Vehicle Specific
Check if it fits by entering your vehicle info| Brand | Four Seasons |
| Part Number | 77561 |
| Part Description | Remanufactured A C Compressor With Clutch |
| Clutch Included | Yes |
| Clutch Maximum Diameter | 3.875 |
| Coil Clock Position | Wire Lead |
| Coil Voltage | 12 |
| Compatible Refrigerant Oil Type | PAG 46 |
| Compressor Type | TRSA12 |
| Discharge Port Type | Sealing Washer |
| Distance From Clutch To Mounting Flange | 2.000 |
| Mount Distance MM | 50.800 |
| Mounting Hardware | Not Included |
| Mounting Type | Tangent Mount |
| New or Reman | Remanufactured |
| O-Ring A Number/Desc | [24355] / Sealing Washer |
| O-Ring A Quantity | 1 |
| O-Ring B Number/Desc | [24354] / Sealing Washer |
| O-Ring B Quantity | 1 |
| Printed Foot Note | May require use of OE connector |
| Pulley Belt Type | Serpentine |
| Pulley Diameter MM | 98.425 |
| Pulley Groove Quantity | 6 |
| Pulley Lip Diameter | 3.875 |
| Pulley Outside Diameter | 3.875 |
| Pulley Ridge Diameter | 3.875 |
| Refrigerant Type | R134a |
| Suction Port Type | Sealing Washer |
| Switch Included | Heat Sensor |
| Terminal Type | Pin |
| UPC | 096361775619 |
| Year Make Model | Trim | Engine |
|---|---|---|
| 2004-2007 Buick Rainier | All Trims | 6 Cyl 4.2L |
| 2002-2005 Chevrolet Trailblazer | All Trims | All Engines |
| 2006-2009 Chevrolet Trailblazer | All Trims | 6 Cyl 4.2L |
| 2002 Chevrolet Trailblazer EXT | All Trims | All Engines |
| 2003-2006 Chevrolet Trailblazer EXT | All Trims | 6 Cyl 4.2L |
| 2002-2004 GMC Envoy | All Trims | All Engines |
| 2005-2009 GMC Envoy | All Trims | 6 Cyl 4.2L |
| 2002 GMC Envoy XL | All Trims | All Engines |
| 2003-2006 GMC Envoy XL | All Trims | 6 Cyl 4.2L |
| 2004-2005 GMC Envoy XUV | All Trims | 6 Cyl 4.2L |
