Vehicle Specific
Check if it fits by entering your vehicle info| Brand | Four Seasons |
| Part Number | 54509 |
| Part Description | A C Evaporator Core |
| Core Depth Fraction | 2-3/4 |
| Core Depth MM | 69.850 |
| Core Height Fraction | 7-5/8 |
| Core Height MM | 193.675 |
| Core Width Fraction | 10 |
| Core Width MM | 254.000 |
| Depth | 2.75 or 2.750 |
| Height | 7.625 or 7.63 |
| Material | Aluminum |
| O-Ring A Number/Desc | [24608] / Green O-Ring |
| O-Ring A Quantity | 1 |
| O-Ring B Number/Desc | [24612] / Green O-Ring |
| O-Ring B Quantity | 1 |
| O-Ring C Number/Desc | [38623] / Orifice Tube |
| O-Ring C Quantity | 1 |
| Outlet Fitting Outside Diameter | No. 12 |
| UPC | 096361545090 |
| Width | 10.000 |
| Year Make Model | Trim | Engine |
|---|---|---|
| 1986-1988 Buick Electra | All Trims | 6 Cyl 3.8L |
| 1986 Buick LeSabre | All Trims | 6 Cyl 3.0L |
| 1986-1988 Buick LeSabre | All Trims | 6 Cyl 3.8L |
| 1986-1988 Oldsmobile 98 | All Trims | All Engines |
| 1986-1988 Oldsmobile Delta 88 | All Trims | All Engines |
