Vehicle Specific
Check if it fits by entering your vehicle info| Brand | Four Seasons |
| Part Number | 57978 |
| Part Description | Remanufactured A C Compressor With Clutch |
| Clutch Included | Yes |
| Clutch Maximum Diameter | 5.000 |
| Coil Clock Position | 12 |
| Coil Voltage | 12 |
| Compatible Refrigerant Oil Type | PAG 150 |
| Compressor Type | V5 |
| Distance From Clutch To Mounting Flange | 1.203125 |
| Mounting Hardware | Not Included |
| Mounting Type | Ear Mount |
| New or Reman | Remanufactured |
| O-Ring A Number/Desc | [24354] / Sealing Washer |
| O-Ring A Quantity | 2 |
| O-Ring B Number/Desc | Not Required |
| O-Ring B Quantity | NR |
| Printed Foot Note | This compressor is equipped with an R12 Control Valve. If retrofitting to R134a, Control Valve [38846] is recommended for optimum system performance. |
| Pulley Belt Type | Serpentine |
| Pulley Diameter MM | 127.000 |
| Pulley Groove Quantity | 6 |
| Pulley Lip Diameter | 5.000 |
| Pulley Outside Diameter | 5.000 |
| Pulley Ridge Diameter | 5.000 |
| Refrigerant Type | R134a |
| Suc Prt Typ Note | w/ 5/8" x 5/8" Ports |
| Suction Port Type | Sealing Washer |
| Switch Included | High Pressure |
| Terminal Type | 8mm Pin Connector |
| UPC | 096361579781 |
| Year Make Model | Trim | Engine |
|---|---|---|
| 1992-1993 Chevrolet S10 | All Trims | 4 Cyl 2.5L |
| 1992-1993 GMC Sonoma | All Trims | 4 Cyl 2.5L |
