Vehicle Specific
Check if it fits by entering your vehicle info| Brand | Four Seasons |
| Part Number | 46085 |
| Part Description | Thermal Engine Cooling Fan Clutch |
| Bolt Hole Quantity | 4 |
| Bolt Quantity | 4 |
| Bolt Thread | M6 x 1.0 Hole |
| Clutch Maximum Diameter | 7.6 |
| Clutch Type | A - 5" & 6" Import |
| Color | Raw Aluminum in Color |
| Distance From Clutch To Mounting Flange | 2.89 |
| Electronic Clutch | Non Electronic |
| Fan Bolt Circle IN | 6.99 |
| Fan Bolt Circle MM | 177.5 |
| Material | Aluminum |
| Meets / Exceeds OEM | Yes |
| Mount Dia. IN | 2.77 |
| Mount Dia. MM | 70 |
| Mounting Hardware | Not Included |
| Mounting Hole Quantity | 4 |
| Mounting Type | Flange |
| New or Reman | New |
| Overall Dia. MM | 193 or 193.04 |
| Overall Height IN | 3.72 |
| Overall Height MM | 94.5 |
| Performance Rated | Yes |
| Pilot Depth IN | 0.67 |
| Pilot Depth MM | 17 |
| Pilot Dia. IN | 0.95 |
| Rotation | STD |
| SDS Required | No (135233618) |
| Style | Heavy Duty |
| UPC | 096361460850 |
| Use Type | Heavy |
| Year Make Model | Trim | Engine |
|---|---|---|
| 2001-2006 Mitsubishi Montero | All Trims | All Engines |
