Vehicle Specific
Check if it fits by entering your vehicle info| Brand | CSF |
| Part Number | 3843 |
| Part Description | Engine Coolant Radiator |
| Bottom Hose Fitting (in) | 2 1/4 Right |
| Box Height (in) | 6 5/8 |
| Box Length (in) | 47 |
| Box Weight (lbs) | 37 |
| Box Width (in) | 31 13/16 |
| Core Length | 33 7/16 |
| Core Material | Aluminum |
| Core Thickness | 2 3/16 |
| Core Width | 27 7/16 |
| Cross-flow/ Down-flow | Cross Flow |
| Hazardous Material | No |
| Inlet Length (in) | 28 7/16 |
| Inlet Width (in) | 2 11/16 |
| No. Of Rows | 2 |
| UPC | 710353038437 |
| OE Part Number | 84224661, GM3010615, 23208447 |
| Oil Cooler (in) | 11 1/2 Right (high-effeciency Plate Type) |
| Outlet Length(in) | 28 7/16 |
| Outlet Width | 2 11/16 |
| Radiator Cap Supplied | No |
| Tank Material | Plastic |
| Tech Note | O.E.M. style Plastic tanks & Aluminum core with quick-connect outlet pipe & oil cooler fittings. |
| Top Hose Fitting (in) | 2 Left |
| Year Make Model | Trim | Engine |
|---|---|---|
| 2017-2019 Chevrolet Silverado 2500 HD | All Trims | 8 Cyl 6.6L |
| 2017-2019 Chevrolet Silverado 3500 HD | All Trims | 8 Cyl 6.6L |
| 2017-2019 GMC Sierra 2500 HD | All Trims | 8 Cyl 6.6L |
| 2017-2019 GMC Sierra 3500 HD | All Trims | 8 Cyl 6.6L |
