Vehicle Specific
Check if it fits by entering your vehicle info| Brand | Four Seasons |
| Part Number | 68661 |
| Part Description | A C Compressor With Clutch |
| Clutch Included | Yes |
| Clutch Maximum Diameter | 4.625 |
| Coil Clock Position | Wire Lead |
| Coil Voltage | 12 |
| Compatible Refrigerant Oil Type | PAG 46 |
| Compressor Type | DKS17D |
| Discharge Port Type | Sealing Washer |
| Distance From Clutch To Mounting Flange | 1.40625 |
| Mount Distance MM | 35.560 |
| Mounting Hardware | Not Included |
| Mounting Type | Tangent Mount |
| New or Reman | New |
| O-Ring A Number/Desc | [24354] / Sealing Washer |
| O-Ring A Quantity | 2 |
| O-Ring B Number/Desc | Not Required |
| O-Ring B Quantity | NR |
| O-Ring C Number/Desc | Not Required |
| O-Ring C Quantity | NR |
| Pulley Belt Type | Serpentine |
| Pulley Diameter MM | 117.475 |
| Pulley Groove Quantity | 6 |
| Pulley Lip Diameter | 4.625 |
| Pulley Outside Diameter | 4.625 |
| Pulley Ridge Diameter | 4.625 |
| Refrigerant Type | R134a |
| Suction Port Type | Sealing Washer |
| Terminal Type | Pin |
| UPC | 096361686618 |
| Year Make Model | Trim | Engine |
|---|---|---|
| 2006-2007 Chevrolet Equinox | All Trims | All Engines |
| 2008-2009 Chevrolet Equinox | All Trims | 6 Cyl 3.4L |
| 2006-2007 Pontiac Torrent | All Trims | All Engines |
| 2008-2009 Pontiac Torrent | All Trims | 6 Cyl 3.4L |
