Vehicle Specific
Check if it fits by entering your vehicle info| Brand | Delphi |
| Part Number | HM10049 |
| Part Description | Direct Injection High Pressure Fuel Pump |
| Drive Shaft Included | No |
| Fuel Type | Gas |
| Gasket or Seal Included | No |
| Housing Color | Silver |
| Housing Material | Metal |
| In Tank or External | External |
| Inlet Outside Diameter | 0.313'' |
| Inlet Type | Hose Bead |
| Item Grade | Standard Replacement |
| Mounting Hardware Included | No |
| Outlet Fitting Thread Size | M14-1.5mm |
| Outlet Quantity | 2 |
| Outlet Type | Female Threaded |
| Package Contents | Direct Injection High Pressure Fuel Pump, Instruction Sheet |
| Pump Type | Mechanical |
| Terminal Gender | Male |
| Terminal Quantity | 2 |
| Terminal Type | Blade |
| UPC | 689604285374 |
| Wiring Harness Included | No |
| Year Make Model | Trim | Engine |
|---|---|---|
| 2014-2017 Volkswagen Beetle | All Trims | 4 Cyl 1.8L |
| 2014-2017 Volkswagen Beetle | All Trims | 4 Cyl 2.0L |
| 2015-2017 Volkswagen Golf | All Trims | 4 Cyl 1.8L |
| 2017 Volkswagen Golf Alltrack | All Trims | 4 Cyl 1.8L |
| 2015-2017 Volkswagen Golf SportWagen | All Trims | 4 Cyl 1.8L |
| 2014-2018 Volkswagen Jetta | All Trims | 4 Cyl 1.8L |
| 2014-2018 Volkswagen Jetta | All Trims | 4 Cyl 2.0L |
| 2014-2017 Volkswagen Passat | All Trims | 4 Cyl 1.8L |
