Check if it fits by entering your vehicle info| Brand | Four Seasons |
| Part Number | 46066 |
| Part Description | Thermal Engine Cooling Fan Clutch |
| Bolt Hole Quantity | 4 |
| Bolt Quantity | 4 |
| Bolt Thread | M6 x 1.0 Hole |
| Clutch Maximum Diameter | 7.4 |
| Clutch Type | D - Severe Duty & Truck Fan Drive |
| Color | Raw Aluminum in Color |
| Distance From Clutch To Mounting Flange | 2.42 |
| Electronic Clutch | Non Electronic |
| Fan Bolt Circle IN | 3.25 |
| Fan Bolt Circle MM | 82.55 or 82.6 |
| Material | Aluminum |
| Meets / Exceeds OEM | Yes |
| Mount Dia. IN | 1.86 (47mm) HEX |
| Mount Dia. MM | 47 HEX |
| Mounting Hardware | Not Included |
| Mounting Hole Quantity | 4 |
| Mounting Type | HEX |
| New or Reman | New |
| Overall Dia. MM | 188 |
| Overall Height IN | 4.94 |
| Overall Height MM | 125.2 |
| Performance Rated | Yes |
| Pilot Depth IN | 0.78 or 0.79 |
| Pilot Depth MM | 20.1 |
| Pilot Dia. IN | M36x2.000 |
| Rotation | REV |
| SDS Required | No (135233618) |
| Style | Severe Duty |
| UPC | 096361460669 |
| Use Type | Severe |
| Year Make Model | Trim | Engine |
|---|---|---|
| 2006-2015 Ford E-350 Super Duty | All Trims | 10 Cyl 6.8L |
| 2015 Ford E-350 Super Duty | All Trims | 8 Cyl 5.4L |
| 2016 Ford E-350 Super Duty | All Trims | All Engines |
| 2017-2018 Ford E-350 Super Duty | All Trims | 10 Cyl 6.8L |
| 1999-2010 Ford F-250 Super Duty | All Trims | 10 Cyl 6.8L |
| 1999-2010 Ford F-350 Super Duty | All Trims | 10 Cyl 6.8L |
