Vehicle Specific
Check if it fits by entering your vehicle info| Brand | Four Seasons |
| Part Number | 56185 |
| Part Description | A C Suction Line Hose Assembly |
| Bracket | w/o Bracket |
| Component Type | Suction Line |
| End 1 Type | P-Nut Fitting |
| End 2 Type | Captured O-Ring |
| Fittings Included | Included |
| Gasket or Seal Included | Included |
| Material | Aluminum / Rubber |
| Muffler | w/o Muffler |
| O-Ring A Number/Desc | [24681] / Green O-Ring |
| O-Ring A Quantity | 2 |
| O.E. Replacement | Yes |
| Refrigerant Type | R134-A |
| Service Port | w/ Service Port |
| Service Port Qty | 1 |
| Service Port Size | 13 mm |
| Suction End Type | P-Nut Fitting |
| Sve Port Low Side | Low Side |
| Switch Included | Not Included |
| Switch Service Port | w/o Switch Port |
| System Pressure | Low Pressure |
| UPC | 096361561854 |
| Year Make Model | Trim | Engine |
|---|---|---|
| 2007-2014 Toyota Tundra | All Trims | 8 Cyl 5.7L |
| 2010-2014 Toyota Tundra | All Trims | 8 Cyl 4.6L |
| 2015 Toyota Tundra | All Trims | All Engines |
| 2016-2017 Toyota Tundra | All Trims | 8 Cyl 4.6L |
| 2016-2017 Toyota Tundra | All Trims | 8 Cyl 5.7L |
