Cadillac Allante A/C Compressor
Select vehicle to guarantee fit
Make
Model
Year
< Back to View All
A/C & Heating
- Department
- Condition
- Brands
- Prices
$361.22 MSRP:$681.56You Save: $320.34 (48%)Product Specifications- Other Names: Compressor, Compressor Assembly
- Item Dimensions: 14.0 x 10.0 x 8.3 inches
- Item Weight: 15.80 Pounds
- Fitment Type: Direct Replacement
- Replaces: 1136547, 1136435, 1136473, 89019229, 89018939, 01136473, 01136547
- Part Description: Cadillac Allante Compressor Assembly
$247.79Product Specifications- Clutch Included: Yes
- Clutch Maximum Diameter: 4.250
- Coil Clock Position: 2
- Coil Voltage: 12
- Compatible Refrigerant Oil Type: PAG 150
- Compressor Type: DA6, HR6, HE6
- Distance From Clutch To Mounting Flange: 0.59375
- Mounting Hardware: Not Included
- Mounting Type: Type I, Metric Threads
- New or Reman: Remanufactured
- O-Ring A Number/Desc: [24354] / Sealing Washer
- O-Ring A Quantity: 2
- O-Ring B Number/Desc: Not Required
- O-Ring B Quantity: NR
- Pulley Belt Type: Serpentine
- Pulley Diameter MM: 107.950
- Pulley Groove Quantity: 6
- Pulley Lip Diameter: 4.250
- Pulley Outside Diameter: 4.250
- Pulley Ridge Diameter: 4.250
- Refrigerant Type: R134a
- Suc Prt Typ Note: w/ 5/8" x 5/8" Ports
- Suction Port Type: Sealing Washer
- Terminal Type: 8mm Pin Connector
- UPC: 096361579637
- Part Description: Cadillac Allante Remanufactured A C Compressor With Clutch
$134.32Product Specifications- Clutch Included: Yes
- Clutch Maximum Diameter: 4.250
- Coil Clock Position: 2
- Coil Voltage: 12
- Compatible Refrigerant Oil Type: PAG 150
- Compressor Type: HR6, DA6
- Distance From Clutch To Mounting Flange: 0.59375
- Mounting Hardware: Not Included
- Mounting Type: Type I, Metric Threads
- New or Reman: Remanufactured
- O-Ring A Number/Desc: [24615] / Green O-Ring
- O-Ring A Quantity: 2
- O-Ring B Number/Desc: Not Required
- O-Ring B Quantity: NR
- Pulley Belt Type: Serpentine
- Pulley Diameter MM: 107.950
- Pulley Groove Quantity: 6
- Pulley Lip Diameter: 4.250
- Pulley Outside Diameter: 4.250
- Pulley Ridge Diameter: 4.250
- Refrigerant Type: R134a
- Reman w/o Clutch: [57250] / Clutch Assembly
- Suc Prt Typ Note: W/ O-Rings / Sealing Washer
- Suction Port Type: Block Mount
- Terminal Type: 8mm Pin Connector
- UPC: 096361578630
- Part Description: Cadillac Allante Remanufactured A C Compressor With Clutch
$234.54Product Specifications- Belt Width IN: 0.875
- Clutch Included: Yes
- Clutch Maximum Diameter: 5.000
- Coil Clock Position: 2
- Coil Voltage: 12
- Compatible Refrigerant Oil Type: PAG 150
- Compressor Type: HD6
- Distance From Clutch To Mounting Flange: 0.59375
- Mounting Hardware: Not Included
- Mounting Type: Type 10 - All Ears No Threads
- New or Reman: Remanufactured
- O-Ring A Number/Desc: [24354] / Sealing Washer
- O-Ring A Quantity: 2
- O-Ring B Number/Desc: Not Required
- O-Ring B Quantity: NR
- Pulley Belt Type: Serpentine
- Pulley Diameter MM: 127.000
- Pulley Groove Quantity: 6
- Pulley Lip Diameter: 5.000
- Pulley Outside Diameter: 5.000
- Pulley Ridge Diameter: 5.000
- Refrigerant Type: R134a
- Suc Prt Typ Note: R12
- Suction Port Type: Sealing Washer
- Terminal Type: 8mm Pin Connector
- UPC: 096361579514
- Part Description: Cadillac Allante Remanufactured A C Compressor With Clutch
$191.12Product Specifications- Clutch Included: Yes
- Clutch Maximum Diameter: 5.000
- Coil Clock Position: 2
- Coil Voltage: 12
- Compatible Refrigerant Oil Type: PAG 150
- Compressor Type: HD6
- Distance From Clutch To Mounting Flange: 0.59375
- Mounting Hardware: Not Included
- Mounting Type: Type XII (All Ears w/o Threads)
- New or Reman: Remanufactured
- O-Ring A Number/Desc: [24354] / Sealing Washer
- O-Ring A Quantity: 2
- O-Ring B Number/Desc: Not Required
- O-Ring B Quantity: NR
- Pulley Belt Type: Serpentine
- Pulley Diameter MM: 127.000
- Pulley Groove Quantity: 6
- Pulley Lip Diameter: 5.000
- Pulley Outside Diameter: 5.000
- Pulley Ridge Diameter: 5.000
- Refrigerant Type: R134a
- Suc Prt Typ Note: R134A - V
- Suction Port Type: Sealing Washer
- Terminal Type: 8mm Pin Connector
- UPC: 096361579569
- Part Description: Cadillac Allante Remanufactured A C Compressor With Clutch
$273.68Product Specifications- Belt Width IN: 0.875
- Clutch Included: Yes
- Clutch Maximum Diameter: 5.000
- Coil Clock Position: 2
- Coil Voltage: 12
- Compatible Refrigerant Oil Type: PAG 150
- Compressor Type: HD6
- Distance From Clutch To Mounting Flange: 0.59375
- Mounting Hardware: Not Included
- Mounting Type: Type 10 - All Ears No Threads
- New or Reman: New
- O-Ring A Number/Desc: [24354] / Sealing Washer
- O-Ring A Quantity: 2
- O-Ring B Number/Desc: Not Required
- O-Ring B Quantity: NR
- O-Ring C Number/Desc: Not Required
- O-Ring C Quantity: NR
- Pulley Belt Type: Serpentine
- Pulley Diameter MM: 127.000
- Pulley Groove Quantity: 6
- Pulley Lip Diameter: 5.000
- Pulley Outside Diameter: 5.000
- Pulley Ridge Diameter: 5.000
- Refrigerant Type: R134a
- Suc Prt Typ Note: R134A - V
- Suction Port Type: Sealing Washer
- Terminal Type: 8mm Pin Connector
- UPC: 096361589513
- Part Description: Cadillac Allante A C Compressor With Clutch
$286.95Product Specifications- Clutch Included: Yes
- Clutch Maximum Diameter: 4.250
- Coil Clock Position: 2
- Coil Voltage: 12
- Compatible Refrigerant Oil Type: PAG 150
- Compressor Type: DA6, HR6, HE6
- Discharge Port Type: Sealing Washer
- Distance From Clutch To Mounting Flange: 0.59375
- Mount Distance MM: 15.240
- Mounting Hardware: Not Included
- Mounting Type: Type I Middle w/ Threads
- New or Reman: New
- O-Ring A Number/Desc: [24354] / Sealing Washer
- O-Ring A Quantity: 2
- O-Ring B Number/Desc: Not Required
- O-Ring B Quantity: NR
- O-Ring C Number/Desc: Not Required
- O-Ring C Quantity: NR
- Pulley Belt Type: Serpentine
- Pulley Diameter MM: 107.950
- Pulley Groove Quantity: 6
- Pulley Lip Diameter: 4.250
- Pulley Outside Diameter: 4.250
- Pulley Ridge Diameter: 4.250
- Refrigerant Type: R134a
- Suction Port Type: Sealing Washer
- Terminal Type: 8mm Pin Connector
- UPC: 096361589636
- Part Description: Cadillac Allante A C Compressor With Clutch
$249.08Product Specifications- Clutch Included: Yes
- Clutch Maximum Diameter: 4.250
- Coil Clock Position: 2
- Coil Voltage: 12
- Compatible Refrigerant Oil Type: PAG 46
- Compressor Type: DA6, HR6, HE6
- Discharge Port Type: Sealing Washer
- Distance From Clutch To Mounting Flange: 0.59375
- Mount Distance MM: 15.240
- Mounting Hardware: Not Included
- Mounting Type: Type I
- New or Reman: New
- O-Ring A Number/Desc: [24354] / Sealing Washer
- O-Ring A Quantity: 2
- O-Ring B Number/Desc: 24357
- O-Ring B Quantity: 1
- O-Ring C Number/Desc: 24358
- O-Ring C Quantity: 1
- Printed Foot Note: 3 Ear, Middle Ear Not threaded
- Pulley Belt Type: Serpentine
- Pulley Diameter MM: 107.950
- Pulley Groove Quantity: 6
- Pulley Lip Diameter: 4.250
- Pulley Outside Diameter: 4.250
- Pulley Ridge Diameter: 4.250
- Refrigerant Type: R134a
- Suction Port Type: Sealing Washer
- Terminal Type: 8mm Pin Connector
- UPC: 096361889637
- Part Description: Cadillac Allante New GM DA6, HR6, HE6 Compressor w/ Clutch
$265.03Product Specifications- Clutch Included: Yes
- Clutch Maximum Diameter: 4.250
- Coil Clock Position: 2
- Coil Voltage: 12
- Compatible Refrigerant Oil Type: PAG 150
- Compressor Type: HR6
- Discharge Port Type: Sealing Washer
- Distance From Clutch To Mounting Flange: 0.59375
- Mount Distance MM: 15.240
- Mounting Hardware: Not Included
- Mounting Type: Type I
- New or Reman: New
- O-Ring A Number/Desc: [24354] / Sealing Washer
- O-Ring A Quantity: 2
- O-Ring B Number/Desc: Not Required
- O-Ring B Quantity: NR
- O-Ring C Number/Desc: Not Required
- O-Ring C Quantity: NR
- Pulley Belt Type: Serpentine
- Pulley Diameter MM: 107.950
- Pulley Groove Quantity: 6
- Pulley Lip Diameter: 4.250
- Pulley Outside Diameter: 4.250
- Pulley Ridge Diameter: 4.250
- Refrigerant Type: R134a
- Suction Port Type: Sealing Washer
- Terminal Type: Spade
- UPC: 096361582637
- Part Description: Cadillac Allante A C Compressor With Clutch
$215.90Product Specifications- Clutch Included: Yes
- Clutch Maximum Diameter: 4.250
- Coil Clock Position: 2
- Coil Voltage: 12
- Compatible Refrigerant Oil Type: PAG 46
- Compressor Type: HR6
- Discharge Port Type: Sealing Washer
- Distance From Clutch To Mounting Flange: 0.59375
- Mount Distance MM: 15.240
- Mounting Hardware: Not Included
- Mounting Type: Type I
- New or Reman: New
- O-Ring A Number/Desc: [24354] / Sealing Washer
- O-Ring A Quantity: 2
- O-Ring B Number/Desc: 24357
- O-Ring B Quantity: 1
- O-Ring C Number/Desc: 24358
- O-Ring C Quantity: 1
- Pulley Belt Type: Serpentine
- Pulley Diameter MM: 107.950
- Pulley Groove Quantity: 6
- Pulley Lip Diameter: 4.250
- Pulley Outside Diameter: 4.250
- Pulley Ridge Diameter: 4.250
- Refrigerant Type: R134a
- Suction Port Type: Sealing Washer
- Terminal Type: Spade
- UPC: 096361882638
- Part Description: Cadillac Allante A C Compressor With Clutch
$211.77Product Specifications- Clutch Included: Yes
- Clutch Maximum Diameter: 5.000
- Coil Clock Position: 2
- Coil Voltage: 12
- Compatible Refrigerant Oil Type: PAG 46
- Compressor Type: HD6
- Discharge Port Type: Sealing Washer
- Distance From Clutch To Mounting Flange: 0.59375
- Mount Distance MM: 15.240
- Mounting Hardware: Not Included
- Mounting Type: Type XII All Ears no Threads
- New or Reman: New
- O-Ring A Number/Desc: [24354] / Sealing Washer
- O-Ring A Quantity: 2
- O-Ring B Number/Desc: Not Required
- O-Ring B Quantity: NR
- O-Ring C Number/Desc: Not Required
- O-Ring C Quantity: NR
- Pulley Belt Type: Serpentine
- Pulley Diameter MM: 127.000
- Pulley Groove Quantity: 6
- Pulley Lip Diameter: 5.000
- Pulley Outside Diameter: 5.000
- Pulley Ridge Diameter: 5.000
- Refrigerant Type: R134a
- Suction Port Type: Sealing Washer
- Switch Included: High Pressure
- Terminal Type: 8mm Pin Connector
- UPC: 096361889569
- Part Description: Cadillac Allante New GM HD6 Compressor w/ Clutch
$177.93Product Specifications- Clutch Included: Yes
- Clutch Maximum Diameter: 5.000
- Coil Clock Position: 2
- Coil Voltage: 12
- Compatible Refrigerant Oil Type: PAG 150
- Compressor Type: HD6
- Distance From Clutch To Mounting Flange: 0.59375
- Mounting Hardware: Not Included
- Mounting Type: Type XII (All Ears no threads)
- New or Reman: New
- O-Ring A Number/Desc: [24354] / Sealing Washer
- O-Ring A Quantity: 2
- O-Ring B Number/Desc: Not Required
- O-Ring B Quantity: NR
- O-Ring C Number/Desc: Not Required
- O-Ring C Quantity: NR
- Pulley Belt Type: Serpentine
- Pulley Groove Quantity: 6
- Pulley Lip Diameter: 5.000
- Pulley Outside Diameter: 5.000
- Pulley Ridge Diameter: 5.000
- Refrigerant Type: R134a
- Suc Prt Typ Note: R134A - V
- Suction Port Type: Sealing Washer
- Switch Included: High Pressure
- Terminal Type: 8mm Pin Connector
- UPC: 096361589568
- Part Description: Cadillac Allante A C Compressor With Clutch
$237.81Product Specifications- Belt Width IN: 0.875
- Belt Width MM: 22.225
- Clutch Included: Yes
- Clutch Maximum Diameter: 5.000
- Coil Clock Position: 2
- Coil Voltage: 12
- Compatible Refrigerant Oil Type: PAG 46
- Compressor Type: HD6
- Discharge Port Type: Sealing Washer
- Distance From Clutch To Mounting Flange: 0.59375
- Mount Distance MM: 15.240
- Mounting Hardware: Not Included
- Mounting Type: Type X All Ears no Threads
- New or Reman: New
- O-Ring A Number/Desc: [24354] / Sealing Washer
- O-Ring A Quantity: 2
- O-Ring B Number/Desc: Not Required
- O-Ring B Quantity: NR
- O-Ring C Number/Desc: Not Required
- O-Ring C Quantity: NR
- Pulley Belt Type: Serpentine
- Pulley Diameter MM: 127.000
- Pulley Groove Quantity: 6
- Pulley Lip Diameter: 5.000
- Pulley Outside Diameter: 5.000
- Pulley Ridge Diameter: 5.000
- Refrigerant Type: R134a
- Suction Port Type: Sealing Washer
- Terminal Type: 8mm Pin Connector
- UPC: 096361889514
- Part Description: Cadillac Allante New GM HD6 Compressor w/ Clutch
Product Specifications- Clutch Maximum Diameter: 127.0 mm
- Compressor Mount Hole Quantity: 3
- Mounting Type: Three Ear Mount
- OE Part Number: 19169358, 1136441, 1136468, 1136511, 1136534, 1136027, 1136037, 1136501, 1136403, 1136545
- Pulley Belt Type: Serpentine
- Refrigerant Type: R134A
- UPC: 042511092044
- Part Description: Cadillac Allante New Compressor W/ Clutch
Product Specifications- Belt Type: Serpentine
- Clutch Included: Yes
- Clutch Pulley Diameter: 138.5 mm
- Coil Clock Position: 2 o'clock
- Coil Voltage: 12V
- Compressor Type: H6
- Connector Terminal Quantity: 2
- Connector Type: Female, 2 Blade
- Length: 8 55/64 " (225.0 mm)
- Mounting Type: Ear Mount
- New or Remanufactured: New
- Oil in Compressor: Yes
- Oil Type: PAG
- Package Contents: O-rings/sealing washers included
- Pulley Groove Quantity: 6
- Refrigerant Type: R134A
- Switch Included: No
- Switch Service Port: No
- UPC: 689604068502
- Part Description: Cadillac Allante A C Compressor With Clutch
- Product Specifications
- Other Names: Compressor, Compressor Assembly
- Item Dimensions: 11.7 x 8.2 x 8.9 inches
- Item Weight: 16.50 Pounds
- Fitment Type: Direct Replacement
- Replaces: 1136501
- Part Description: Cadillac Allante Air Conditioner Compressor H6
Product Specifications- Clutch Included: Yes
- Clutch Maximum Diameter: 4.250
- Coil Clock Position: 2
- Coil Type: Spade
- Coil Voltage: 12
- Compatible Refrigerant Oil Type: PAG 150
- Compressor Type: HR6, DA6
- Distance From Clutch To Mounting Flange: 0.59375
- Mounting Hardware: Not Included
- Mounting Type: Type I, Metric Threads
- New or Reman: Remanufactured
- O-Ring A Number/Desc: [24615] / Green O-Ring
- O-Ring A Quantity: 2
- O-Ring B Number/Desc: Not Required
- O-Ring B Quantity: NR
- Pulley Belt Type: Serpentine
- Pulley Diameter MM: 107.950
- Pulley Groove Quantity: 6
- Pulley Lip Diameter: 4.250
- Pulley Outside Diameter: 4.250
- Pulley Ridge Diameter: 4.250
- Refrigerant Type: R134a
- Reman w/o Clutch: [57250]
- Suc Prt Typ Note: W/ O-Rings / Sealing Washer
- Suction Port Type: Block Mount
- Switch Included: High Pressure
- Terminal Type: Spade
- UPC: 096361572638
- Part Description: Cadillac Allante Remanufactured A C Compressor With Clutch
Product Specifications- Clutch Included: Yes
- Clutch Maximum Diameter: 4.250
- Coil Clock Position: 2
- Coil Voltage: 12
- Compatible Refrigerant Oil Type: PAG 150
- Compressor Type: DA6
- Distance From Clutch To Mounting Flange: 0.59375
- Mounting Hardware: Not Included
- Mounting Type: Type I Metric Thread
- New or Reman: Remanufactured
- O-Ring A Number/Desc: [24615] / Green O-Ring
- O-Ring A Quantity: 2
- O-Ring B Number/Desc: Not Required
- O-Ring B Quantity: NR
- Pulley Belt Type: Serpentine
- Pulley Diameter MM: 107.950
- Pulley Groove Quantity: 6
- Pulley Lip Diameter: 4.250
- Pulley Outside Diameter: 4.250
- Pulley Ridge Diameter: 4.250
- Refrigerant Type: R134a
- Reman w/o Clutch: [57250] / Clutch Assembly
- Suc Prt Typ Note: W/ O-Rings / Sealing Washer
- Suction Port Type: Block Mount
- Switch Included: High Pressure
- Terminal Type: Spade
- UPC: 096361576636
- Part Description: Cadillac Allante Remanufactured A C Compressor With Clutch
Product Specifications- UPC: 671607335347
- Part Description: Cadillac Allante A/C Compressor
Product Specifications- UPC: 042511091917
- Part Description: Cadillac Allante A/C Compressor
Product Specifications- UPC: 671607331554
- Part Description: Cadillac Allante A/C Compressor
- Product Specifications
- Other Names: Compressor, Compressor Assembly
- Item Dimensions: 14.4 x 9.8 x 8.2 inches
- Item Weight: 15.50 Pounds
- Fitment Type: Direct Replacement
- Replaces: 89018914, 01136461, 1136461, 1136419
- Part Description: Cadillac Allante Air Conditioner Compressor And Component Kit
Product Specifications- Clutch Maximum Diameter: 108.0
- Compressor Mount Hole Quantity: 3
- Mounting Type: Three Ear Mount
- New or Remanufactured: New
- Pulley Belt Type: Serpentine
- Refrigerant Type: R134A
- UPC: 042511092075
- Part Description: Cadillac Allante A/C Compressor
Product Specifications- UPC: 671607330526
- Part Description: Cadillac Allante A/C Compressor
