Vehicle Specific
Check if it fits by entering your vehicle info| Brand | Four Seasons |
| Part Number | 78372 |
| Part Description | A C Compressor With Clutch |
| Clutch Included | Yes |
| Clutch Maximum Diameter | 4.750 |
| Coil Clock Position | 4 |
| Coil Voltage | 12 |
| Compatible Refrigerant Oil Type | PAG 46 |
| Compressor Type | 10S17C |
| Discharge Port Type | O-Ring |
| Distance From Clutch To Mounting Flange | 1.203125 |
| Mount Distance MM | 30.480 |
| Mounting Hardware | Not Included |
| Mounting Type | Tangent Mount |
| New or Reman | New |
| O-Ring A Number/Desc | [24681] / Green O-Ring |
| O-Ring A Quantity | 1 |
| O-Ring B Number/Desc | [24661] / Green O-Ring |
| O-Ring B Quantity | 1 |
| Printed Foot Note | May Require use of OE Manifold; DeSlugger [36140] Recommended to Eliminate Compressor Damage on Vehicles with Low Mount Compressor |
| Pulley Belt Type | Serpentine |
| Pulley Diameter MM | 120.650 |
| Pulley Groove Quantity | 7 |
| Pulley Lip Diameter | 4.750 |
| Pulley Outside Diameter | 4.750 |
| Pulley Ridge Diameter | 4.750 |
| Refrigerant Type | R134a |
| Suction Port Type | O-Ring |
| Terminal Type | Pin |
| UPC | 096361783720 |
| Year Make Model | Trim | Engine |
|---|---|---|
| 2003-2011 Honda Element | All Trims | All Engines |
