Vehicle Specific
Check if it fits by entering your vehicle info| Brand | Four Seasons |
| Part Number | 54582 |
| Part Description | A C Evaporator Core |
| Core Depth Fraction | 2-3/4 or 2-7/8 |
| Core Depth MM | 69.850 or 73.025 |
| Core Height Fraction | 7-7/8 or 8 |
| Core Height MM | 200.025 or 203.200 |
| Core Width Fraction | 10 or 13-3/8 |
| Core Width MM | 254.000 or 339.725 |
| Depth | 2.750 or 2.875 |
| Height | 7.875 or 8.000 |
| Inlet Fitting Outside Diameter | No. 10 |
| Material | Aluminum |
| O-Ring A Number/Desc | [24606] / Green O-Ring |
| O-Ring A Quantity | 1 |
| O-Ring B Number/Desc | [24610] / Green O-Ring |
| O-Ring B Quantity | 1 |
| O-Ring C Number/Desc | [24612] / Green O-Ring |
| O-Ring C Quantity | 1 |
| Outlet Fitting Outside Diameter | No. 12 |
| UPC | 096361545823 |
| Width | 10.000 or 13.375 |
| Year Make Model | Trim | Engine |
|---|---|---|
| 1991 Buick Reatta | All Trims | All Engines |
| 1991-1993 Buick Riviera | All Trims | All Engines |
| 1991-1993 Cadillac Allante | All Trims | All Engines |
| 1991 Cadillac Eldorado | All Trims | All Engines |
| 1991 Cadillac Seville | All Trims | All Engines |
| 1991-1992 Oldsmobile Toronado | All Trims | All Engines |
