Vehicle Specific
Check if it fits by entering your vehicle info| Brand | CSF |
| Part Number | 3793 |
| Part Description | Engine Coolant Radiator |
| Bottom Hose Fitting (in) | 1 1/2 Right |
| Box Height (in) | 5 11/16 |
| Box Length (in) | 36 15/16 |
| Box Weight (lbs) | 15 |
| Box Width (in) | 27 1/2 |
| Core Length | 27 3/4 |
| Core Material | Aluminum |
| Core Thickness | 1 1/4 |
| Core Width | 23 |
| Cross-flow/ Down-flow | Cross Flow |
| Hazardous Material | No |
| Inlet Length (in) | 23 9/16 |
| Inlet Width (in) | 1 1/2 |
| No. Of Rows | 1 |
| UPC | 710353037935 |
| OE Part Number | 7-3555, 8013555, 13555, F2GZ 8005B |
| Outlet Length(in) | 23 9/16 |
| Outlet Width | 1 1/2 |
| Radiator Cap Supplied | No |
| Tank Material | Plastic |
| Tech Note | O.E.M. style Plastic tanks & Aluminum core;with quick-connect outlet pipe. |
| Top Hose Fitting (in) | 1 5/16 Left |
| Year Make Model | Trim | Engine |
|---|---|---|
| 2015-2020 Ford Edge | All Trims | 4 Cyl 2.0L |
| 2015-2020 Ford Edge | All Trims | 6 Cyl 2.7L |
| 2016-2018 Lincoln MKX | All Trims | 6 Cyl 2.7L |
| 2019-2020 Lincoln Nautilus | All Trims | 4 Cyl 2.0L |
| 2019-2020 Lincoln Nautilus | All Trims | 6 Cyl 2.7L |
