Check if it fits by entering your vehicle info| Brand | Four Seasons |
| Part Number | 36954 |
| Part Description | Thermal Engine Cooling Fan Clutch |
| Bolt Hole Quantity | 4 |
| Bolt Quantity | 4 |
| Bolt Thread | 5/16-18 Hole |
| Clutch Maximum Diameter | 7.2 |
| Clutch Type | B - Non-Thermal & Std Thermal |
| Color | Raw Aluminum in Color |
| Distance From Clutch To Mounting Flange | 1.75 |
| Electronic Clutch | Non Electronic |
| Fan Bolt Circle IN | 3 |
| Fan Bolt Circle MM | 76.2 |
| Material | Aluminum |
| Meets / Exceeds OEM | Yes |
| Mount Dia. IN | 2.33 |
| Mount Dia. MM | 59 |
| Mounting Hardware | Not Included |
| Mounting Hole Quantity | 4 |
| Mounting Type | Flange |
| New or Reman | New |
| Overall Dia. MM | 182.88 or 182.9 |
| Overall Height IN | 3.3 |
| Overall Height MM | 83.8 or 83.82 |
| Performance Rated | Yes |
| Pilot Depth IN | 0.75 |
| Pilot Depth MM | 19.05 or 19.1 |
| Pilot Dia. IN | .63 to .75 |
| Rotation | STD |
| SDS Required | No (135233618) |
| Style | Standard Duty |
| UPC | 096361369542 |
| Use Type | Standard |
| Year Make Model | Trim | Engine |
|---|---|---|
| 1975-1980 Buick Skyhawk | All Trims | All Engines |
| 1968 Buick Skylark | All Trims | 6 Cyl 4.1L |
| 1968 Buick Special | All Trims | 6 Cyl 4.1L |
| 1964 Cadillac Series 60 Fleetwood | All Trims | All Engines |
| 1969 Checker Deluxe | All Trims | 8 Cyl 5.3L |
| 1965-1966 Checker Marathon | All Trims | 8 Cyl 4.6L |
| 1965-1967 Checker Marathon | All Trims | 8 Cyl 5.3L |
| 1968 Checker Marathon | All Trims | 8 Cyl 5.4L |
| 1955-1957 Chevrolet Bel Air | All Trims | 8 Cyl 4.3L |
| 1957-1962 Chevrolet Bel Air | All Trims | 8 Cyl 4.6L |
