2017 Mazda CX-9 Timing Belts, Chains, Cams & Related Parts
My Vehicle Change Vehicle
2017 Mazda CX-9
< Back to View All
Engine & Drivetrain
- Department
- Part Type
- Brands
- Prices
$185.22Product Specifications- Color: Silver/Zinc-Plated/Brass
- Components Included: No
- Electrical Connection Quantity: 1
- Electrical Connector Gender: Male
- Electrical Connector Terminal Quantity: 2
- Electrical Connector Terminal Type: Plug and Socket
- Electrical Connector Type: Plug and Socket
- Height: 4"
- Housing Material: Plastic
- Item Grade: Standard Replacement
- Overall Length: 1.15"
- Overall Width: 2"
- Plug/Connector Type: Plug and Socket
- Quantity of Wires: 2
- Shaft Diameter: 0.7"
- Solenoid Activation Type: Electromagnetic
- Solenoid Finish: Stainless Steel
- Terminal Gender: Female
- Type: Intake
- UPC: 885484591769
- Voltage: 12v
- Part Description: 2017 Mazda CX-9 OE Solutions Intake Variable Valve Timing Solenoid
Vehicle Fitment- 2017 Mazda CX-9 | All Trims | 4 Cyl 2.5L
$14.55Product Specifications- OE Comparison Rating: OE Performance
- Outside Circumference: 981 mm
- Rib Quantity: 6
- Section: K
- Top Width: 20 mm
- UPC: 072053008982
- Part Description: 2017 Mazda CX-9 Micro V V Ribbed Belt
Vehicle Fitment- 2017 Mazda CX-9 | All Trims | 4 Cyl 2.5L
$10.47Product Specifications- Notes: Routing:Crk,Wp; 790mm; OE: P301-15-908;Routing:Crk,Tens,Alt,Comp; 971mm; From 09/01/2016; OE: PY01-15-909A;OE: PY01-15-909; Routing:Crk,Tens,Alt,Comp; 971mm; To 09/01/2016
- Effective Length: 38"
- Inch Number: 380K6
- Rib Quantity: 6
- Top Width: 0.84"
- UPC: 649717002374
- Part Description: 2017 Mazda CX-9 Rib Ace™ V-Ribbed Serpentine Belt
Vehicle Fitment- 2017 Mazda CX-9 | All Trims | All Engines
$18.06Product Specifications- Notes: Serpentine Belt
- Color: Black
- Cross Section: K-Section
- Effective Length: 38.228; 971.00
- Material: EPDM, Aramid Reinforced
- Maximum Operating Temperature: 100; 212
- Minimum Operating Temperature: -42.7; -45
- Outside Circumference: 38.787; 985.19
- Rib Depth: Standard
- Rib Profile: W Profile
- Rib Quantity: 6
- Standards: SAE J1459, SAE J2432
- Top Width: .82
- UPC: 036687888853
- Part Description: 2017 Mazda CX-9 Poly Rib Serpentine Belt
Vehicle Fitment- 2017 Mazda CX-9 | All Trims | All Engines
$103.32Product Specifications- Color/Finish: Black
- Degree Markings: Yes
- Depth: 50.5 mm
- Drive Belt Type: Serpentine
- Grade Type: Regular
- Inside Diameter: 30.05 mm
- Keyway Type: Yes
- Mounting Hole Diameter: 30.05 mm
- OE Part Number: PE0111400, PE0111400A
- Outside Diameter: 144 mm
- Pulley Groove Quantity: 9
- UPC: 885484901285
- Part Description: 2017 Mazda CX-9 Oe Solutions Harmonic Balancer
Vehicle Fitment- 2017 Mazda CX-9 | All Trims | 4 Cyl 2.5L
$114.40Product Specifications- Bearing Bore Inside Diameter 1: 17
- Bearing Bore Inside Diameter 1 (in): .67
- Belt Type: V-Ribbed
- Contact Surface: Smooth/Backside
- Contents: Tensioner Assy., Bolt, Hydraulic Damper
- Material: Thermoplastic
- Mounting Hole Quantity: 2
- OE Comparison Rating: OE Performance
- Outside Diameter: 2.56; 65
- Pulley 1 Flanged: No
- Pulley Quantity: 1
- UPC: 770075762171
- Width: 1; 25.5
- Part Description: 2017 Mazda CX-9 Automatic Belt Tensioner
Vehicle Fitment- 2017 Mazda CX-9 | All Trims | 4 Cyl 2.5L
$88.37Product Specifications- Belt Type: Serpentine
- Direction: Linear
- Number Of Pulleys: 1
- Pulley 1 Diameter: 65
- Pulley 1 Flat: Y
- Pulley 1 Width: 25
- UPC: 036687924216
- Part Description: 2017 Mazda CX-9 No Slack Light Duty Automatic Tensioner
Vehicle Fitment- 2017 Mazda CX-9 | All Trims | All Engines
Product Specifications- Color/Finish: Silver/Zinc-Plated
- Connector Color: Black
- Connector Shape: Oval
- Electrical Connection Quantity: 1
- Electrical Connector Gender: Female
- Electrical Connector Terminal Quantity: 2
- Electrical Connector Terminal Type: Blade
- Electrical Connector Type: Plug and Socket
- Height: 1.22"
- Housing Length: 1.38"
- Housing Material: Metal
- Housing Width: 1.22"
- Mount Hole Quantity: 1
- Overall Length: 3.11"
- Overall Width: 1.22"
- Plug/Connector Type: Plug and Socket
- Quantity of Wires: 0
- Shaft Diameter: 0.79"
- Solenoid Activation Type: Electromagnetic
- Solenoid Finish: Zinc Plated
- Terminal Gender: Male
- UPC: 885484765627
- Voltage: 12V
- Part Description: 2017 Mazda CX-9 OE Solutions Exhaust Variable Valve Timing Solenoid
Vehicle Fitment- 2017 Mazda CX-9 | All Trims | 4 Cyl 2.5L
Product Specifications- Notes: Elastic Self-Tensioning Belt
- Color: Black
- Cross Section: K-Section
- Effective Length: 0
- Free Length: 30.5; 774.700
- Material: EPDM4
- Maximum Operating Temperature: 100; 212
- Minimum Operating Temperature: -42.7; -45
- Outside Circumference: 0
- Rib Depth: Standard
- Rib Profile: Straight Rib
- Rib Quantity: 3
- Standards: SAE J1459
- Top Width: .40
- UPC: 036687908018
- Part Description: 2017 Mazda CX-9 Poly Rib Self Tensioning Serpentine Belt
Vehicle Fitment- 2017 Mazda CX-9 | All Trims | All Engines
