Check if it fits by entering your vehicle info| Brand | Four Seasons |
| Part Number | 77586 |
| Part Description | Remanufactured A C Compressor With Clutch |
| Clutch Included | Yes |
| Clutch Maximum Diameter | 3.9375 |
| Coil Clock Position | Wire Lead |
| Coil Voltage | 12 |
| Compatible Refrigerant Oil Type | PAG 46 |
| Compressor Type | Scroll |
| Discharge Port Type | O-Ring |
| Distance From Clutch To Mounting Flange | 1.859375 |
| Mount Distance MM | 46.990 |
| Mounting Hardware | Not Included |
| Mounting Type | Tangent Mount |
| New or Reman | Remanufactured |
| O-Ring A Number/Desc | [24632] / Green O-Ring |
| O-Ring A Quantity | 2 |
| O-Ring B Number/Desc | Not Required |
| O-Ring B Quantity | NR |
| Pulley Belt Type | Serpentine |
| Pulley Diameter MM | 100.025 |
| Pulley Groove Quantity | 6 |
| Pulley Lip Diameter | 3.9375 |
| Pulley Outside Diameter | 3.9375 |
| Pulley Ridge Diameter | 3.9375 |
| Refrigerant Type | R134a |
| Suction Port Type | O-Ring |
| Switch Included | Heat Sensor |
| Terminal Type | Pin |
| UPC | 096361775862 |
| Year Make Model | Trim | Engine |
|---|---|---|
| 2000-2008 Jaguar S-Type | All Trims | 6 Cyl 3.0L |
| 2002-2008 Jaguar X-Type | All Trims | All Engines |
| 2000-2005 Lincoln LS | All Trims | 6 Cyl 3.0L |
