Vehicle Specific
Check if it fits by entering your vehicle info| Brand | Four Seasons |
| Part Number | 58547 |
| Part Description | A C Compressor With Clutch |
| Belt Width IN | 0.500 |
| Clutch Included | Yes |
| Clutch Maximum Diameter | 5.250 |
| Coil Clock Position | Wire Lead |
| Coil Voltage | 12 |
| Comp Head Prt Config | Top-Vert-Tube-O |
| Compatible Refrigerant Oil Type | PAG 100 |
| Compressor Head Type | N |
| Compressor Type | SD508HD |
| Discharge Port Type | O-Ring |
| Distance From Clutch To Mounting Flange | 0.953125 |
| Mount Distance B IN | 1.546875 |
| Mounting Hardware | Not Included |
| Mounting Type | Ear Mount |
| New or Reman | New |
| O-Ring A Number/Desc | [24111] / Mini York Teflon Seal O-Ring |
| O-Ring A Quantity | 2 |
| O-Ring B Number/Desc | Not Required |
| O-Ring B Quantity | NR |
| O-Ring C Number/Desc | Not Required |
| O-Ring C Quantity | NR |
| Pulley Belt Type | Serpentine |
| Pulley Diameter MM | 133.350 |
| Pulley Groove Quantity | 2 |
| Pulley Lip Diameter | 5.250 |
| Pulley Outside Diameter | 5.250 |
| Pulley Ridge Diameter | 5.250 |
| Refrigerant Type | R134a |
| Suction Port Type | O-Ring |
| Terminal Type | Bullet |
| UPC | 096361585478 |
| Year Make Model | Trim | Engine |
|---|---|---|
| 1985-1986 Jeep CJ7 | All Trims | 4 Cyl 2.5L |
| 1984 Jeep Cherokee | All Trims | 4 Cyl 2.5L |
| 1984 Jeep Cherokee | All Trims | 6 Cyl 2.8L |
| 1985 Jeep Scrambler | All Trims | 4 Cyl 2.5L |
| 1985 Jeep Scrambler | All Trims | 6 Cyl 4.2L |
| 1984 Jeep Wagoneer | All Trims | 4 Cyl 2.5L |
| 1984 Jeep Wagoneer | All Trims | 6 Cyl 2.8L |
| 1985-1987 Renault Alliance | All Trims | 4 Cyl 1.4L |
| 1985-1987 Renault Alliance | All Trims | 4 Cyl 1.7L |
| 1987 Renault Alliance | All Trims | 4 Cyl 2.0L |
