Vehicle Specific
Check if it fits by entering your vehicle info| Brand | Delphi |
| Part Number | HM10033 |
| Part Description | Direct Injection High Pressure Fuel Pump |
| Drive Shaft Included | No |
| Fuel Type | Gas |
| Gasket or Seal Included | No |
| Housing Color | Silver |
| Housing Material | Metal |
| In Tank or External | External |
| Inlet Outside Diameter | 0.313'' |
| Inlet Type | Quick Connect |
| Item Grade | Standard Replacement |
| Mounting Hardware Included | No |
| Outlet Fitting Thread Size | M14-1.5mm |
| Outlet Quantity | 2 |
| Outlet Type | Threaded |
| Pump Type | Mechanical |
| Terminal Gender | Male |
| Terminal Quantity | 2 |
| Terminal Type | Blade |
| UPC | 689604284285 |
| Wiring Harness Included | No |
| Year Make Model | Trim | Engine |
|---|---|---|
| 2015-2018 Ford Edge | All Trims | 4 Cyl 2.0L |
| 2017-2019 Ford Escape | All Trims | 4 Cyl 2.0L |
| 2016-2019 Ford Explorer | All Trims | 4 Cyl 2.3L |
| 2016-2018 Ford Focus | All Trims | 4 Cyl 2.3L |
| 2017-2020 Ford Fusion | All Trims | 4 Cyl 2.0L |
| 2015-2020 Ford Mustang | All Trims | 4 Cyl 2.3L |
| 2015-2019 Lincoln MKC | All Trims | 4 Cyl 2.3L |
| 2017-2019 Lincoln MKC | All Trims | 4 Cyl 2.0L |
| 2017-2020 Lincoln MKZ | All Trims | 4 Cyl 2.0L |
