1997 Chevrolet Express 2500 Fuel Pump
My Vehicle Change Vehicle
1997 Chevrolet Express 2500
< Back to View All
Fuel Systems
- Department
- Product Fit
- Brands
- Prices
OEM (Genuine) 1997 Chevrolet Express 2500 Fuel Pump
PartNumber: 25117340$169.47 MSRP:$319.80You Save: $150.33 (48%)Product Specifications- Notes: Express, Savana; Diesel Engines; Diesel
- Item Dimensions: 6.9 x 4.3 x 3.4 inches
- Item Weight: 1.80 Pounds
- Fitment Type: Direct Replacement
- Part Description: 1997 Chevrolet Express 2500 Fuel Pump
Vehicle Fitment- 1997 Chevrolet Express 2500 | Base, LS | 6 Cyl 4.3 L GAS, 8 Cyl 5.0 L GAS, 8 Cyl 5.7 L GAS, 8 Cyl 6.5 L DIESEL
Product Specifications- Notes: Over 8,600lb GVW; Sender & Pump Assy; wo/Calif Emissions
- Connector Color: White
- Connector Gender: Female
- Connector Shape: Oval
- Height: 345 mm
- Housing Length: 168 mm
- Housing Material: Plastic (Polyoxymethylene)
- Housing Width: 92 mm
- Inlet Type: Jet
- Length: 170 mm
- Lock Ring Included: No
- Maximum Flow Rating: 180 LPH
- Maximum Pressure: 110 PSI
- OE Part Number: 25314352, 25314356
- Outlet Diameter: 3/8''; 5/16''
- Outlet Quantity: 2
- Outlet Type: Male Quick Connect
- Seal Included: Yes
- Terminal Gender: Male
- Terminal Quantity: 4
- Terminal Type: Spade
- Top Mount Diameter: 112.5 mm
- Universal Or Specific Fit: Specific
- UPC: 747214303328
- Width: 154 mm
- Wire Gauge Measurement: 15 AWG; 17 AWG
- Wire Quantity: 4
- Part Description: 1997 Chevrolet Express 2500 Fuel Tank Sending Unit
Vehicle Fitment- 1997 Chevrolet Express 2500 | All Trims | All Engines
Product Specifications- Notes: without Evaporative Emission;without Fitting for Take-Off Fuel Line;Module has 1 Electrical Connector(s);Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
- Current Draw: 10
- Flow Rating: 32 gph
- Fuel Level Sender Assembly Included: Yes
- Fuel Type: Gas
- Gasket or Seal Included: Yes
- In Tank or External: In Tank
- Inlet Type: Strainer
- Internal or External Strainer: External
- Item Grade: Standard Replacement
- Maximum Pressure: 109.0 PSI
- Outlet Outside Diameter: 0.375''
- Outlet Quantity: 2
- Outlet Type: Quick Connect
- Pump Type: Electric
- Regulator Included: No
- Resistance Ohms Empty: 40.0
- Resistance Ohms Full: 250.0
- Strainer Included: Yes
- System Pressure: 62 psi
- Terminal Gender: Male
- Terminal Quantity: 4
- Terminal Type: Blade
- UPC: 689604060353
- Vapor Pressure Sensor: No
- Voltage: 13.0 VDC
- Part Description: 1997 Chevrolet Express 2500 Fuel Pump Module Assembly
Vehicle Fitment- 1997 Chevrolet Express 2500 | All Trims | 6 Cyl 4.3L
- 1997 Chevrolet Express 2500 | All Trims | 8 Cyl 5.0L
- 1997 Chevrolet Express 2500 | All Trims | 8 Cyl 5.7L
Product Specifications- Notes: with 1 Connectors;with Tag Code Marked VAZ;with 1 Connectors;with Tag Code Marked VAZ;with 1 Connectors;with Tag Code Marked VAZ;with 1 Connectors;with Tag Code Marked VAZ;with 1 Connectors;with Tag Code Marked VAZ;with 1 Connectors;with Tag Code Marked VAZ;with 1 Connectors;with Tag Code Marked VAZ;with 1 Connectors;with Tag Code Marked VAZ;with 1 Connectors;with Tag Code Marked VAZ
- Average Current Draw(A): 7.3
- Average Flow Rating(GPH): 35.6
- Connector Gender: Male
- Connector Quantity: 1
- Connector Shape: Rectangle
- Country of Orign: China
- Fuel Filter Included: No
- Fuel Sending Unit Included: Yes
- Fuel Tank Pressure Sensor Included: No
- Gasket or Seal Included: Yes
- Gasket Or Seal Material: NBR
- Grade Type: Regular
- Housing Material: POM
- In Tank or External: In Tank
- Inlet Size: 5/16
- Inlet Type: Quick Connect
- Installation Warnings: No
- Maximum Pump Pressure (PSI): 145
- Minimum Pump Pressure (PSI): 87
- Mounting Hardware Included: No
- Negative Ground: No
- Outlet Quantity: 1
- Outlet Type: Quick Connect
- Product Height (in): 6.3
- Product Length (in): 13.78
- Product Width (in): 7.52
- Pump Type: Turbine
- Regulator Included: No
- Resistance Ohms Empty: 40
- Resistance Ohms Full: 250
- Strainer Included: Yes
- Terminal Gender: Male
- Terminal Quantity: 4
- Terminal Type: PIN
- UPC: 00072845129772
- Voltage: 12V
- Weight (lbs): 2.19
- Wire Harness Included: Yes
- Part Description: 1997 Chevrolet Express 2500 Fuel Pump Module Assembly
Vehicle Fitment- 1997 Chevrolet Express 2500 | All Trims | 6 Cyl 4.3L
- 1997 Chevrolet Express 2500 | All Trims | 8 Cyl 5.0L
- 1997 Chevrolet Express 2500 | All Trims | 8 Cyl 5.7L
OEM (Genuine) 1997 Chevrolet Express 2500 Fuel Pump
PartNumber: 19367490$283.57 MSRP:$535.04You Save: $251.47 (48%)Product Specifications- Other Names: Fuel Gauge Sending Unit, Fuel Pump
- Item Dimensions: 20.5 x 8.0 x 5.9 inches
- Item Weight: 2.80 Pounds
- Fitment Type: Direct Replacement
- Replaced by: 19369945
- Part Description: 1997 Chevrolet Express 2500 Fuel Pump
Product Specifications- Notes: Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
- Current Draw: 2
- Flow Rating: 32 gph
- Fuel Type: Diesel
- Gasket or Seal Included: No
- In Tank or External: External
- Inlet Fitting Thread Size: M16-1.5
- Inlet Type: Female Threaded
- Item Grade: Standard Replacement
- Outlet Fitting Thread Size: M16 - 1.5
- Outlet Type: Female Threaded
- Pump Type: Electric
- Strainer Included: No
- System Pressure: 7 psi
- Terminal Gender: Female
- Terminal Quantity: 2
- Terminal Type: Pin
- UPC: 689604032633
- Voltage: 12 VDC
- Wiring Harness Included: No
- Part Description: 1997 Chevrolet Express 2500 In Line Electric Fuel Pump
Vehicle Fitment- 1997 Chevrolet Express 2500 | All Trims | 8 Cyl 6.5L
Autobest® Externally Mounted Electric Fuel Pump for 1997 Chevrolet Express 2500
PartNumber: F2310$27.68Product Specifications- Notes: Frame Mounted
- Average Current Draw(A): 1.6
- Average Flow Rating(GPH): 100
- Connector Gender: Male
- Connector Quantity: 1
- Country of Orign: China
- Gasket or Seal Included: Yes
- Gasket Or Seal Material: FKM
- In Tank or External: External
- Inlet Size: M16 x 1.5
- Inlet Type: Female Thread
- Installation Warnings: No
- Maximum Pump Pressure (PSI): 9.4
- Minimum Pump Pressure (PSI): 5.1
- Negative Ground: No
- Outlet Quantity: 1
- Outlet Type: Female Threaded
- Product Height (in): 2.05
- Product Length (in): 5.31
- Product Width (in): 2.05
- Pump Type: Sliding vane
- Regulator Included: No
- Strainer Included: No
- Terminal Gender: Female
- Terminal Quantity: 2
- Terminal Type: Wire
- UPC: 00072845123107
- Voltage: 12V
- Weight (lbs): 0.82
- Wire Harness Included: Yes
- Part Description: 1997 Chevrolet Express 2500 Externally Mounted Electric Fuel Pump
Vehicle Fitment- 1997 Chevrolet Express 2500 | All Trims | 8 Cyl 6.5L
OEM (Genuine) 1997 Chevrolet Express 2500 Fuel Pump
PartNumber: 19369945$283.57 MSRP:$535.04You Save: $251.47 (48%)Product Specifications- Notes: Gas
- Other Names: Fuel Gauge Sending Unit, Fuel Pump, Sending Unit
- Item Dimensions: 8.2 x 6.0 x 20.3 inches
- Item Weight: 2.80 Pounds
- Replaces: 25314777, 25314352, 25312112, 19367490, 25312309, 19177232
- Part Description: 1997 Chevrolet Express 2500 Fuel Pump
Vehicle Fitment- 1997 Chevrolet Express 2500 | Base, LS | 6 Cyl 4.3 L GAS, 8 Cyl 5.0 L GAS, 8 Cyl 5.7 L GAS
Product Specifications- Notes: Fits Tag Code VAZ; w/o Fitting for Take Off Fuel Line (RPO Code: 7T6); Except Export; w/o Pressure Sensor; w/1 Electrical Connectors
- Gasket Included: Y
- Hazardous Material: No
- Inlet Count: 1
- Inlet Type: Strainer
- Item Grade: Standard Replacement
- Maximum Free Flow Rate (gph): 60
- Maximum Pressure Rate (psi): 100
- Minimum Free Flow Rate (gph): 50
- Minimum Pressure Rate (psi): 80
- Outlet Count: 1
- Outlet Size: 3/8"
- Outlet Type: Quick Connect
- Package Contents: Pump & Kit
- Package Quantity: 1
- Warranty: Lifetime Limited Warranty
- Part Description: 1997 Chevrolet Express 2500 In-Tank Fuel Pump Module Assembly
Vehicle Fitment- 1997 Chevrolet Express 2500 | All Trims | 6 Cyl 4.3L
- 1997 Chevrolet Express 2500 | All Trims | 8 Cyl 5.0L
- 1997 Chevrolet Express 2500 | All Trims | 8 Cyl 5.7L
Product Specifications- Notes: DENSO Solution Module Assy-Turbine Pump & Design Upgrade Over OE
- Gaskets Included: Yes
- Internet Product Code (IPC): 7A9F4D914DD
- Item Grade: Premium Replacement
- Item has MSDS (SDS): Y
- MFG Brand Name: DENSO Auto Parts
- MFG Model # (Series): 953-0018
- MFG Name: DENSO
- Package Contents: Fuel Pump Module
- Supplier Company Name: DENSO
- Universal Or Specific Fit: Specific
- UPC: 042511193369
- Part Description: 1997 Chevrolet Express 2500 Fuel Pump Module
Vehicle Fitment- 1997 Chevrolet Express 2500 | All Trims | 6 Cyl 4.3L
- 1997 Chevrolet Express 2500 | All Trims | 8 Cyl 5.0L
- 1997 Chevrolet Express 2500 | All Trims | 8 Cyl 5.7L
Product Specifications- Notes: Discontinued; 12V
- UPC: 760687052104
- Part Description: 1997 Chevrolet Express 2500 Fuel Pump
Vehicle Fitment- 1997 Chevrolet Express 2500 | All Trims | 8 Cyl 5.0L
- 1997 Chevrolet Express 2500 | All Trims | 8 Cyl 5.7L
Product Specifications- Notes: Sell out reorder 953-0018
- Gaskets Included: Yes
- Internet Product Code (IPC): C409DCD5362
- Item Grade: Premium Replacement
- Item has MSDS (SDS): Y
- MFG Brand Name: DENSO Auto Parts
- MFG Model # (Series): 953-5054
- MFG Name: DENSO
- Package Contents: Fuel Pump Module
- Supplier Company Name: DENSO
- UPC: 042511163683
- Part Description: 1997 Chevrolet Express 2500 Fuel Pump Module Assembly
Vehicle Fitment- 1997 Chevrolet Express 2500 | All Trims | 6 Cyl 4.3L
- 1997 Chevrolet Express 2500 | All Trims | 8 Cyl 5.0L
- 1997 Chevrolet Express 2500 | All Trims | 8 Cyl 5.7L
Product Specifications- Gasket or Seal Included: Yes
- Inlet Attachment: Inlet-O-Ring Seat
- Inlet Size: Inlet-M16x1.5-6H
- Inlet Type: O-RING SEAT
- Internet Product Code (IPC): 1E1A564DBD3
- Item Grade: OEM Standard Part
- Item has MSDS (SDS): No
- Maximum Pressure (psi): 8
- MFG Brand Name: Airtex Products
- MFG Model # (Series): E3309
- Minimum Pressure (psi): 1.0
- Outlet Attachment: Outlet-O-RingSeat
- Outlet Size: Outlet - M16 x 1.5-6H
- Outlet Type: O-RING SEAT
- Package Contents: Pump and Kit
- Package Quantity: 1
- Supplier Company Name: Airtex Products
- UPC: 080044515371
- Voltage [V]: 12V
- Part Description: 1997 Chevrolet Express 2500 In-Tank Electric Fuel Pump
Vehicle Fitment- 1997 Chevrolet Express 2500 | All Trims | 8 Cyl 6.5L
Product Specifications- Notes: Strainer is Inside the Module Assembly;Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.;Actual OE Part
- Fuel Level Sender Assembly Included: Yes
- Fuel Type: Diesel
- Gasket or Seal Included: Yes
- In Tank or External: In Tank
- Inlet Type: Strainer
- Internal or External Strainer: External
- Item Grade: Standard Replacement
- Outlet Outside Diameter: 0.375''
- Outlet Quantity: 2
- Outlet Type: Quick Connect
- Regulator Included: No
- Resistance Ohms Empty: 0.1
- Resistance Ohms Full: 90.0
- Strainer Included: Yes
- Terminal Gender: Male
- Terminal Quantity: 4
- Terminal Type: Pin
- UPC: 689604059708
- Vapor Pressure Sensor: No
- Part Description: 1997 Chevrolet Express 2500 Fuel Pump Module Assembly
Vehicle Fitment- 1997 Chevrolet Express 2500 | All Trims | 8 Cyl 6.5L
