Vehicle Specific
Check if it fits by entering your vehicle info| Brand | Dorman |
| Part Number | 626-634 |
| Part Description | Hvac Heater Hose Assembly |
| Branch Quantity | 2 |
| Color/Finish | Natural |
| Contains Spring | No |
| Coolant Hose Heat Shield Included | No |
| Coolant Hose Length | 20" |
| Coolant Hose Material | Aluminum |
| Coolant Hose Protective Sleeve Included | No |
| Coolant Hose Type | Single I.D. (Inside Diameter) |
| End 1 Attachment Type | Flat |
| End 2 Attachment Type | Flat |
| Grade Type | Regular |
| Hose End (1) Inside Diameter (In) | 0.608" |
| Hose End (1) Outside Diameter (In) | 0.747" |
| Hose End (2) Inside Diameter (In) | 0.608" |
| Hose End (2) Outside Diameter (In) | 0.627" |
| Hose Shape | Molded Assembly |
| Maximum Working Pressure (psi) | 100 PSI |
| UPC | 885484875968 |
| OE Part Number | 5143117AA |
| Thermostatically Controlled | No |
| With Clamps | No |
| Year Make Model | Trim | Engine |
|---|---|---|
| 2006-2010 Jeep Commander | All Trims | 6 Cyl 3.7L |
| 2006-2010 Jeep Commander | All Trims | 8 Cyl 4.7L |
| 2006-2010 Jeep Commander | All Trims | 8 Cyl 5.7L |
| 2005-2010 Jeep Grand Cherokee | All Trims | 6 Cyl 3.7L |
| 2005-2010 Jeep Grand Cherokee | All Trims | 8 Cyl 5.7L |
| 2006-2010 Jeep Grand Cherokee | All Trims | 8 Cyl 6.1L |
