackets: No
- Compressed Length: 14.25
- Extended Length: 21.75
- Force: 28.00
- Hardware Kit: No
- High Performance Item: N
- Internal Springs: No
- Is Application Specific: Y
- Material: Heavy gauge steel pressure tube provides long life; Rubber o-ring piston seal for controlled lift; Teflon backup ring gives enhanced performance
- Shaft: 6.00
- SHAFT CONNECTION: ball socket (nylon) 10mm
- Stroke: 7.00
- UPC: 845998014994
- Part Description: Front Access Door Lift Support
StrongArm® Back Door Lift Support
PartNumber: 4560$17.12Product Specifications- Body: 15.00
- BODY CONNECTION: off-set blade (.416 dia. hole)
- Brackets: No
- Compressed Length: 12.06
- Extended Length: 18.30
- Force: 44.00
- Hardware Kit: No
- High Performance Item: N
- Internal Springs: No
- Is Application Specific: Y
- Material: Heavy gauge steel pressure tube provides long life; Rubber o-ring piston seal for controlled lift; Teflon backup ring gives enhanced performance
- Shaft: 6.00
- SHAFT CONNECTION: off-set blade (.415 dia. hole)
- Stroke: 6.24
- UPC: 043645711429
- Part Description: Back Door Lift Support
StrongArm® Back Door Lift Support
PartNumber: 4789$13.34Product Specifications- Body: 15.00
- BODY CONNECTION: off-set blade (.416 dia. hole)
- Brackets: No
- Compressed Length: 13.82
- Extended Length: 23.07
- Force: 27.00
- Hardware Kit: No
- High Performance Item: N
- Internal Springs: No
- Is Application Specific: Y
- Material: Heavy gauge steel pressure tube provides long life; Rubber o-ring piston seal for controlled lift; Teflon backup ring gives enhanced performance
- Shaft: 6.00
- SHAFT CONNECTION: off-set blade (.415 dia. hole)
- Stroke: 9.25
- UPC: 043645642075
- Part Description: Back Door Lift Support
StrongArm® Rear Access Door Lift Support
PartNumber: 6901$10.13Product Specifications- Body: 15.00
- BODY CONNECTION: ball socket (nylon) 10mm
- Brackets: No
- Compressed Length: 14.34
- Extended Length: 20.59
- Force: 26.00
- Hardware Kit: No
- High Performance Item: N
- Internal Springs: No
- Is Application Specific: Y
- Material: Heavy gauge steel pressure tube provides long life; Rubber o-ring piston seal for controlled lift; Teflon backup ring gives enhanced performance
- Shaft: 6.00
- SHAFT CONNECTION: ball socket (nylon) 10mm
- Stroke: 6.25
- UPC: 845998011009
- Part Description: Rear Access Door Lift Support
