Vehicle Specific
Check if it fits by entering your vehicle info| Brand | Four Seasons |
| Part Number | 198361 |
| Part Description | A C Compressor With Clutch |
| Clutch Included | Yes |
| Clutch Maximum Diameter | 4.3125 |
| Coil Clock Position | Wire Lead |
| Coil Voltage | 12 |
| Compatible Refrigerant Oil Type | PAG 46 |
| Compressor Type | 7SBU17C |
| Discharge Port Type | O-Ring |
| Distance From Clutch To Mounting Flange | 1.5625 |
| ECV Harness Connector | SE05F, 26892 Female / / SE22M, 26882 Male |
| Mounting Hardware | Not Included |
| Mounting Type | 3 Tangent One on Rear Head |
| New or Reman | New |
| O-Ring A Number/Desc | [24659] / Green O-Ring |
| O-Ring A Quantity | 1 |
| O-Ring B Number/Desc | [24635] / Green Round O-Ring |
| O-Ring B Quantity | 1 |
| Printed Foot Note | May Require use of OE Manifold |
| Pulley Belt Type | Serpentine |
| Pulley Diameter MM | 109.728 |
| Pulley Groove Quantity | 8 |
| Pulley Lip Diameter | 4.3125 |
| Pulley Outside Diameter | 4.3125 |
| Pulley Ridge Diameter | 4.3125 |
| Refrigerant Type | R134a |
| Suction Port Type | O-Ring |
| Terminal Type | Pin |
| UPC | 096361625075 |
| Year Make Model | Trim | Engine |
|---|---|---|
| 2012-2013 BMW 335i | All Trims | 6 Cyl 3.0L |
| 2014-2015 BMW 335i | All Trims | All Engines |
| 2014-2016 BMW 335i GT xDrive | All Trims | All Engines |
| 2013 BMW 335i xDrive | All Trims | 6 Cyl 3.0L |
| 2014-2015 BMW 335i xDrive | All Trims | All Engines |
| 2014-2016 BMW 435i | All Trims | All Engines |
| 2015-2016 BMW 435i Gran Coupe | All Trims | All Engines |
| 2014-2016 BMW 435i xDrive | All Trims | All Engines |
| 2015-2016 BMW 435i xDrive Gran Coupe | All Trims | All Engines |
| 2016 BMW 535d | All Trims | All Engines |
