Vehicle Specific
Check if it fits by entering your vehicle info| Brand | Dorman |
| Part Number | 622-008 |
| Part Description | Engine Cooling Fan Clutch |
| Bolt Hole Quantity | 6 |
| Bolt Hole Size | M6x1.0 |
| Bore Size | 57 mm |
| Clutch Maximum Diameter | 195 mm |
| Color | Grey |
| Color/Finish | Metallic |
| Connector Quantity | 1 |
| Distance From Clutch To Mounting Flange | 21 mm |
| Fan Rotation | Clockwise |
| Installation Instructions Included | No |
| Item Grade | Standard Replacement |
| Material | Plastic/Metal |
| Mounting Flange Thickness | 16 mm |
| Mounting Hardware Included | No |
| Mounting Hole Quantity | 6 |
| Mounting Type | Threaded |
| UPC | 885484880719 |
| OE Part Number | 7C3Z8A616F, 7C3Z8A616E |
| Outside Diameter | 195 mm |
| Package Contents | Fan Clutch Assembly |
| Package Quantity | 1 |
| Packaging Type | Box |
| Terminal Quantity | 5 |
| Terminal Type | Pin |
| Thermal Or Centrifugal | Thermal |
| Thermostatic | Yes |
| Use Type | Regular |
| Width | 57 mm |
| Wire Gauge Measurement | 18 AWG |
| Wire Quantity | 5 |
| Year Make Model | Trim | Engine |
|---|---|---|
| 2008-2010 Ford F-250 Super Duty | All Trims | 8 Cyl 6.4L |
| 2008-2010 Ford F-350 Super Duty | All Trims | 8 Cyl 6.4L |
