Vehicle Specific
Check if it fits by entering your vehicle info| Brand | Four Seasons |
| Part Number | 198360 |
| Part Description | A C Compressor With Clutch |
| Clutch Included | Yes |
| Clutch Maximum Diameter | 4.265625 |
| Coil Clock Position | Lead Wire |
| Coil Voltage | 12 |
| Compatible Refrigerant Oil Type | PAG 46 |
| Compressor Type | HCC-VS16 |
| ECV Harness Connector | SE25F, 26897 Female / / SE23M, 26883 Male |
| Mounting Hardware | Not Included |
| Mounting Type | Tangent Mount |
| New or Reman | New |
| O-Ring A Number/Desc | 24257 |
| O-Ring A Quantity | 1 |
| O-Ring B Number/Desc | 24642 |
| O-Ring B Quantity | 1 |
| O-Ring C Number/Desc | 24243 |
| O-Ring C Quantity | 1 |
| Pulley Belt Type | Serpentine |
| Pulley Diameter MM | 108.204 |
| Pulley Groove Quantity | 4 |
| Pulley Lip Diameter | 4.265625 |
| Pulley Outside Diameter | 4.265625 |
| Pulley Ridge Diameter | 4.265625 |
| Refrigerant Type | R134a |
| Terminal Type | Pin |
| UPC | 096361625105 |
| Year Make Model | Trim | Engine |
|---|---|---|
| 2013-2016 Ford Escape | All Trims | 4 Cyl 2.0L |
| 2015-2016 Lincoln MKC | All Trims | All Engines |
