Vehicle Specific
Check if it fits by entering your vehicle info| Brand | Four Seasons |
| Part Number | 158360 |
| Part Description | A C Compressor With Clutch |
| Clutch Included | Yes |
| Clutch Maximum Diameter | 4.72 |
| Coil Clock Position | NR |
| Coil Voltage | 12 |
| Compatible Refrigerant Oil Type | PAG 46 |
| Compressor Type | 7SEU17C |
| Discharge Port Type | O-Ring |
| Distance From Clutch To Mounting Flange | 0.640625 |
| ECV Harness Connector | SE05F, 26892 Female / / SE22M, 26882 Male |
| Mount Distance MM | 16.256 |
| Mounting Hardware | Not Included |
| Mounting Type | Tangent Mount |
| New or Reman | New |
| O-Ring A Number/Desc | [24670] / Green O-Ring |
| O-Ring A Quantity | 1 |
| O-Ring B Number/Desc | [24635] / Green Round O-Ring |
| O-Ring B Quantity | 1 |
| Printed Foot Note | May Require use of OE Manifold |
| Pulley Belt Type | Serpentine |
| Pulley Diameter MM | 120.396 |
| Pulley Groove Quantity | 7 |
| Pulley Lip Diameter | 4.72 |
| Pulley Outside Diameter | 4.72 |
| Pulley Ridge Diameter | 4.72 |
| Refrigerant Type | R134a |
| Suction Port Type | O-Ring |
| Terminal Type | Pin |
| UPC | 096361616868 |
| Year Make Model | Trim | Engine |
|---|---|---|
| 2003-2005 Mercedes-Benz C230 | All Trims | All Engines |
| 2006 Mercedes-Benz E350 | All Trims | All Engines |
| 2009 Porsche 911 | All Trims | All Engines |
| 2011-2016 Porsche 911 | All Trims | All Engines |
| 2013-2016 Porsche Boxster | All Trims | All Engines |
| 2003-2004 Porsche Cayenne | All Trims | All Engines |
| 2005-2006 Porsche Cayenne | All Trims | 8 Cyl 4.5L |
| 2011-2014 Porsche Cayenne | All Trims | 8 Cyl 4.8L |
| 2016-2017 Porsche Cayenne | All Trims | 8 Cyl 4.8L |
| 2014-2016 Porsche Cayman | All Trims | All Engines |
