Vehicle Specific
Check if it fits by entering your vehicle info| Brand | Four Seasons |
| Part Number | 198393 |
| Part Description | A C Compressor With Clutch |
| Clutch Included | Yes |
| Clutch Maximum Diameter | 5.09375 |
| Coil Clock Position | Lead Wire |
| Coil Voltage | 12 |
| Compatible Refrigerant Oil Type | PAG 46 |
| Compressor Type | 7SEU17C |
| Distance From Clutch To Mounting Flange | 1.300 |
| ECV Harness Connector | SE35F, 26901 Female / / SE35M, 26887 Male |
| Mounting Hardware | Not Included |
| Mounting Type | 3 Tangent One on Rear Head |
| New or Reman | New |
| O-Ring A Number/Desc | 24635 |
| O-Ring A Quantity | 1 |
| O-Ring B Number/Desc | 24659 |
| O-Ring B Quantity | 1 |
| O-Ring C Number/Desc | 24683 |
| O-Ring C Quantity | 1 |
| Printed Foot Note | May Require use of OE Manifold |
| Pulley Belt Type | Serpentine |
| Pulley Groove Quantity | 6 |
| Pulley Lip Diameter | 5.09375 |
| Pulley Outside Diameter | 5.09375 |
| Pulley Ridge Diameter | 5.09375 |
| Refrigerant Type | R134a |
| Terminal Type | Pin |
| UPC | 096361001435 |
| Year Make Model | Trim | Engine |
|---|---|---|
| 2005-2006 Audi A4 | All Trims | 6 Cyl 3.2L |
| 2008 Audi A4 | Base | 6 Cyl 3.2L |
| 2005 Audi A4 Quattro | All Trims | 6 Cyl 3.0L |
| 2005-2006 Audi A4 Quattro | All Trims | 6 Cyl 3.2L |
| 2008 Audi A4 Quattro | Avant | 6 Cyl 3.2L |
| 2008 Audi A4 Quattro | Base | 6 Cyl 3.2L |
| 2008 Audi A4 Quattro | Cabriolet | 6 Cyl 3.2L |
| 2008-2009 Audi A4 Quattro | All Trims | 6 Cyl 3.2L |
| 2011 Audi Q5 | All Trims | All Engines |
| 2011 Audi Q5 | Premium | All Engines |
