Vehicle Specific
Check if it fits by entering your vehicle info| Brand | Four Seasons |
| Part Number | 58595 |
| Part Description | A C Compressor With Clutch |
| Clutch Included | Yes |
| Clutch Maximum Diameter | 4.750 |
| Coil Clock Position | Wire Lead |
| Coil Voltage | 12 |
| Comp Head Prt Config | Rear-Vert-Pad |
| Compatible Refrigerant Oil Type | PAG 100 |
| Compressor Head Type | HS/QB/QP/SH |
| Compressor Type | SD7H15 |
| Discharge Port Type | O-Ring / Gasket |
| Distance From Clutch To Mounting Flange | 1.171875 |
| Mount Distance MM | 29.972 |
| Mounting Hardware | Not Included |
| Mounting Type | Ear Mount |
| New or Reman | New |
| O-Ring A Number/Desc | [24615] / Green O-Ring |
| O-Ring A Quantity | 2 |
| O-Ring B Number/Desc | Not Required |
| O-Ring B Quantity | NR |
| O-Ring C Number/Desc | Not Required |
| O-Ring C Quantity | NR |
| Pulley Belt Type | Serpentine |
| Pulley Diameter MM | 120.650 |
| Pulley Groove Quantity | 6 |
| Pulley Lip Diameter | 4.750 |
| Pulley Outside Diameter | 4.750 |
| Pulley Ridge Diameter | 4.750 |
| Refrigerant Type | R134a |
| Suc Prt Typ Note | Rear |
| Suction Port Type | O-Ring |
| Terminal Type | Pin |
| UPC | 096361585959 |
| Year Make Model | Trim | Engine |
|---|---|---|
| 1993-1995 Volkswagen EuroVan | All Trims | 5 Cyl 2.5L |
